System Specifications

Features
Below is a brief summary of the graphics dock many features:
Video Controller
ATI Mobility Radeon HD 4670
Dimensions and Weight)
Weight: 0.65 kg
Dimensions: 193.5 (W) x 193.5 (D) x 32.8 (H) mm
Power supply
3-pin 65 W AC adapter
SI/O interface
Six USB ports
HDMI port
HDCP supported external display (VGA) port
DC-in jack for AC adapter
Acer DynaVivid Graphics Dock connector
Environment
Temperature:
Operating: 5 °C to 35 °C
Non-operating: -20 °C to 65 °C
Humidity (non-condensing):
Operating: 20% to 80%
Non-operating: 20% to 80%
NOTE: The specifications listed above are for reference only. The exact configuration of the graphics dock
depends on the model purchased.
Chapter 1
Chapter 1
1
