Replacing the Monitor Mount

1.
Place the graphics dock onto the monitor mount.
2.
Slide the monitor mount latch switch open (1) and press the graphics dock down (2) until it latches in
place.
3.
Repeat Step 2 on the other side.
24
2
1
2
1
Chapter 2
