Sanitaire
14" Autoscrubber
SC6200A
Part No. SC6200A Rev 2 (11/13)
PLEASE RETAIN
We suggest you record the model, type, and serial numbers
below. They are located on the silver rating plate on your
unit. For prompt and complete service information, always
refer to these numbers when inquiring about service.
Model & Type____________________________
Serial No._______________________________
It is also important to keep your receipt as proof of date of
purchase.
®
©2013 Electrolux Home Care Products Ltd.
Owner's Guide
IMPORTANT
Do not return this product to the store.
Call 1-800-800-8975*
Monday - Friday 8:00 AM to 7:30 PM
and Saturday 10 AM to 6:30 PM
Central time or visit our web site,
www.sanitairevac.com for any of the
following:
• assembly problems
• replacement of broken or missing
items
• to review repair parts list
• to order replacement parts and
accessories
• to locate the nearest sanitaire
warranty station
*En Mexico llame al 5670-6169
1
www.sanitairevac.com
Advertisement
Table of Contents
Related Manuals for Sanitaire SC6200A
Summary of Contents for Sanitaire SC6200A
- Page 1 Sanitaire ® 14” Autoscrubber SC6200A Part No. SC6200A Rev 2 (11/13) Owner’s Guide IMPORTANT Do not return this product to the store. Call 1-800-800-8975* Monday - Friday 8:00 AM to 7:30 PM and Saturday 10 AM to 6:30 PM Central time or visit our web site, www.sanitairevac.com for any of the...
- Page 2 WHAT THIS WARRANTY COVERS Your Sanitaire commercial cleaner is warranted to be free from all defects in material and workmanship in normal use FOR A PERIOD OF ONE YEAR. The warranty is granted only to the original purchaser of the cleaner. The warranty is sub- ject to the following provisions.
- Page 3 If it is necessary to ship the cleaner outside your community to obtain warranty repair, you must pay the shipping charg- es to the Sanitaire Authorized Warranty Station. Return shipping charges will be paid by the Warranty Station. When returning parts for repair, please include the model, type and serial numbers from the data plate on the cleaner.
-
Page 4: Grounding Instructions
GROUNDING INSTRUCTIONS This appliance must be grounded If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment grounding conductor and grounding plug. The plug must be inserted into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 5: Safety Instructions And Warnings
Use this unit only as described in this manual. Use only manufacturer’s recommended attachments. To reduce the risk of personal injury or damage to your unit use only Sanitaire recommended accessories Important Safety Advice... -
Page 6: Extension Cords
• Leaks from battery cells can occur under extreme usage or temperature conditions. If liquid gets on the skin, wash quickly with water. If the liquid gets into the eyes, flush them immediately with clean water for a minimum of 10 minutes. Seek medical attention. • While there is no shock hazard from electrical terminals located on the vacuum, a burn could re- sult from metal objects being inserted onto the terminal areas. - Page 7 1. Handle 12. Handle Adjusting Lever 2. Recovery Tank Lid 13. Squeegee Lifting Lever 3. Recovery Tank 14. Recovery Tank Drain Hose 4. Solution Tank Filling Opening 15. Vacuum Hose 5. Solution Tank 16. Battery Charger Lead 6. Brush Guard 17.
- Page 8 1 Product Information 1.3 Guidelines for the operator This commercial automatic scrubber is designed for the WARNING scrubbing/cleaning of hard floors in indoor areas. Operators must be fully trained in the use of the machine in accordance with these Maintenance free (gel) batteries must be used. A battery life instructions, able to perform user mainte- indicator allows the operator to check the degree of bat- nance and the correct selection of accessories.
- Page 9 To move the machine to the work area lock handle and tilt • Remove the recovery water tank (Fig 2). backwards to raise the front off the floor, and wheel into position. CAUTION – Bumping over thresholds, curbs and similar obstacles can damage the machine. Pull the machine backwards to go over small obstacles. 1.4 Symbols & Markings In order to highlight information and procedures regarding Fig 2 safety, maintenance etc, the following symbols have been...
- Page 10 • Let the batteries charge until the “Green” LED comes on, then remove the plug and wind the battery charging around the cable holder (Fig 5). Fig 5 NOTE: 10 hours are required for complete battery charge. • IMPORTANT - Overcharging will damage the batteries. This will cause run time to be reduced and overall battery life will be affected.
- Page 11 before refilling the solution tank. 3 Controls The operating controls are located on the handle. (Fig 9). The icons adjacent to each switch identify the functions. Fig 10 5 – Brush rotating and/or water dispensing lever Pressing and holding lever 5 will start the rotation of the brush.
- Page 12 • Washing, brushing, drying cycle Press button 2 to start the vacuum, button 4 (Fig 9) to release solution and press the lever 5 (Fig 10) to start the cycle. 4.3 Using the machine WARNING! Never start the machine without a brush or pad attached. • Set the handle set at a comfortable working height.
- Page 13 with vacuum motor OFF. Scrub floor again, picking up the 5.2 Draining and cleaning the recovery tank solution. At the end of the cleaning cycle or when the recovery WARNING - If foam or liquid is leaking, turn tank is full, it is necessary to empty the tank by proceeding the machine off immediately and empty the as follows: recovery tank.
- Page 14 • Wash the inside of the tank, leaving the drain cap open 6.1 Prolonged storage and adding clean water though the front opening. • After cleaning, replace the cap, pushing inwards. • Drain the clean water contained in the tank. • IMPORTANT – To dispose of unused cleaning solution, • Place the machine under cover, in a place where the tem- comply with the local, state, and federal standards perature is between 40°F and 105°F. in force in the country in which the machine is • Charge the batteries and, once they are charged, discon- being used.
- Page 15 7.3 Changing the brush or pad driver • Lift the machine up slightly at the front • Press the brush rotation button (3) to enable the rotation of the brush, then press lever (5) and release it; the brush becomes disconnected (Fig 23) Fig 21 NOTE: It is possible to have two types of rubber blades. Para (Fig 23) rubber blades for all types of floors and polyurethane 7.4 Replacing the fuses (Fig 24) rubber blades for mechanical workshop floors which are...
- Page 16 7.5 Operations to perform weekly Cleaning the clean water filter (Fig. 25) Fig 25 • Make sure that the solution tap is fully closed. Refer to Fig • Unscrew the transparent filter cover (1) and remove the filter (2). • Clean the filter (2) in running water. If it is blocked, replace • Replace all the components in reverse order.
- Page 17 8 Technical specification Model SC6200A Battery Scrubber Charging Voltage/Frequency 110-120/50-60 VAC/Hz DC Voltage Charging Time Hours Run Time Minutes Brush Cleaning Width Inches Squeegee Width Inches Brush Pressure g/cm Brush Speed Working capacity (Theoretical) 11,945 Sqft/Hour Solution Tank Capacity Gallons...
-
Page 18: Troubleshooting
TROUBLESHOOTING THE MACHINE DOES NOT START UP CAUSE: SOLUTION: Low battery Check/Charge battery. Main 30A fuse blown Replace GREEN 30A fuse. THE BRUSH DOES NOT ROTATE CAUSE: SOLUTION: 1) Brush unit outlet overcurrent error or brush 1) See paragraph ‘Warning signals while using unit open circuit error the machine (Section 5) 2) Brush rotation button not pressed on handle...
