Safety instructions

Care
- Read and follow the operating and installation instructions and all other information enclosed
with the washing machine.
- Retain documents for subsequent use.
Risk of electric shock - Never pull out the mains plug by tugging the power cord!
- Never insert/pull out the mains plug with damp hands.
Danger to life Redundant appliances:
- Pull out the mains plug.
- Sever the power cord and discard together with the plug.
- Destroy the lock on the washing machine door.
This will prevent children from locking themselves in and
1.
suffocating.
Risk of suffocation - Keep packaging, plastic film and packaging parts out of the reach
of children.
Risk of poisioning - Keep detergents and care products out of the reach of children. 2.
Risk of explosion - Caused by detergents containing solvents, e.g. stain
remover/items of washing pretreated with solvent naphtha may 3.
result in an explosion after being loaded into the washing machine.
Before hand thoroughly rinse items of washing by hand.
4.
Risk of injury - Washing machine door may become very hot.
- Caution when draining hot detergent solution.
- Do not climb on the washing machine.
- Do not lean on the open washing machine door.
- Do not touch the drum in case it is still spinning.

Consumption values

Programme Additonal Load Current** Water** Programme
function duration**
resistentes algod.
7 intensivo
8,0 kg 0.94 kWh 80 l 2:12 h
(Cottons/Coloureds) 40 °C*
(Intensive Wash)
resistentes algod. 7 intensivo
8,0 kg 1.65 kWh 80 l 2:12 h
(Cottons/Coloureds) 60 °C* Information about the indicator lights
(Intensive Wash)
intensivo
extra (Eco) 60 °C* 7
8,0 kg 1.20 kWh 56 l 3:25 h
(Intensive Wash)
depending on model
resistentes algod. intensivo
7
8,0 kg 2.73 kWh 97 l 2:12 h
(Cottons/Coloureds) 90 °C A signal sounds and the spin speed indicator lamps and the status displays flash:
(Intensive Wash)
intensivo
sintéticos (Easy Care) 40 °C* 7
3,5 kg 0.55 kWh 53 l 1:12 h
(Intensive Wash)
sintéticos (Easy Care) 60 °C*
- 3,5 kg 0.54 kWh 53 l 0:45 h
(also suitable as Short programme)
delicado (Delicates/Silk)
- 2,0 kg 0.03 kWh 39 l 0:40 h
frio (Cold)
lana/lã u (Wool) frio (Cold)
- 2,0 kg 0.08 kWh 40 l 0:36 h
lana/lã u (Wool) 30 °C
- 2,0 kg 0.20 kWh 40 l 0:36 h
* Programme setting to be tested in accordance with European standard 60 456.
Note on comparative tests: test the test programme with maximum load,
7 intensivo (Intensive Wash) option selected, maximum spin speed.
A short programme which can be used for coloured items is sintéticos (Easy Care) 40 ºC,
without the intensivo (Intensive Wash) option selected and set to maximum spin speed.
7 Other displays:
** The values deviate from the indicated values depending on water pressure, water hardness, water Switch off the appliance, wait for 5 seconds and switch it back on.
inlet temperature, room temperature, type and amount of washing and degree of soiling, If the display appears again, call customer services -> Installation instructions, Page 7.
7 8
utilised detergent, fluctuations in the mains voltage and selected additional functions.
Risk of electric shock!

Maintenance

Pull out the mains plug!
Risk of explosion! No solvents!
Detergent solution pump
Machine housing, control panel
Set programme selector to stop (Off), pull out the mains plug.
- Wipe with a soft, damp cloth.
1. Open and remove service flap.
- Do not use any abrasive cloths, sponges or cleaning agents (stainless steel cleaner).
- Immediately remove washing and cleaning agent residue.
- Do not clean the appliance with a water jet. 2. Take the drainage hose out of the holder.
Remove sealing cap, allow detergent solution to flow
Clean the detergent drawer ...
out.
... if it contains detergent or fabric softener residue.
Put the closing cap back on the hose.
Pull out, depress insert, completely remove.
Remove insert: Press insert upwards with finger.
3. Carefully unscrew the pump cover (residual water).
Clean detergent dispenser and insert with water and a brush and dry.
4. Clean the interior, pump cover thread and pump housing
(fan impeller in the detergent solution pump must rotate).
Attach insert and engage (connect cylinder to guide pin).
Insert detergent drawer.
5. Re insert pump cover and screw on tight, handle is upright.
Insert the drain hose into the holder.
Leave detergent drawer open so that residual water can evaporate.
6. Insert and close service flap.
Drum
To prevent unused detergent from flowing into the outlet during the next wash:
Leave washing machine door open so that the drum can dry out. Pour 1 litre of water into dispenser II and start the b (Empty) programme.
Rust stains use chlorine free cleaning agent, not steel wool.
Descaling Drainage hose at the siphon
No washing in the machine!
Set the programme selector to stop (Off), disconnect the mains plug.
Not necessary if detergent dispensed correctly. However, follow the instructions of the descaler
manufacturer.
1. Loosen the hose clamp, carefully remove the drainage hose (residual water).
2. Clean the drainage hose and siphon connecting piece.
3. Reattach the drainage hose and secure the connection with the hose clamp.
Filter in the water inlet hose
Risk of electric shock!
Release water pressure in the supply hose:
1. Turn off the tap!
Close the washing Turn the tap on fully, Clean detergent
2. Select any programme (except B (Spin)/b (Empty)).
machine door properly; supply hose kinked/ solution pump ->
3. Select 0 inicio/pausa (Start/Pause). Leave programme for approx. 40
washing may be jammed; Page 10; outlet pipe/
seconds.
caught. Clean filter > Page 10; drainage hose
4. Set programme selector to stop (Off). Pull out the mains plug.
water pressure too low. blocked.
Clean filter:
Water in the base pan, 1. Depending on model:
Motor fault.
appliance leaking. Call
or or Remove hose from tap.
Call customer service!
customer service! Clean filter with small brush.
or
Remove hose from the rear.
Remove filter with pliers and clean.
2. Connect the hose and check for leaks.
9
Risk of scalding!
What to do if ...
Allow deterhgent solution to cool down!
Turn off the tap!
F Water is running out. - Correctly attach/replace drainage hose.
- Tighten screw fitting on the supply hose.
F Water not flowing in. - 0 inicio/pausa (Start/Pause) not selected?
Detergent not washed - Tap not open?
in. - Filter blocked? Clean filter -> Page 10.
- Supply hose kinked or jammed?
F Washing machine door - Safety function active. Programme stopped? -> Page 4.
- D (Rinse stop = without final spin) selected? -> Page 4.
cannot be opened.
- Can be opened via emergency release only -> Page 6.
F Programme does not - 0 inicio/pausa (Start/Pause) selected?
start. - Washing machine door closed?
F Detergent solution is not - Clean detergent solution pump -> Page 10.
drained. - Clean outlet pipe and/or drainage hose.
Water not visible in the - Not a fault - water below the visible area.
F
drum.
F Spin result not - Wash small and large items of washing together.
satisfactory. - menos (Less Ironing) selected? -> Page 5.
5
- Too low speed selected? -> Page 3.
F Spin cycle actuated - Not a fault - unbalanced load detection system adjusts
several times. imbalance.
F 2 - Remove the insert. Clean detergent drawer and insert > Page 9.
Dispenser not
completely rinsed out.
F Odour formation in the - Run resistentes algod. (Cottons/Coloureds) 90 ºC programme
washing machine. without washing. Use standard detergent.
F Foam is coming out of - Too much detergent used?
the detergent drawer. Mix 1 tablespoon of fabric softener with ½ litre of water and pour
into compartment II (not with outdoor fabrics!).
- Reduce detergent dosage for the next wash cycle.
F Intense noise formation, - Appliance feet fixed?
vibrations and Secure appliance feet > Installation instructions, Page 5.
"wandering" during spin - Transportation safety devices removed?
Remove transportation protection devices > Installation
cycle.
Do not immerse Aqua Stop safety device in water instructions, Page 3.
(contains electric valve).
F Indicator lights do not - Power failure?
function while the - Fuse tripped? Switch on/replace fuse.
appliance is running. - If the fault occurs repeatedly, call customer service.
F Programme progress - Not a fault - unbalanced load detection system adjusts imbalance
longer than usual. by repeatedly distributing the washing.
- Not a fault foam detection system active - a rinse cycle is
started.
F Detergent residue on the - Occasionally phosphate free detergents contain water insoluble
washing. residue.
- Select I rápido 15 min. (Super Quick 15') or brush the laundry
after washing.
F In the pause state - Water level too high. Top up washing is not possible.
0 inicio/pausa If required, close door immediately.
- Select "Start/Pause" to continue the programme.
(Start/Pause) flashes
very quickly and a signal
sounds.
F If a fault cannot be rectified or a repair is required:
- Set programme selector to stop (Off) and pull out the mains plug.
10 - Turn off tap and call customer service > Installation instructions, Page 7.
en
Operating instructions
Washing
machine
Read these instructions before switching on the washing
machine! Also follow the separate Installation instructions.
Follow the safety instructions on page 8!
