Page 1: Installation Guide
XNET Network Weatherproof Camera Installation Guide XNET Network Weatherproof Camera (IXC2050IR) Installation Guide Ver. 1.0 1/20... -
Page 2: Important Notices
About this Installation Guide A compatibility and durability test ensured this product’s high performance. This installation guide is for XNET Network Weatherproof Camera users only, and it describes operations related to XNET Network Weatherproof Camera. Please read this manual thoroughly paying attention to cautions and warnings before using the product even if you have used similar products before. -
Page 3: Table Of Contents
2.3.3 Cable Connection ....................8 2.3.4 Connecting to Alarm Devices .................. 9 3. Software Installation ......................10 3.1. Connecting XNET to network ..................10 3.1.1. Mounting the Camera ..................15 3.1.2. Installing XNET ....................15 3.2. Installing IP-Installer Software and Configuring IP address ..........15 3.2.1. -
Page 4: About Xnet
Codec such as H.264, MJPEG. XNET provides stable real-time surveillance by real time video/ audio at 1080P level, local storage for any network problems, and hybrid IP technology that can be used with existing analog CCTV devices. -
Page 5: About The Product
Adaptor and Power Cable Video Cable 2.2 Product Information Install CD XNET (IXC2050IR) IP-Installer Viewer Program (XNET-NVR) A PC software that monitors and Network Weatherproof assigns an IP address to the XNET records Video signal from the XNET Camera product device 5/20... -
Page 6: Hardware
XNET Network Weatherproof Camera Installation Guide 2.3 Hardware 2.3.1 Hardware Designation Complete System ① MegaPixel Fixed Lens ② IR Illuminator : automatically illuminates depending on the light intensity ③ CDS Sensor ④ Screws (front-4EA & rear-4EA) : Sets the front and back cap ⑤... -
Page 7: Camera Module - Bottom
Red when 12V DC power is connected. ⑤ ACT LED : Lights up Green when the XNET is connected to 100Mbps LAN. Will not light up at 10Mbps LAN. This will also blink green when there is a network collision. -
Page 8: Cable Connection
XNET Network Weatherproof Camera Installation Guide 2.3.3 Cable Connection Power Input Use the cable adapter in the package to connect power. Please use the accessory power supply provided in the package. (DC12V/2A) Analog Video Output Use this output for immediate monitoring of the video during installation. -
Page 9: Connecting To Alarm Devices
XNET Network Weatherproof Camera Installation Guide 2.3.4 Connecting to Alarm Devices Alarm Input Wires from various sensor type (IR, heat, and magnetic) can be connected to Alarm in(+)/(-) terminal as shown in figure 2.5. (NC or NO of sensor input can be selected at Menu screen.) Alarm Sensor device requires a separate power source. -
Page 10: Software Installation
XNET Network Weatherproof Camera Installation Guide 3. Software Installation This section provides brief guidelines to install the XNET quickly and to monitor XNET’s Video and Audio signals easily. If you have questions about details not explained in this section or if the product is not functioning as described, please refer to FAQ before contacting the store. - Page 11 3.1.2 Installing XNET Connect XNET to PC directly User can monitor and configure XNET camera by connecting it to your PC directly. A. Connect XNET camera to your PC directly using a LAN cable like below. COMPUTER Crossover Network Cable NOTE: XNET camera’s IP address will be automatically set to the default...
- Page 12 XNET Network Weatherproof Camera Installation Guide C. Please insert the Setup CD into your CD-ROM drive, and then please setup IPInstaller program D. Please click ‘Next’ button when the Setup screen appear. E. Please click ‘Install’ button to begin the Installation.
- Page 13 XNET Network Weatherproof Camera Installation Guide G. XNET IP Installer program is automatically launched like below right after the program installation. Please double click XNET camera on the list. H. XNET camera is successfully connected to your PC. (Internet Explorer will prompt you to install ActiveX. In order to view video, you must accept the ActiveX download.
- Page 14 XNET Network Weatherproof Camera Installation Guide Connect XNET with a router Please connect XNET camera and PC to a router using LAN cables like below. COMPUTER Direct Network Cable NOTE : If DHCP server is enabled at your router, XNET camera automatically receives an IP address from your router.
-
Page 15: Installing Xnet
XNET Network Weatherproof Camera Installation Guide 3.2. Installing IP-Installer Software and Configuring IP address 3.2.1. About IP-Installer A unique IP address has to be configured in order to connect IP camera and monitoring PC to a network. IP-Installer software provided in the Installation CD (included in the package and also available to download from our website http://www.cnbtec.com) will configure IP address easily. - Page 16 XNET Network Weatherproof Camera Installation Guide Select the camera you wish to configure and click (Set IP Address) button to open the box shown in Figure 3-2. Figure 3-2. Set IP Address box C. When you enter the IP address and click Set button, the box shown in Figure 3-3 will appear.
-
Page 17: Using Web Viewer
XNET Network Weatherproof Camera Installation Guide 4. Using Web Viewer Connecting to network devices can be done using internet web browser or “XNET-CMS” software. This guide explains about using internet web browser only. For instructions on how to configure network connection using XNET-CMS software, please refer to XNET-CMS Manual, which can be found in the installation CD. -
Page 18: Web Viewer Page
The image is saved as jpeg file in the following folder: C:₩xNetCapture Brings up Menu screen. Setting Setup page for each XNET feature can be opened from this Menu screen. Please refer to [XNET Owner’s Manual] for detail. Main Stream When this box is checked, Main Stream Video is displayed. -
Page 19: Specifications
XNET Network Weatherproof Camera Installation Guide 5. Specifications Specifications IXC2050IR Signal System Progressive image processing Scanning System 16:9 Progressive Pixel Clock 80MHz Image Sensor 1/3" Progressive CMOS Sensor Sync. System Internal Effective Pixels Number 1920 (H) x 1080(V) 2.0 Mega... - Page 20 XNET Network Weatherproof Camera Installation Guide Dimensions(mm) The casing, parts, and specifications of this product are subject to change without prior notice for improvements. 20/20...
