- Page 1 Ver. 1.0 XNET Network Box Camera (IGP1000F) Installation Manual...
-
Page 2: Important Notices
About this Installation Manual A compatibility and durability test ensured this product’s high performance. This installation manual is for XNET Network Box Camera users only, and it describes operations related to XNET Network Box Camera. Please read this manual thoroughly paying attention to cautions and warnings before using the product even if you have used similar products before. -
Page 3: Table Of Contents
2.3.2. Rear View ........................... 7 2.3.3 Connecting to Alarm devices ....................... 9 3 . Software Installation ..................... 10 3.1. Connecting XNET to network ....................10 3.2. Installing IP-Installer Software and Configuring IP address ..........11 3.2.1. About IP-Installer ........................11 3.2.2. -
Page 4: About Xnet
Codec such as MJPEG, MPEG-4, and H.264. XNET provides stable real-time surveillance by real time video/ audio at SXGA level, local storage for any network problems, and hybrid IP technology that can be used with existing analog CCTV devices. -
Page 5: About The Product
XNET Network Box Camera Installation Manual 2. About the Product Please make sure the following contents are included when you open the package Contents Description Additional info. XNET product Network Box Camera (Lens not included) Auto Iris Lens Plug Connection plug for Auto-Iris control signal... -
Page 6: Functions And Designations
XNET Network Box Camera Installation Manual Mounting Screw Hole Auto Iris control plug 1/4”. 20 UNC(20 THREAD) L : 4.5mm +-0.2mm (ISO standard) or 0.197” (ASA standard) CS Ring Fix Screw Lens(Sold Separately) CS Ring Please ask at the store about purchasing lens separately. -
Page 7: Rear View
XNET Network Box Camera Installation Manual RS-485 and alarm Input/ Output Analog video Output Power Input Factory Reset Button for 12 VDC Recalls initial factory settings POWER LED Network Terminal Event LED Mic / audio Input Audio Output SD CARD Slot Figure 2-2. - Page 8 When optional PoE is used, the power will be supplied from the Network Cable. LINK : Yellow light indicates that he network is properly connected. ACT : Green light indicates that the XNET system connected to 100Mbps LAN. This green lamp will blink if the system receives data.
-
Page 9: Connecting To Alarm Devices
XNET Network Box Camera Installation Manual Alarm Input Wires from various sensor type (IR, heat, and magnetic) can be connected to Alarm in(+)/(-) terminal as shown in figure 2.5. (NC or NO of sensor input can be selected at Menu screen.) Alarm Sensor device requires a separate power source. -
Page 10: Software Installation
3. Software Installation This section provides brief guidelines to install the XNET software quickly and to monitor XNET’s Video and Audio signals easily. If you have questions about details not explained in this section or if the product is not functioning as described, please refer to FAQ before contacting the store. -
Page 11: Installing Ip-Installer Software And Configuring Ip Address
XNET Network Box Camera Installation Manual A unique IP address has to be configured in order to connect network camera and monitoring PC to a network. IP-Installer software provided in the Installation CD (included in the package and also available to download from our website http://www.cnbtec.com) will configure IP address easily. - Page 12 XNET Network Box Camera Installation Manual 2. Select the camera of which you wish to change the IP address and click (Set IP Address) button to bring up the following box in Figure 3-3. Figure 3-3. IP Address box 3. When you enter the IP address and click Set button, the box shown in Figure 3-4 will appear.
-
Page 13: Using Web Viewer
XNET Network Box Camera Installation Manual 4. Using Web Viewer Connecting to network devices can be done using internet web browser or “XNET-CMS” software. This manual explains about using internet web browser only. For instructions on how to configure network connection using XNET-CMS software, please refer to XNET-CMS Manual, which can be found in the installation CD. - Page 14 XNET Network Box Camera Installation Manual Enter the user name and password to bring up the web viewer page. The default id and password is “root”, “admin” respectively. If you want to use a different HTTP port number from the default value, simply put a colon and port number at the end of the IP address.
-
Page 15: Web Viewer Page
XNET Network Box Camera Installation Manual Web viewer page consists of Video monitor screen and menu option buttons. Figure 4-2. Web Viewer Page 15 / 18... - Page 16 Capture The image is saved as jpeg file in the following folder: C:₩xNetCapture Brings up Menu screen. Setup page for each XNET feature can be opened from this Menu screen. Setting Please refer to [XNET Owner’s Manual] for detail. Opens up PTZ page.
-
Page 17: Specifications
Local storage (Internal memory or SD card memory : JPEG image) Browser Internet Explorer 6.0 or later Web Viewer (Window Web Browser Base) Applications Live view for up to 10 user clients Monitoring Application Video Snapshot to file (JPEG) XNET NVR, CNB CMS and Utility (IP-Installer, etc) 17 / 18... - Page 18 XNET Network Box Camera Installation Manual System Upgrade Firmware upgrade over HTTP Maintenance PTZ control (RS-485) PTZ Protocol Service (User define update) Operating Temperature -10℃ ~ 40℃ Mechanical Power DC 12V Max. 5 W Dimensions 128.7(D) x 72(W) x 64(H)mm...
