Network Weatherproof Camera Installation Manual About this Installation Guide This product has been tested for compatibility and stability as per high performance standard. This installation guide covers the installation and operation of Network weatherproof Camera only. Please read this manual including the important cautions and warnings thoroughly before using the product even if you are an expert.
Network Weatherproof Camera Installation Manual Index 1. About the product......................... 4 1.1. Features of the product ....................4 1.2. Applications ........................4 2. Product Description ....................... 5 2.1. Contents ........................5 2.2. Product Information ....................... 5 2.3. Hardware Designation ....................6 2.3.1.
Network Weatherproof Camera Installation Manual 1. About the product This Product is an internet based security and surveillance system that is compatible with various networks with its easy installation, various user interfaces, and multi-functional compressor Codec such as H.264 and MJPEG.
2. Product Description Please make sure the following contents are included in the package Contents Description Additional info. Product NXE3055MR INPUT : 100~240VAC 50-60Hz POWER ADAPTOR AC Power Cable OUTPUT : 12VDC 2A / AC24V 2.5A 2 Jack Power Cable for Outlet...
Network Weatherproof Camera Installation Manual 1. Motorize Lens : 3-9mm Motorize Lens 2. IR LED : IR Led light controlled by CDS Sensor. 3. CDS Sensor : senses the light intensity (low light level). 4. Casing Screws (front - 4EA) : attach the front and rear bodies together 5.
Network Weatherproof Camera Installation Manual 1. Micro SD Card Slot : Video images can be stored into a Micro SD card when an event occurs. Please use less than 16 GB MICRO SD Memory. Figure 2-3. MICRO SD CARD 2. Video Out: Analog Video output. When installing the camera, use this output to connect a CCTV monitor to quickly check for desired image.
Network Weatherproof Camera Installation Manual INPUT, OUTPUT Alarm Connection These wires connect to Alarm input/output devices. Alarm Sensor Input: Connect to an Alarm sensor device such as an IR Sensor or a Heat sensor. The operation of this input can be configured to either normally close or normally open.
Page 9
Network Weatherproof Camera Installation Manual Audio Connection MIC/Line Input (Mono) RED Connect this wire to the Audio input. The audio input can come from a microphone or an Audio device. Line Output (Mono) WHITE This is an Audio signal output to a Power Amplified device or a Speaker. In two way audio communication using the camera, this can be used to listen to the audio from a remote PC.
Network Weatherproof Camera Installation Manual Alarm Input Various alarm sensor types (IR, heat, magnetic, etc.) can be connected to Alarm input (+)/(-) terminal as shown in figure 2.5. (NC or NO can be configured in Menu.) Please note that the Alarm Sensor device requires a separate power source. Signal(+5 ~ 30VDC) Alarm in(+) Sensor...
Network Weatherproof Camera Installation Manual Sunvisor Install Sunvisor to the Camera’s main body using Sunvisor washers, and screws. Mounting the Camera Ceiling Mount type Wall Mount Type Mount the Bracket Base on the installation surface using the four 6mm screws provided. Mount the camera’s main body on the Bracket Base using the four 5/16”...
Page 12
Network Weatherproof Camera Installation Manual Adjusting the Camera Angle Ceiling Mount type Wall Mount Type After mounting the Camera, unlock the fixing screws shown in the picture using the L wrench provided to adjust the camera’s angle as desired. Tighten the fixing screws back when done. 12 / 23...
Network Weatherproof Camera Installation Manual 3. Software Installation This is a quick installation guide for IP Installer software. IP Installer software helps you monitor the camera’s Video and Audio in an easy user interface. If you have questions about details not explained in this section or if the product is not functioning as described, please contact the manufacturer.
Page 14
Network Weatherproof Camera Installation Manual NOTE: IP address of the PC can be set in anywhere between 192.168.123.2 and 192.168.123.254 except for 192.168.123.100, which is taken by the camera. C. Insert the Setup CD into your CD-ROM drive, and install IPInstaller software.
Page 15
Network Weatherproof Camera Installation Manual F. Click ‘Finish’ to complete the installation. G. IP Installer will launch automatically as shown below. Double click on the camera from the list. 15 / 23...
Page 16
Network Weatherproof Camera Installation Manual H. When the camera is successfully connected to your PC, you’ll see the camera’s IP address on the IP installer software. (Internet Explorer will prompt you to install ActiveX. Please accept the ActiveX download in order to view video. ) NOTE: Click on Setting in the main screen to change the configurations of the camera.
Page 17
Network Weatherproof Camera Installation Manual Connecting the Camera to a router camera can be connected to the router of an existing LAN. Please connect the camera to a router using a LAN cable as shown below: NETWORK HUB COMPUTER Direct Network Cable NOTE:...
Network Weatherproof Camera Installation Manual In order to have the camera viewable on the network, an IP address has to be assigned first. A software called IP-Installer (provided in the Installation CD) will help you assign the IP address easily. If your network uses a DHCP server, the server will automatically assign an IP addresses to the camera.
Page 19
Network Weatherproof Camera Installation Manual C. When you enter the IP address and click Set button, the box shown in Figure 3-4 will appear. Figure 3-3. Select Network Adapter Box D. Select the adapter and click Select button to complete changing the IP address of the camera. 19 / 23...
Network Weatherproof Camera Installation Manual 4. Using Web Viewer You can connect to the camera using your internet browser or a software called “CMS”. This section covers the connection through your web browser only. For instructions on how to configure the network connection using the CMS software, please refer to the manual for the...
Network Weatherproof Camera Installation Manual Web viewer page contains a Video monitor screen and menu option buttons. Figure 4-2. Web Viewer Page Item Sub Item Description Captures and saves the current image as a still picture. Capture The image is saved as jpeg file in the following folder: C:\NBRDCapture Brings up Menu screen in which all camera features can be configured.
Network Weatherproof Camera Installation Manual 5. Specification NXE3055MR Specifications Camera Signal System Progressive Image processing Scanning System 16:9 Progressive Image Sensor Progressive CMOS Sensor Sync. System Internal Effective Pixel Number 1920(H)x1080(V) Video Output Level Select NTSC/PAL 1.0Vp.p (BNC 75, composite) Lens Built-in DC Iris Motorize Lens, f=3.0~9.0mm, F 1.2...
Page 23
Network Weatherproof Camera Installation Manual Maintenance System Upgrade Firmware upgrade over HTTP Mechanical IP Class IP66 Operating -20℃ ~ 50℃/ 0% ~ 80% Temperature/Humidity Pan/Tilt/Horizontal 4-Axis Movement for Free Lens Rotation 24VAC(24~28V)/12VDC(11~15V) Dual Voltage Power Maximum IR on(FAN on) DC12V : 6.0W / AC24V :500mA Maximum IR on(HEATER on) DC12V : 8.0W / AC24V : 670mA Dimensions / Weight(Net) 109.4(W) x 122.7(H) x 343.1(D)mm / Approx.
