XNET IGC2050F Install Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
X
N
E
T
N
e
t
w
o
r
k
B
o
X
N
E
T
N
e
t
w
o
r
k
B
o
XNET Network Box Camera ( IGC2050F )
x
C
a
m
e
r
a
I
n
s
t
a
l
l
G
x
C
a
m
e
r
a
I
n
s
t
a
l
l
Install Guide
u
i
d
e
G
u
i
d
e
Ver. 1.0 (101130)
1 / 17

Advertisement

Table of Contents
loading

Related Manuals for XNET IGC2050F

Summary of Contents for XNET IGC2050F

  • Page 1 XNET Network Box Camera ( IGC2050F ) Install Guide Ver. 1.0 (101130) 1 / 17...

  • Page 2: About This Manual

    About this Manual A compatibility and durability test ensured this product’s high performance. This installation guide is for XNET Network Box Camera users only, and it describes operations related to XNET Network Box Camera. Please read this manual thoroughly paying attention to cautions and warnings before using the product even if you have used similar products before.

  • Page 3: Table Of Contents

    2.3.2. Rear View ........................7 2.3.3 Connecting to Alarm devices ..................9 3 . Software Installation ........................10 3.1. Connecting XNET to network ....................10 3.2. Installing IP-Installer Software and Configuring IP address ..........11 3.2.1. About IP-Installer ..................... 11 3.2.2.

  • Page 4: About Xnet

    Codec such as MJPEG and H.264. XNET provides stable real-time surveillance by real time video/ audio at 1080P level, local storage for any network problems, and hybrid IP technology that can be used with existing analog CCTV devices.

  • Page 5: About The Product

    Power Jack Software and User’s manual Install CD XNET (IGC2050F) IP-Installer Viewer Program (XNET-NVR) A software that monitors and records Network Camera (Lens not A software that assigns an IP Audio and Video signal from the included) address to the product...

  • Page 6: Functions And Designations

    Auto Iris control plug Mounting Screw Hole 1/4”. 20 UNC(20 THREAD) L : 4.5mm +-0.2mm (ISO standard) or 0.197” (ASA standard) CS Ring Fix Screw C Ring Attach both C Ring and CS Ring to use C-mount Lens Lens(Sold Separately) CS Ring Attach CS Ring only to use Please ask at the store about purchasing lens separately.

  • Page 7: Rear View

    STATUS LED Factory Reset Power LED Figure 2-2 Network Camera Front / Rear view STATUS LED : Indicate the status of the product EVENT LED : If the alarm out is operating, the green LED blinks. SYSTEM LED : The system operates normally when the blue LED blinks MIC : Have built-in microphone.
  • Page 8 When optional PoE is used, the power will be supplied from the Network Cable. LINK : Yellow light indicates that he network is properly connected. ACT : Green light indicates that the XNET system connected to 100Mbps LAN. This green lamp will blink if the system receives data.

  • Page 9: Connecting To Alarm Devices

    Alarm Input Wires from various sensor type (IR, heat, and magnetic) can be connected to Alarm in(+)/(-) terminal as shown in figure 2.5. (NC or NO of sensor input can be selected at Menu screen.) Alarm Sensor device requires a separate power source. Figure 2-5.

  • Page 10: Software Installation

    3. Software Installation This section provides brief guidelines to install the XNET software quickly and to monitor XNET’s Video and Audio signals easily. If you have questions about details not explained in this section or if the product is not functioning as described, please refer to FAQ before contacting the store.

  • Page 11: Installing Ip-Installer Software And Configuring Ip Address

    A unique IP address has to be configured in order to connect network camera and monitoring PC to a network. IP-Installer software provided in the Installation CD (included in the package and also available to download from our website http://www.cnbtec.com) will configure IP address easily. If your network have a DHCP server that automatically assigns IP addresses to network cameras.
  • Page 12 B. Select the camera of which you wish to change the IP address and click (Set IP Address) button to bring up the following box in Figure 3-2. Figure 3-2. IP Address box C. When you enter the IP address and click Set button, the box shown in Figure 3-3 will appear. Figure 3-3.

  • Page 13: Using Web Viewer

    4. Using Web Viewer Connecting to network devices can be done using internet web browser or “XNET-CMS” software. This guide explains about using internet web browser only. For instructions on how to configure network connection using XNET-CMS software, please refer to XNET-CMS Manual, which can be found in the installation CD.

  • Page 14: Web Viewer Page

    Web viewer page consists of Video monitor screen and menu option buttons. Figure 4-2 Web Viewer Page 14 / 17...
  • Page 15 Capture The image is saved as jpeg file in the following folder: C:₩xNetCapture Brings up Menu screen. Setup page for each XNET feature can be opened from this Menu screen. Setting Please refer to [XNET Owner’s Manual] for detail. Opens up PTZ page.

  • Page 16: Specifications

    Internet Explorer Ver. 6.0 or later Applications Web Viewer(Window Web Browser Base), Live view for up to 10 user clients Video Snapshot to file (JPEG) Monitoring Applications XNET NVR, CNB CMS and Utility(IP-Installer, etc) System Upgrade Firmware upgrade over HTTP Maintenance PTZ Control (RS-485)
  • Page 17 17 / 17...
