XNET Network Box Camera User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XNET Network Box Camera User's Guide
XNET Network Box Camera
User's Guide
Ver. 1.0 (070918)
1 of 47

Advertisement

Table of Contents
loading

Related Manuals for XNET Network Box Camera

Summary of Contents for XNET Network Box Camera

  • Page 1 XNET Network Box Camera User’s Guide XNET Network Box Camera User’s Guide Ver. 1.0 (070918) 1 of 47...
  • Page 2 XNET Network Box Camera User’s Guide Directions This product is designed for indoor use only. When using this camera at outdoors or in an environment that exceeds the limited range, you must separately use a water-resistant case. Be careful not to cause any physical damage by dropping or throwing the unit. Especially keep the device out of reach from children.

  • Page 3: Table Of Contents

    2.3. Physical Description ......................... 6 2.4. PC Requirements ........................9 2.5 Quick Installation Guide ......................9 3. Connecting XNET/XNET-Wireless to the Network ................12 3.1. Connecting to LAN ......................... 12 3.2. Connecting to xDSL/Cable Modem ................... 13 4. IP-Installer ............................. 14 4.1.

  • Page 4: Introduction

    IP connection over internet or intranet. Unlike other CCTVs or DVRs, the XNET is easy to install and user will experience cost and space savings in the installation.

  • Page 5: Product Description

    XNET Network Box Camera User’s Guide government facilities, military, etc.) Real time Internet broadcasting  Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)  Teleconference (Bi-directional audio conference)  Remote Learning  Weather and environmental observation  2. Product Description 2.1.

  • Page 6: Physical Description

    Lens: XNET/XNET-Wireless basically delivered without Lens assembly. Standard C or CS type  lens can be accommodated into XNET/XNET-Wireless. Either DC Iris lens or Non-DC Iris lens can be used with XNET/XNET-Wireless. Auto-Iris Control: Plug in the cable from standard DC-Iris lens.
  • Page 7 XNET Network Box Camera User’s Guide 2.3.2. Rear panel RS232C & Analog Video Out Status LED Link LED RS485 & Reset Button Alarm Input / Output Figure 2-3. Rear Views of XNET/XNET-Wireless  MIC /LINE IN: Connect external audio source or microphone. Use a standard stereo...
  • Page 8 - Status LED: Green color indicates that the camera is in normal operation mode, while red color indicates that the camera is in abnormal condition. When connecting a power source to the XNET, the status LED will be lit red for a second and then it will change to green.

  • Page 9: Pc Requirements

    Connector for connecting 3dBi antenna supplied with XNET-Wireless 2.4. PC Requirements AV streaming data received from XNET/XNET-Wireless can be decoded or stored in a PC running XNET-NVR program which is a viewing & recording program for a PC. Minimum requirement of the PC is described below:...
  • Page 10 XNET Figure 2-6. Connecting Network camera and PC using AC Adaptor The XNET Series does not support standard PoE. Do not connect the network camera directly to a hub supporting standard PoE. We assume no responsibility for the damages caused by use of standard PoE device with this product.
  • Page 11 Setup memorize these values. Default value : Current Time Input correct time in this field. 2001/1/1 ⑤ Connect the input and output signals to XNET/XNET-Wireless Connectors Function Signal description Number LINE- Connect microphone or output from audio...

  • Page 12: Connecting Xnet/Xnet-Wireless To The Network

    In case of connecting the XNET/XNET-Wireless to LAN, it is generally connected as in Figure 3-1. IP Network (LAN/WAN) Router Client PC Client PC XNET Figure 3-1. Connecting the XNET to LAN 1) Follow through steps ① to ③ in Section 2.5 to assign IP address to XNET/XNET- 12 of 47...

  • Page 13: Connecting To Xdsl/Cable Modem

    3.2. Connecting to xDSL/Cable Modem 1) Follow through steps ① to ③ in Section 2.5 to assign IP address and other network parameters to XNET/XNET-Wireless. 2) Install XNET/XNET-Wireless and connect it to xDSL or Cable modem as in Figure 3-2. IP Network (LAN/WAN)

  • Page 14: Ip-Installer

    IP environment, you have to assign the e-mail address when user name and password are input using IP-installer. When connecting XNET/XNET-Wireless to xDSL or Cable modem, usually a straight LAN cable is required. But since some modems have crossover connections, in this case, you should use a crossover LAN cable.

  • Page 15: Configuring Xnet In Administrative Mode

    There are two ways of connecting to XNET/XNET-Wireless administrative mode. One is through Internet Explorer (IE) and the other is through “XNET-NVR” or “XNET-XNVR” program. But this user‟s guide will explain accessing by IE and “XNET-NVR” only. (Please refer to the XNVR user‟s guide in the supplied CD for using “XNET-XNVR”.) 5.1.1.
  • Page 16 XNET Network Box Camera User’s Guide 5.1.3. Input User Name and Password After fallowing the method which explained in Section 5.1.1. or 5.1.2, the login screen will open. Input the User Name and Password in the login screen shown in Figure 5-2.

  • Page 17: Basic Setup

    Select a language of your choice. English, Korean, Chinese, Language Japanese, Spanish, Italian, Portuguese are available. Logical name of the XNET. It is same as the one set-up by IP- System Name installer. You can reassign the system name. Save a image file captured from the web viewer to the folder of Screen Capture your choice.
  • Page 18 XNET Network Box Camera User’s Guide Select the type of input audio. Audio Input Select Line In for using Line-out from audio devices.  Selection Select Mic for using microphone.  Input Video This filed is set by the factory...

  • Page 19: Network Configuration

    XNET Network Box Camera User’s Guide 5.3. Network Configuration Setup the network parameters appropriately in accordance with your network environment. Many of the parameters in this page are same as those set up by “IP-Installer”. Figure 5-4. Network Configuration 19 of 47...
  • Page 20 Sub Field Field/Button Description /Button The network types supported by the XNET/XNET-Wireless are LAN(fixed IP), PPPoE, and DHCP(automatic IP allocation) When the network environment is fixed IP, select „LAN‟ in the network type, and put the IP address, Subnet Mask, Static IP Gateway, DNS1 and DNS2.
  • Page 21 XNET Network Box Camera User’s Guide address set by “Recv E-Mail Address”. Recv E-Mail Enter E-mail address to receive information sent from your Address network camera. This is same as E-mail field in IP-installer. Return E-Mail Fill in this field with correct e-mail address to identify the...

  • Page 22: Wireless Configuration(Xnet-Wireless Only)

    XNET Network Box Camera User’s Guide 5.4. Wireless Configuration (XNET-Wireless Only) For the case of a network camera having built in wireless LAN it is needed to set up wireless LAN configuration parameters. Click “Wireless Configuration”. Figure 5-5 Wireless Configuration...
  • Page 23 XNET Network Box Camera User’s Guide the MAC address of the access point is shown. Current Indicates the channel number of present connection. Channel Signal Indicates the strength of the received signal. Strength Link Quality Indicates the quality of Link level.

  • Page 24: Ccd Adjustment

    Field/Button Description /Button Standard XNET is delivered without lens. Any lens having C or CS mount type can be installed on XNET. A C-CS adaptor is packaged with XNET for accommodating CS type lens. Confirm whether your lens is Non DC IRIS or DC IRIS lens before your selection and then click “SAVE”...
  • Page 25 In case of using NTSC type iCanViewV230 in 50Hz AC regions or using PAL type XNET/XNET-Wireless in 60Hz AC region, video output tends to flicker when XNET/XNET- Wireless is used under fluorescent lamps. This mode reduces the flickering phenomena.

  • Page 26: User Admin & Time Setup

    XNET Network Box Camera User’s Guide 5.6. User Admin & Time Setup You can change the ID and password of users and also assign different attributes for each user. Figure 5-7. User Admin. & Time Setup Sub Field Field/Button Description...
  • Page 27  You can delete specific user by clicking the DELETE button. If you want to restrict viewing access to the XNET/XNET- Wireless, check at the box left to Yes and click on Save. Users need to input ID and password to connect to XNET/XNET-Wireless.
  • Page 28 Synchronize the time with the internet time server at the with an right. When the time server is out of the reach from Internet XNET/XNET-Wireless, you can assign time server by filling in Time Server Specific Time Server field. Synchronize Synchronize the time with the time of the PC.

  • Page 29: Sensor & Capture Setup

    Normal Open and Normal Close. Name Input logical name for the sensor. It sets the condition of video transmission via FTP or E-mail. The XNET/XNET-Wireless supports 2 types of conditions which are mutually independent. Video Capture Sensor Check to enable Sensor initiated capture.
  • Page 30 XNET Network Box Camera User’s Guide Transmission Check to send captured video by e-mail. E-mail is sent to the Recv E-mail address. Refer to [Section 5.3.] By E-Mail Captured video data for E-mail consists of intra frames only in consideration of the limited storage space for E-mail account.

  • Page 31: Alarm Device Setup

    XNET Network Box Camera User’s Guide 5.8. Alarm Device Setup Test the alarm output and describe the condition of alarm annunciation. Figure 5-10. Alarm Output Setup Sub Field Field/Button Description /Button Test alarm devices. Click on On/Off for testing. Small box with white background indicates the status of the Alarm Device relay by On/Off.

  • Page 32: Motion Region Setup

    XNET Network Box Camera User’s Guide 5.9. Motion Region Setup Set the motion detection regions. Up to 3 regions can be defined. Figure 5-11. Motion Region Setup Sub Field Field/Button Description /Button Channel Not applicable. Selection Channel Set the sensitivity in motion detection for each channel. 1 is Sensitivity the most sensitive, and 10 is the least sensitive.
  • Page 33 XNET Network Box Camera User’s Guide Set up to 3 the motion detection zone Enable each zone by checking the box at the left of each Region. To set the region: Click on START and click on a box overlaid on the video Region 1, 2, Click on END and click on a box overlaid on the video.

  • Page 34: Ptz Setup(Zoom Is Not Applicable For Xnet/Xnet-Wireless)

    Press this button to delete the setup of PT Selection Button Your PT device needs an ID, input ID in this field. PTZ Device ID Click on SAVE to save the ID. Note that zoom is not applicable for XNET 34 of 47...
  • Page 35 XNET Network Box Camera User’s Guide You can check the various operation of the PT devices. “Left”/”Right”/”UP”/”DOWN”  Operation ZIN(Zoom In), AUTOFOCUS, ZOUT(Zoom Out)  Check functions does not applicable to this product You can set up the PTZ limitation & preset positions if the PT device supports it.

  • Page 36: Encryption Set Up

    XNET Network Box Camera User’s Guide 5.11. Encryption Set up Figure 5-13. Encryption Setup For additional security to the video and audio data transmitted from the network camera, you can set key codes and use them for encrypting the data from the network camera.
  • Page 37 XNET Network Box Camera User’s Guide You can use up to 20 different key codes for the encryption of the data To generate the key value click on “GENERATE” button. The GENERATE boxes for the Key values will be filled with new values.

  • Page 38: Upgrade & Reset

    XNET Network Box Camera User’s Guide 5.12. Upgrade & Reset You can upgrade the XNET/XNET-Wireless via the IP network. Figure 5-14. Upgrade & Reset For each of the upgrade of the system component, upgrade code should be downloaded from cnbtec‟s home page before the system upgrade is performed.
  • Page 39 XNET Network Box Camera User’s Guide Refer to [6.4. How To Upgrade Your XNET/XNET- Wireless System]. Upgrade the bootloader installed in the network camera via the network. Bootloader needed for the upgrade can be Bootloader downloaded from cnbtec‟s home page.

  • Page 40: Status Report

    XNET Network Box Camera User’s Guide 5.13. Status Report It shows you system records since the system started. Figure 5-15. Status Report You can check the problems as well as the versions and event status of the whole system and each module.

  • Page 41: Tips For Using Xnet/Xnet-Wireless

    XNET Network Box Camera User’s Guide 6. Tips for using XNET/XNET-Wireless 6.1. ALARM-IN and ALARM-OUT ALARM connectors are used to connect various sensing and alerting devices. Examples of sensing devices are infrared sensors, motion sensors, heat/smoke sensors, magnetic sensor, etc.
  • Page 42 XNET Network Box Camera User’s Guide Figure 6-2. ALARM-IN circuit 6.1.2. ALARM-OUT A Relay output is provided for connecting alarm devices or for remote on/off devices such as light control. Relay circuits are normal open and circuits are closed upon alarm output or remote on.
  • Page 43 XNET Network Box Camera User’s Guide 6.1.3. Connection of Sensor, Alarm Device 6.1.3.1 Connection of Sensor Photo Coupler NO/NCType Open CollectorType Sensor1+ Sensor Sensor Device Device Sensor1- +12V Sensor Sensor Power Power Supply Supply 6.1.3.2. Connection of Relay Relay Switch Power Supply...

  • Page 44: Trouble Shooting

    Then press Enter. If you see the “Reply from …” message it means that the network is working properly. To check if the XNET/XNET-Wireless is connected, open the MS-DOS Prompt and type the following. ping [the IP of the server] Example) ping 192.168.1.112 If you see the “Reply from...

  • Page 45: Web Viewer

    6.3. Web Viewer XNET/XNET-Wireless is designed to be connected through internet explorer, too. For connection to XNET/XNET-Wireless using internet explorer type in IP address or host address in the address input field of the internet explorer. Figure 6-4. Web Viewer of XNET/XNET-Wireless...
  • Page 46 XNET Network Box Camera User’s Guide  Control Panel of Web Viewer Enable bidirectional audio. When bidirectional audio is enabled, voice from your PC is delivered to XNET/XNET-Wireless. Capture and store the still image on your desk top screen. Connect to XNET/XNET-Wireless in administrative mode of XNET/XNET-Wireless.

  • Page 47: How To Upgrade The Xnet/Xnet-Wireless

    XNET Network Box Camera User’s Guide 6.4. How to Upgrade the XNET/XNET-Wireless Unless otherwise instructed, the owners of the XNET/XNET-Wireless are recommended to upgrade the system when upgraded firmware is released using manual upgrade procedure. (The automatic upgrade mode will supported soon later.) Followings are the procedure to apply for the automatic upgrade Save the upgrade system software to your PC.
