Gardena R70Li Quick Manual

5. Starting and stopping

See chapter 4.3 and 4.4 in the Operator's Manual
Starting
1. Open the cover by pressing the STOP button.
2. Set the main switch to position 1. When you do this for the fi rst time, a start up sequence starts
where you select a four digit PIN code among other things.
3. Press the START button.
4. Close the cover.
Stopping
Press the STOP button.
6. Adjust the robotic lawnmower to suit
your garden
See chapter 6.3, 6.4 and 6.6 in the Operator's Manual
Here you will fi nd some tips on important settings for your robotic lawnmower.
All settings for your robotic lawnmower are made via the menu functions.
Adjust the mower to suit the size of your lawn
The mowing results depend on mowing time. Adjust the mowing time to suit your
garden using the Timer function. If the mower cuts too often, the lawn will appear
trampled down. If the mower cuts too seldom, the lawn will not be properly mown.
Test run the mower through narrow passages
Narrow passages in the garden make it diffi cult for the mower to fi nd the charging station.
function (Calibrate guide function for the GARDENA R40Li) to test that the mower can travel through the narrowest
passage.
1. Place the mower in the charging station.
2. Select Test Out (Calibrate guide for GARDENA R40Li) in the robotic lawnmower's menu and press OK.
press the Start button and close the cover.
3. Check that the mower follows the guide wire through the passage.
a. If the mower travels through the passage, the test is complete.
b. If the robotic lawnmower does not get through the passage: Check that the guide wire has been laid ac-
cording to the instructions in chapter 3.6 in the Operator's Manual.
It is also possible to adjust the guide width for the GARDENA R70Li. See chapter 6.4 in the Operator's Manual.
WWW.GARDENA.COM
The right to make changes without prior notice is reserved.
Copyright © 2013 GARDENA Manufacturing GmbH. All rights reserved.
www.gardena.com
115 49 66-26
1 2 3 4 5
GARDENA
Start
1 2 3
4 5 6
1
7 8 9
0
Timer
You decide what times during the day and days of the week the mower is to work.
The robotic lawnmower mows about 45 m² per hour and day (30 m² for the
GARDENA R40Li). For example; if your garden consists of 360 m² of grass, the
robotic lawnmower should work on average 8 hours per day (12 hours for the
GARDENA R40Li).
Use the Test out
Then
3
1
QUICK GUIDE
GARDENA ROBOTIC LAWNMOWER
R40Li / R70Li
