  • Page 1 INSTALLATION MANUAL INSTALLATION MANUAL GARDENA ROBOTIC LAWNMOWER GARDENA ROBOTIC LAWNMOWER R38Li, R40Li, R45Li, R50Li, R70Li, R80Li OMSLAG QG, BRUX, 1155943-.indd 2 2014-10-17 10.29...

  • Page 3: Table Of Contents

    1157069-26,R40Li_GB.book Page 3 Wednesday, November 19, 2014 5:02 PM TABLE OF CONTENTS Introduction and safety ........... 5 Introduction ................ 5 Symbols on the product ............. 6 Symbols in the Operator’s Manual ........7 Safety Instructions ............8 Presentation ..............11 What is what? ..............
  • Page 4 PIN code. The product registration key is provided in a separate document in the product packaging. If the robotic lawnmower is stolen, it is important to notify GARDENA of this. Contact GARDENA Central Service and provide the robotic lawnmower's serial number and product registration key so that it can be registered as stolen in an international database.

  • Page 5: Introduction And Safety

    As a complement to this Operator's Manual, there is more information available on GARDENA's website, www.gardena.com. Here you can find more help and guidance in the use of the robotic lawnmower. The following system is used in the Operator's Manual to make it easier to use: •...

  • Page 6: Symbols On The Product

    1157069-26,R40Li_GB.book Page 6 Wednesday, November 19, 2014 5:02 PM 1. INTRODUCTION AND SAFETY 1.2 Symbols on the product These symbols can be found on the robotic lawnmower. Study them carefully. • Please read the Operator’s Manual carefully and make sure you understand the instructions before using your robotic lawnmower.

  • Page 7: Symbols In The Operator's Manual

    1157069-26,R40Li_GB.book Page 7 Wednesday, November 19, 2014 5:02 PM 1. INTRODUCTION AND SAFETY • The low voltage cable must not be shortened, extended or spliced. • Do not use a trimmer nearby the low voltage cable. Be careful when trimming edges where the cables are placed.

  • Page 8: Safety Instructions

    1157069-26,R40Li_GB.book Page 8 Wednesday, November 19, 2014 5:02 PM 1. INTRODUCTION AND SAFETY 1.4 Safety Instructions • This robotic lawnmower is designed to mow grass in open and level ground areas. It may only be used with the equipment recommended by the manufacturer.
  • Page 9 1157069-26,R40Li_GB.book Page 9 Wednesday, November 19, 2014 5:02 PM 1. INTRODUCTION AND SAFETY use. The robotic lawnmower can only start when the main switch is set to 1 and the correct PIN code has been entered. • The robotic lawnmower must never be used at the same time as a sprinkler.
  • Page 10 1157069-26,R40Li_GB.book Page 10 Wednesday, November 19, 2014 5:02 PM 1. INTRODUCTION AND SAFETY Transport The original packaging should be used when transporting the robotic lawnmower over long distances. To safely move from or within the working area: Press the STOP button to stop the robotic lawnmower.

  • Page 11: Presentation

    The loop wire supplied for the installation is 200 m long (150 m for the GARDENA R38Li, R40Li, R45Li & R50Li). If it is not long enough, more loop wire can be purchased and spliced onto the existing loop wire with an original coupler.

  • Page 12: What Is What

    1157069-26,R40Li_GB.book Page 12 Wednesday, November 19, 2014 5:02 PM 2. PRESENTATION 2.1 What is what? 3018-169 The numbers in the illustration represent: Body 16. Loop wire for boundary loop and guide wire Cover to display, keypad and cutting height 17. Low voltage cable adjustment 18.

  • Page 13: Package Contents

    1157069-26,R40Li_GB.book Page 13 Wednesday, November 19, 2014 5:02 PM 2. PRESENTATION 2.2 Package Contents Your Gardena ® robotic mower package contains the following details. Gardena® R38Li, R40Li, Gardena® R70Li, R80Li R45Li, R50Li √ √ Robotic mower √ √ Charging station √...

  • Page 14: Function

    1157069-26,R40Li_GB.book Page 14 Wednesday, November 19, 2014 5:02 PM 2. PRESENTATION 2.3 Function Capacity The robotic lawnmower is recommended for lawn sizes up to the maximum capacity listed in the technical data section. How big an area the robotic lawnmower can keep cut depends primarily on the condition of the blades and the type, growth and moisture of the grass.
  • Page 15 1157069-26,R40Li_GB.book Page 15 Wednesday, November 19, 2014 5:02 PM 2. PRESENTATION Working method The robotic lawnmower automatically mows the lawn. It continuously alternates between mowing and charging. The robotic lawnmower starts to search for the charging station when the battery charge becomes too low.

  • Page 16: Search Method

    1157069-26,R40Li_GB.book Page 16 Wednesday, November 19, 2014 5:02 PM 2. PRESENTATION The control panel on the top of the robotic lawnmower is where you manage all the robotic lawnmower settings. Open the control panel cover by pressing down the STOP button. When the main switch is set to position 1 for the first time, a start-up sequence begins which includes Start...

  • Page 17: Installation

    1157069-26,R40Li_GB.book Page 17 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION 3. Installation This chapter describes how you install the GARDENA robotic lawnmower. Before starting the installation read the previous chapter 2. Presentation. Read also through this entire chapter before beginning the installation.

  • Page 18: Installation Of The Charging Station

    • It must be close to a wall socket The supplied low voltage cable is 10 metres long. A 20 meter low voltage cable is available to purchase as an accessory. Contact GARDENA Central Service for more information. • A level surface to place the charging station on •...
  • Page 19 1157069-26,R40Li_GB.book Page 19 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION The charging station must be positioned with a great deal of free space in front of it (at least 3 metres). It should also be centrally placed in the working area to make it easier for the robotic lawnmower to reach all areas in the working area.
  • Page 20 1157069-26,R40Li_GB.book Page 20 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION If the installation is done in a working area with a steep slope (such as around a house on a hill), the charging station should be placed in the area at the bottom of the slope.
  • Page 21 1157069-26,R40Li_GB.book Page 21 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION It is possible to let the low voltage cable cross the working area. The low voltage cable must be stapled down or buried, and the cutting height should be such that the blades on the blade disc can never come in contact with the low voltage cable.

  • Page 22: Charging The Battery

    1157069-26,R40Li_GB.book Page 22 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION Installation and connecting the charging station Position the charging station in a suitable spot. Connect the low voltage cable to the charging station. Connect the transformer’s power cable to a 100-240V wall socket.

  • Page 23: Installation Of The Boundary Wire

    1157069-26,R40Li_GB.book Page 23 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION 3.4 Installation of the boundary wire The boundary wire can be installed in one of the following ways: Securing the wire to the ground with staples. It is preferable to staple down the boundary wire if you want to make adjustments to the boundary wire during the first few weeks of operation.
  • Page 24 1157069-26,R40Li_GB.book Page 24 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION Working area boundaries If a high obstacle, for example a wall or fence, borders the working area, the boundary wire should be laid 30 cm from the obstacle. This will prevent the robotic lawnmower from colliding with the obstacle and reduce body wear.
  • Page 25 Instances of this are 25% slopes or a passage that is narrower than 60 cm (90 cm for GARDENA R38Li, 40Li, R45Li, R50Li). Lay the boundary wire then around the secondary area so that it forms an island outside of the main area.
  • Page 26 1157069-26,R40Li_GB.book Page 26 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION Passages when mowing Long and narrow passages and areas narrower than 1.5 - 2 metres should be avoided. When the robotic lawnmower mows, there is a risk that it travels around in the passage or area for a period of time.
  • Page 27 1157069-26,R40Li_GB.book Page 27 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION Laying the boundary wire If you intend to staple down the boundary wire: • Cut the grass very low with a standard lawnmower or a trimmer where the wire is to be laid.
  • Page 28 1157069-26,R40Li_GB.book Page 28 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION Laying the boundary wire in towards the charging station The boundary wire must be laid in line with the rear end of the charging station and at least 1.5 metres straight out to the right and left of the station.

  • Page 29: Connecting The Boundary Wire

    1157069-26,R40Li_GB.book Page 29 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION 3.5 Connecting the boundary wire Connect the boundary wire to the charging station: IMPORTANT INFORMATION The boundary wire must not be crossed when connecting it to the charging station. The right hand wire end must be connected to the right hand pin on the charging station and the left hand wire end to the left pin.

  • Page 30: Installation Of The Guide Wire

    1157069-26,R40Li_GB.book Page 30 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION 3.6 Installation of the guide wire The guide wire is a wire that is laid from the charging station towards, for instance, a remote part of the working area or through a narrow passage to be then connected with the boundary wire.
  • Page 31 1157069-26,R40Li_GB.book Page 31 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION Laying and connecting the guide wire Run the wire through the slot in the bottom of the charger plate. Fit the connector to the guide wire in the same way as for the boundary wire described in 3.5 Connecting the boundary wire on page 29.
  • Page 32 1157069-26,R40Li_GB.book Page 32 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION - In the passage, the guide wire must therefore be placed so that the robotic lawnmower has as much space to run in as possible. The distance Maximum between the boundary wire and the guide wire distance must however be at least 30 cm.
  • Page 33 1157069-26,R40Li_GB.book Page 33 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION Connect the guide wire to the boundary wire using a coupler: Insert the boundary wire in each of the holes in the coupler. Insert the guide wire in the centre hole in the coupler.

  • Page 34: Checking The Loop

    1157069-26,R40Li_GB.book Page 34 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION 3.7 Checking the loop Check the loop signal by inspecting the indicator lamp on the charging station. See 9.2 Indicator lamp in the charging station on page 72 if the lamp does not indicate a solid green light.

  • Page 35: Test Docking With The Charging Station

    1157069-26,R40Li_GB.book Page 35 Wednesday, November 19, 2014 5:02 PM 3. INSTALLATION 3.9 Test docking with the charging station Before using the robotic lawnmower, check that the robotic lawnmower can follow the guide wire all the way to the charging station and easily docks with the charging station.

  • Page 36: Use

    4. USE 4. Use 4.1 Charging a flat battery When the GARDENA robotic lawnmower is new or has been stored for a long period, the battery will be flat and needs to be charged before starting. Charging takes approximately 80 to 100 minutes.

  • Page 37: Using The Timer

    Example 1 The times used in this example are applicable to GARDENA R40Li, but the principle is the same for the other models. Work period 1: 07:00 - 22:00 Work days: All days The factory setting ensures that the robotic lawnmower begins cutting the lawn at 07.00.

  • Page 38: Starting

    1157069-26,R40Li_GB.book Page 38 Wednesday, November 19, 2014 5:02 PM 4. USE Example 2 The times used in this example are applicable to GARDENA R40Li, but the principle is the same for the other models. Work period 1: 06:00 - 16:00 Work period 2: 20:00 - 23:00...

  • Page 39: Switching Off

    1157069-26,R40Li_GB.book Page 39 Wednesday, November 19, 2014 5:02 PM 4. USE 4.5 Switching off Press the STOP button. Set the main switch in position 0. Always switch the robotic lawnmower off using the main switch if it requires maintenance or if the robotic lawnmower must be moved outside the working area.

  • Page 40: Control Panel

    5. CONTROL PANEL 5. Control panel All forms of commands and settings for the GARDENA robotic lawnmower are made via the control panel. All functions are accessed via a number of menus. The control panel consists of a display and a keypad.

  • Page 41: Operation Selection

    1157069-26,R40Li_GB.book Page 41 Wednesday, November 19, 2014 5:02 PM 5. CONTROL PANEL 5.1 Operation selection The operation selection button is symbolised by a house. When the button has been pressed, the selected operation mode is shown in the display. By consecutively pressing the button many times, one can choose between three different operation modes.

  • Page 42: Multi-Choice Buttons

    1157069-26,R40Li_GB.book Page 42 Wednesday, November 19, 2014 5:02 PM 5. CONTROL PANEL 5.2 Multi-choice buttons The three multi-choice buttons offer various functions, among others depending on where in the menu structure you are. The button function is shown at the very bottom of the display. Example: If you are in the main menu, the left button Start can be used to go back, the middle button confirms...

  • Page 43: Menu Functions

    1157069-26,R40Li_GB.book Page 43 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS 6. Menu functions 6.1 Main menu The main menu for the GARDENA R38Li, R40Li, R45Li, R50Li offers three options: • Timer • Security • Settings Start The main menu for the GARDENA R70Li /R80Li offers four options: •...

  • Page 44: Menu Structure

    1157069-26,R40Li_GB.book Page 44 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS 6.2 Menu structure GARDENA R38Li, R40Li, R45Li, R50Li 44 - English...
  • Page 45 1157069-26,R40Li_GB.book Page 45 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS GARDENA R70Li, R80Li English - 45...

  • Page 46: Timer

    Settings the garden. The factory setting is 07:00 - 23:00 (07:00-22:00 for GARDENA R38Li, R40Li, R45Li, R50Li) and it allows mowing every day of the week. This setting is suitable for the listed maximum working area. When setting the timer, calculate that the robotic...
  • Page 47 1157069-26,R40Li_GB.book Page 47 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS This table goes for GARDENA R40Li Work area Work days per week Work hours per day Suggested time time interval 4,5h 07:00 - 11:30 100 m 3,5h 07:00 - 10:30...
  • Page 48 1157069-26,R40Li_GB.book Page 48 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS This table goes for GARDENA R70Li Work area Work days per week Work hours per day Suggested time time interval 05:00 - 08:00 100 m 2,5h 05:00 - 07:30...

  • Page 49: Installation, R70Li, R80Li

    The robotic lawnmower has an inbuilt standby period of about 8 hours a day (11 hours for the GARDENA R40Li). The robotic lawnmower is parked in the charging station during this period. See 4.2 Using the timer on page 37.
  • Page 50 1157069-26,R40Li_GB.book Page 50 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS Wide In a wide corridor, the robotic lawnmower mows at more varied distances from the guide wire. A garden that is open and free of narrow passages should have a wide corridor to minimise the risk of tracks forming.
  • Page 51 1157069-26,R40Li_GB.book Page 51 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS • Proportion Never How often the robotic lawnmower must follow the guide wire from the charging station is selected Rarely as a proportion of the total number of times it Proportion leaves the charging station.
  • Page 52 1157069-26,R40Li_GB.book Page 52 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS Test settings In the Test settings menu, it is possible to test the Guide width settings for Remote start 1 and Remote start 2 and that the selected Guide width works in the working area in question.

  • Page 53: Security

    1157069-26,R40Li_GB.book Page 53 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS Test IN The Test IN function allows you to test how well the robotic lawnmower docks with the charging station. Test IN can only be performed after Test OUT has been performed.
  • Page 54 1157069-26,R40Li_GB.book Page 54 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS Function Medium High Time lock PIN request Alarm IMPORTANT INFORMATION We recommend using the High security level at all times. Time lock This function means that the robotic lawnmower cannot be started after 30 days without first entering the correct PIN code.

  • Page 55: Settings

    1157069-26,R40Li_GB.book Page 55 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS 6.6 Settings About The About menu displays information about the Timer About robotic lawnmower's model, serial number and the different softwares. Installation Time & Date Security Language Country Settings Backlight Remote start...
  • Page 56 Place the cursor at the required country and press OK. Backlight, R38Li, R40Li, R45Li, R50Li To indicate where the robotic lawnmower is at night in the working area, it is possible to allow the display to remain on when the robotic lawnmower is in operation.
  • Page 57 1157069-26,R40Li_GB.book Page 57 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS Remote start, R38Li, R40Li, R45Li, R50Li One important function with the guide wire is the capacity to steer the robotic lawnmower to remote garden areas when required. This function is very...
  • Page 58 1157069-26,R40Li_GB.book Page 58 Wednesday, November 19, 2014 5:02 PM 6. MENU FUNCTIONS Calibrate guide, R38Li, R40Li, R45Li, R50Li The Calibrate guide function allows you to test if the robotic lawnmower can follow the guide wire out from the charging station.

  • Page 59: Garden Examples

    The settings only need to be adjusted when special installation conditions exist. The recommended timer settings in the following garden example are applicable to GARDENA R40Li unless otherwise stated. For other models, the operating time can be reduced, see 4.2 Using the timer on page 37.
  • Page 60 1157069-26,R40Li_GB.book Page 60 Wednesday, November 19, 2014 5:02 PM 7. GARDEN EXAMPLES Installation proposals and settings Area 400 m . A number of islands and a 25% slope. Timer 07:00-22:00 (factory setting) Monday-Sunday Remote start- Rarely (factory setting) Proportion Place the charging station in Remarks the lower part of the working area.
  • Page 61 Select Proportion Rarely as the right hand area is a small fraction of the total area. Applies to the GARDENA R70Li, R80Li only. 400 m . Three areas linked Area with two narrow passages.
  • Page 62 1157069-26,R40Li_GB.book Page 62 Wednesday, November 19, 2014 5:02 PM 7. GARDEN EXAMPLES Installation proposals and settings Area 200 m + 50 m in a secondary area. Timer 07:00-18:00 Monday, Tuesday, Thursday, Friday Remote start - Rarely (factory setting) Proportion The secondary area is cut Remarks using the MAN mode on Wednesday and Saturday.

  • Page 63: Maintenance

    1157069-26,R40Li_GB.book Page 63 Wednesday, November 19, 2014 5:02 PM 8. MAINTENANCE 8. Maintenance Check and clean the robotic lawnmower regularly and replace worn parts if necessary to improve operating reliability and to ensure a longer service life. For further information on cleaning, see 8.3 Cleaning. When the robotic lawnmower is first used, the blade disc and blades should be inspected once a week.

  • Page 64: Winter Storage

    1157069-26,R40Li_GB.book Page 64 Wednesday, November 19, 2014 5:02 PM 8. MAINTENANCE 8.1 Winter storage Robotic lawnmower The robotic lawnmower must be cleaned carefully before putting it away for the winter. See 8.3 Cleaning on page 65. To guarantee battery functionality and service life, it is very important to fully charge the robotic lawnmower before storing it away for the winter.

  • Page 65: Cleaning

    1157069-26,R40Li_GB.book Page 65 Wednesday, November 19, 2014 5:02 PM 8. MAINTENANCE 8.3 Cleaning It is important to keep the robotic lawnmower clean. A mower with large amounts of grass stuck to it will not cope as well with slopes. It is recommended to clean using a brush.

  • Page 66: Transport And Removal

    1157069-26,R40Li_GB.book Page 66 Wednesday, November 19, 2014 5:02 PM 8. MAINTENANCE Body Use a damp, soft sponge or cloth to clean the body. If the body is very dirty it may be necessary to use a soap solution or washing-up liquid. Charging station Clean the charging station regularly from grass, leaves, twigs and other objects that may impede...

  • Page 67: Replacing The Blades

    All three blades and screws must be replaced at the same time to obtain a balanced mowing system. Use GARDENA approved original blades only. To replace the blades: Set the main switch in position 0.
  • Page 68 1157069-26,R40Li_GB.book Page 68 Wednesday, November 19, 2014 5:02 PM 8. MAINTENANCE IMPORTANT INFORMATION Fully charge the battery at the end of the season before winter storage. Replacing the battery If the operating times for the robotic lawnmower are shorter than normal between charges, this indicates that the battery is getting old and eventually needs replacing.

  • Page 69: Troubleshooting

    More suggestions for steps to take in the event of malfunction or symptoms can be found on www.gardena.com. 9.1 Messages Below a number of messages are listed which may be shown in the display of the robotic lawnmower. Contact GARDENA Central Service if the same message appears often. See Memo on page 4. Message Cause Action...
  • Page 70 Wrong PIN Wrong PIN code has been entered. Enter the correct PIN code. Contact Five attempts are permitted, and the GARDENA Central Service if you keypad is then blocked for five forget the PIN code. See Memo on minutes. page 4.
  • Page 71 1157069-26,R40Li_GB.book Page 71 Wednesday, November 19, 2014 5:02 PM 9. TROUBLESHOOTING Message Cause Action Right wheel The robotic lawnmower has got Free the robotic lawnmower and overloaded caught in something. rectify the reason for the lack of drive. If it is due to wet grass, wait until the Left wheel overloaded lawn has dried before using the robotic lawnmower.

  • Page 72: Indicator Lamp In The Charging Station

    For a fully functional installation, the indicator lamp in the charging station must emit a solid green light. If something else appears, follow the troubleshooting guide below. There is more troubleshooting help on www.gardena.com. If you still need help with troubleshooting, please contact GARDENA Central Service. See Memo on page 4.

  • Page 73: Symptoms

    If your robotic lawnmower does not work as expected, follow the troubleshooting guide below. There is a FAQ (Frequently Asked Questions) on www.gardena.com which provides more detailed answers to a number of standard questions. Contact GARDENA Central Service if you still cannot find the reason for the fault. See Memo on page 4.
  • Page 74 1157069-26,R40Li_GB.book Page 74 Wednesday, November 19, 2014 5:02 PM 9. TROUBLESHOOTING Symptom Cause Action The robotic The robotic lawnmower clock needs Set the clock. See 6.6 Settings on lawnmower runs at to be set. page 54. the wrong time The start and stop times for mowing Reset the start time and stop time are incorrect.

  • Page 75: Finding Breaks In The Loop Wire

    1157069-26,R40Li_GB.book Page 75 Wednesday, November 19, 2014 5:02 PM 9. TROUBLESHOOTING 9.4 Finding breaks in the loop wire Breaks in the loop wire are usually the result of unconscious physical damage to the wire such as when gardening with a shovel. In countries with ground frost, even sharp stones that move in the ground can damage the wire.
  • Page 76 1157069-26,R40Li_GB.book Page 76 Wednesday, November 19, 2014 5:02 PM 9. TROUBLESHOOTING Connect the charging station to the power supply. Switch the connections between the guide wire and the boundary wire in the charging station. a) Switch connection AL and Guide. If the indicator lamp flashes yellow, then the break is somewhere on the boundary wire between AL and the point where the guide wire...
  • Page 77 1157069-26,R40Li_GB.book Page 77 Wednesday, November 19, 2014 5:02 PM 9. TROUBLESHOOTING a) Assume that the indicator lamp flashed yellow in test a) above. Reset all connections to their original positions. Then disconnect AR. Connect a new loop wire to AR. Connect the other end of this new loop wire somewhere at the centre of the installation.
  • Page 78 1157069-26,R40Li_GB.book Page 78 Wednesday, November 19, 2014 5:02 PM 9. TROUBLESHOOTING Continue until only a very short section of the wire remains which is the difference between a flashing blue light and a solid green light. b) If the indicator lamp flashed yellow in test 3b) above, a similar test is carried out but with the new loop wire connected to AL instead.

  • Page 79: Technical Data

    1157069-26,R40Li_GB.book Page 79 Wednesday, November 19, 2014 5:02 PM 10. TECHNICAL DATA 10. Technical Data Data R38LiLi R40Li R45Li Dimensions Length 58 cm 58 cm 58 cm Width 46 cm 46 cm 46 cm Height 26 cm 26 cm 26 cm Weight 7,4 kg 7,4 kg...
  • Page 80 1157069-26,R40Li_GB.book Page 80 Wednesday, November 19, 2014 5:02 PM 10. TECHNICAL DATA Data R50LiLi R70Li R80Li Dimensions Length 58 cm 58 cm 58 cm Width 46 cm 46 cm 46 cm Height 26 cm 26 cm 26 cm Weight 7,4 kg 7,4 kg 7,4 kg Electrical system...

  • Page 81: Guarantee Terms

    The blades and wheels are seen as disposable and are not covered by the guarantee. If an error occurs with your GARDENA robotic lawnmower, please contact GARDENA Central Services (see Memo on page 4) for further instructions. Please have the receipt and the robotic lawnmower's serial number at hand when contacting GARDENA Central Service.

  • Page 82: Environmental Information

    1157069-26,R40Li_GB.book Page 82 Wednesday, November 19, 2014 5:02 PM 12. ENVIRONMENTAL INFORMATION 12. Environmental information Symbols on the GARDENA robotic lawnmower or its packaging indicate that this product cannot be handled as domestic waste. It should instead be left at a suitable recycling centre to recycle its electronic components and batteries.

  • Page 83: Eu Declaration Of Conformity

    GARDENA R38Li, GARDENA R40Li, GARDENA R45Li, GARDENA R50Li, GaARDENA R70Li & GARDENA R80Li with serial numbers dating year 2014 week 40 and onwards (the year and week is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL'S DIRECTIVE: •...
  • Page 84 WWW.GARDENA.COM We reserve the right to make changes without prior notice. Copyright © 2014 GARDENA Manufacturing GmbH. All rights reserved. 115 70 69-26 OMSLAG QG, BRUX, 1155943-.indd 3 2014-10-17 10.29...
