Team Durango DEX210v2 User Manual page 40

H
1:1
B H M 2 x 5 m m
7 0 5 0 0 8 x 4
S H I M 2 . 6 x 5 x 0 . 5 m m
7 0 9 0 0 9 x 4
S H O C K O - R I N G
3 3 0 6 0 9 x 8
S H O C K S TO P P E R
3 3 0 0 2 7 x 4
.40.
+
7 0 9 0 0 9
3 3 0 6 0 9
3 3 0 6 0 9
3 3 0 3 1 2 - 5
3 3 0 0 1 1 - 5
3 3 0 0 2 7
Shock OIL
Front 400CST
Rear 300CST
Thread Lock
Note the piston
direction and location
7 0 5 0 0 8
on shim 709009
3 3 0 0 1 1 - 3
4
3 3 0 0 1 1 - 4
X
3 3 0 0 4 3 ( R e a r )
330590-3 2x1.7mm 330590-4 3x1.7mm
(Front) (Rear)
Use correct front and rear pistons
1:1
3 3 0 5 9 6 ( F r o n t )
3 3 0 5 9 7 ( F r o n t )
4 2 . 5 mm
3 3 0 1 6 9 ( R e a r )
5 2 mm
