Team Durango DEX210v2 User Manual page 20

1:1
B H M 2 . 5 x 4 m m
7 0 5 0 2 9 x 4
D R O O P S C R E W
7 0 1 0 0 1 x 2
Set droop screws level
with wishbone as shown
Lef t
.20.
L
R
R ig ht
3 3 0 7 1 2 - 2
7 0 1 0 0 1
7 0 5 0 2 9
3 3 0 7 1 2 - 1
2
X
7 0 5 0 2 9
3 3 0 3 6 3 - 1
3 3 0 3 5 1
Rear
3 3 0 3 5 1
3 3 0 3 6 3 - 1
1:1
3 7 m m
