Specifications

Amplifier section — CA-MXJ500
Output Power (IEC 268-3/DIN)
72 W per channel, min. RMS, both channels driven into 6
with no more than 0.9% total harmonic distortion.
Audio input sensitivity/Impedance (at 1 kHz)
AUX:
420 mV/50 k
MIC 1/2: 3.9 mV/5 k
Speakers/Impedance: 6
– 16
Tuner
FM tuning range:
AM tuning range:
For Saudi Arabia:
At 9 kHz intervals :
At 10 kHz intervals :
For other countries:
At 9 kHz intervals :
At 10 kHz intervals :
CD player
CD Capacity:
3 CDs
Dynamic range:
85 dB
Signal-to-noise ratio: 90 dB
Wow and flutter:
Immeasurable
Cassette deck
Frequency response
Normal (type I): 50 Hz — 14,000 Hz
CrO
(type II):
50 Hz — 14,000 Hz
2
Metal (type IV): 50 Hz — 14,000 Hz (only for playback)
Wow and flutter
0.15% (WRMS)
General
Power requirement:
AC 110 V / AC 127 V / AC 220 V /
AC 230 V – AC 240 V
voltage selector), 50 Hz/ 60 Hz
Power consumption:
95 W (at operation)
14 W (on standby)
Maximum power consumption (for Taiwan only): 360 W
Dimensions (approx.): 265 mm x 335 mm x 368 mm (W/H/D)
7
(10
/
in. x 13
16
Mass (approx.):
9.8 kg (21.6 lbs)
Supplied accessories
See page 6.
Speaker section — SP-MXJ550
T
ype:
3-way bass-reflex type
Speaker units:
Woofer:
Midrange:
Tweeter:
Power handling capacity: 120 W
Impedance:
6
Frequency range:
45 Hz — 25,000 Hz
Sound pressure level: 86 dB/W•m
Dimensions (approx.): 235 mm x 335 mm x 270 mm (W/H/D)
(9
5
/
in. x 13
16
Mass (approx.):
3.7 kg (8.2 lbs) each
Design and specifications are subject to change without notice.
– 26 –
at 1 kHz
87.50 MHz – 108.00 MHz
531 kHz – 1,602 kHz
530 kHz – 1,600 kHz
531 kHz – 1,710 kHz
530 kHz – 1,710 kHz
(adjustable with the
1
1
/
in. x 14
/
in.)
4
2
16 cm (6
5
/
in.) cone x1
16
5 cm (2 in.) cone x1
13
2 cm (
/
in.) dome x1
16
1
/
in. x 10
11
/
in.)
4
16
