Chapter: 1 Overview

Introduction
This manual describes the Viglen L440GX+ motherboard inside your computer. The
motherboard is the most important part of your computer. It contains all of the CPU,
memory and graphics circuitry that makes the computer work.
The motherboard contains the very latest CPU design, Pentium III processors, which
include Intel's MMX technology.
MMX technology adds a total of 57 new
instructions to the CPU, all of which are designed to vastly improve both multimedia
and communications on your PC. The combination of the Intel Pentium III
processors, MMX technology and Viglen expertise make this a formidable computer.
This manual contains technical information about the Viglen L440GX+ motherboard
and other hardware components inside your computer. If you are new to computers
we recommend that you read the user guide first.
If you are an experienced
computer user this manual should provide all the information you will need to
perform simple upgrades and maintenance.
We hope that this manual is both readable and informative.
If you have any
comments or suggestions about how we could improve the format then please fill out
the form at the back of the manual and send it to us.
Above all we hope that you enjoy using your Viglen computer.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L440GX+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viglen L440GX+

Summary of Contents for Viglen L440GX+

  • Page 1: Chapter: 1 Overview

    Chapter: 1 Overview Introduction This manual describes the Viglen L440GX+ motherboard inside your computer. The motherboard is the most important part of your computer. It contains all of the CPU, memory and graphics circuitry that makes the computer work. The motherboard contains the very latest CPU design, Pentium III processors, which include Intel’s MMX technology.

  • Page 2: System Board Components

    L440GX+ Motherboard Specification Intel 8440GX Chipset Intel Primary Secondary Intel DC111D Adaptec Intel 7896 82371EB Cirrus iFlash Logic 5480 Figure 1 System Board Components PS/2 keyboard and Mouse ports Server monitor module connector Heatsink fan connectors Wide SCSI connector Processor connector (SECC2) LVD SCSI connector DIMM Memory sockets (4) Hard Drive LED Input...

  • Page 3: Back Panel Connectors

    Back Panel Connectors The motherboard external IO connectors are attached to a metallic I/O shield. This shield serves several purposes: •= It protects the sensitive motherboard from any external EMC problems. •= It stops the computer from interfering with other electrical devices. •= It allows the motherboard to be easily upgraded in the future without having to resort to buying a whole new case.

  • Page 4: Feature Summary

    Feature Summary The L440GX+ server board supports Pentium III processors running at 450, 500, 550, and 600MHz with 512KB of integrated L2 cache, and also Pentium III processors running at 600, 650 and 700MHz with 256KB of integrated L2 cache. The motherboard features: Form Factor •= ATX form factor of 12 x 13 inches...
  • Page 5 National 87309 I/O features •= Support for two FIFO serial ports, one Multi-mode Parallel port, floppy disk drive and PS/2 keyboard and mouse Adaptec AIC-7896 controller Interface •= Support for 8 or 16 bit fast SCSI •= Ultra2 Wide (Low Voltage Differential) and Ultra Wide (Single Ended) interfaces •= Up to 15 devices per channel (depending on configuration) •= High data transfer rates:...

  • Page 6: Microprocessor Packaging

    The motherboard can be upgraded with Pentium III processors that run at higher speeds. When upgrading the processor the USER must manually configure the processor speeds in the System BIOS see chapter 4. Intel & Viglen recommend using identical stepping processors with the L440GX+ server board whenever possible.
  • Page 7 Memory Main Memory The motherboard has four dual inline memory module (DIMM) sockets. Minimum memory size is 32 MB using unbuffered DIMMs; maximum memory size is 2 GB using registered DIMMs. The BIOS automatically detects memory type, size, and speed. The motherboard supports the following memory features: •= 168-pin DIMMS with gold-plated contacts.
  • Page 8 Chipset The Intel 440GX+ chipset is the latest generation of Intel’s PCI set and is designed for the Pentium III processors. It consists of the Intel 82440GX PCI/A.G.P. controller (PAC) and the Intel 82371EB PCI/ISA/IDE controller (PIIX4e) bridge chip. Intel 82440GX PCI/A.G.P. Controller (PAC) The 82440GX host bridge is a 492-pin BGA device with a 3.3V core and mixed 5V, 3.3V, and GTL+ signal interface pins.

  • Page 9: Super I/O Controller

    Super I/O Controller The PC87309 Super I/O Controller from National Semiconductor is an ISA Plug and Play compatible, multifunction I/O device that provides the following features: •= Serial ports = Two 16450/16550A-software compatible UARTs = Internal send/receive 16-byte FIFO buffer = Four internal 8-bit DMA options for the UART with SIR support (USI) •= Multimode bidirectional parallel port = Standard mode: IBM and Centronics compatible...

  • Page 10: Floppy Controller

    Floppy Controller In the Setup program, the floppy interface can be configured for the following floppy drive capacities and sizes: •= 360 KB, 5.25-inch •= 1.2 MB, 5.25-inch •= 720 KB, 3.5-inch •= 1.2 MB, 3.5-inch (driver required) •= 1.25/1.44 MB, 3.5-inch Keyboard and Mouse Interface PS/2 keyboard and mouse connectors are located on the back panel.

  • Page 11: Expansion Slots

    Programmed I/O operations usually require a substantial amount of processor bandwidth. However, in multitasking operating systems, the bandwidth freed by bus mastering IDE can be devoted to other tasks while disk transfers are occurring. LS-120 Support LS-120 MB Diskette technology enables you to store 120MB of data on a single, 3.5” removable diskette.

  • Page 12: Server Management

    IDE Auto Configuration If you install an IDE drive in the system, the IDE auto-configuration utility automatically detects and configures the drive for operation in the system. This utility eliminates the need to enter the Set-up program after you install an IDE drive. PCI Auto Configuration The PCI auto-configuration utility works in conjunction with the Set-up program to support PCI add-in boards in the system.
  • Page 13 •= Updates the nonvolatile storage device (EEPROM) associated with the Baseboard Management Controller (BMC) that holds the SDR and FRU area •= Updates the DMI area located in the BIOS nonvolatile storage device •= Generically handles FRU devices that may not be associated with the BMC Emergency Management Port (EMP) The COM2 serial port on your L440GX+ server motherboard can be configured for use as an Emergency Management Port.

  • Page 14: Chapter: 2 System Board Options

    Chapter: 2 System Board Options The L440GX+ motherboard is capable of accepting 450, 500, 550, 600, 650 and 700MHz, Pentium III CPU's. RAM can be upgraded to a maximum of 2GB using registered ECC SDRAM DIMMs. Warnings and Cautions WARNING! Unplug the system before carrying out the procedures described in this chapter.
  • Page 15 Make sure you are earthed and free of static charge before you open the computer case. If you are unsure about upgrading your computer, return it to Viglen so a qualified engineer can perform the upgrade. STEPS TO TAKE TO PREVENT STATIC DISCHARGE: 1.

  • Page 16: Overview Of Jumper Settings

    Overview of Jumper Settings The system motherboard inside your computer contains a block of twenty-four pins and eight plastic jumpers. Different pins and jumper configurations make it possible to change how the computer functions. This section of the manual should give you all the information you will require making any changes.

  • Page 17: Jumper Settings

    Jumper Settings Each set of 3 pins requires one jumper, and has two options. The following figure shows the position of jumpers on the motherboard, and also the standard position of the jumpers (two white pins). BMC Forced Update mode BMC Write Enable Chassis Intrusion...
  • Page 18 Table 2 Function Jumper Configuration J2J1 Clear CMOS Preserve contents of NVRAM. Replace contents of NVRAM with default settings. Clear system Maintain current system password. password. Clear password Recover from 9-10 System boots using BIOS stored in the flash corrupted BIOS memory.

  • Page 19: Motherboard Connectors

    Motherboard Connectors There are connectors on the motherboard for Floppy drives, IDE devices, Fans, Power, Serial Port’s, SCSI, and Front Panel Connectors. The location and/or details of these connections are shown below. Floppy Drive connector ATX power CPU Fan Connector PCI IDE Connector x2 Connector 2A Pwr On...

  • Page 20: Front Panel Connectors

    Front Panel I/O Connector Header Figure 4.1 SLP – Sleep switch This option is not used in you Viglen server. Reset - Reset switch connector When these pins are shorted, it will cause the computer to perform a cold reboot.
  • Page 21 Upgrading the CPUs CAUTION! Allow time for the processor and heatsink to cool before touching either of them. The Pentium III processors together with Level 2 cache chips are housed in a protective cartridge called a SECC2. The SECC2 modules are attached to the computer using a slot 1 interface.
  • Page 22 Pentium III shown with Heatsink (Marked A in Figure 5) fitted. Figure 5...

  • Page 23: Installing Memory

    Installing & Removing DIMM Memory Modules Installing Memory You can install from 32MB to 2GB of memory in the motherboard DIMM (Dual In- Line Memory Modules) sockets. The board has DIMM sockets arranged as banks 1, 2, 3, and 4. The motherboard supports the following memory features: •= 168-pin 3.3 V DIMMs with gold-plated contacts •= 100 MHz unbuffered or Registered SDRAM •= Single or double-banked DIMMs...
  • Page 24 To install DIMMs, follow these steps: Intel 8440GX Chipset Intel Primary Secondary Intel DC111D Adaptec Intel 7896 82371EB Cirrus iFlash Logic 5480 Ensure DIMM Notch Locations match exactly with DIMM scoket Keys Notches Figure 6.1 1. Observe the precautions in “Before You Begin” Turn off all peripheral devices connected to the computer.
  • Page 25 6. Insert the bottom edge of the DIMM into the socket. 7. When the DIMM is seated, push down on the top edge of the DIMM until the retaining clips at the ends of the socket snap into place. Make sure the clips are firmly in place, marked 1 in Figure 6.1.

  • Page 26: Replacing The Clock/Cmos Ram Battery

    CAUTION! Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by Viglen. Discard used batteries according to manufacturer’s instructions. The battery is listed as board component ‘L’ on the diagram on page 2.

  • Page 27: Chapter; 3 Solving Problems

    The first part of this chapter helps you identify and solve problems that might occur when the system is in use. The second part lists error code messages that might be displayed. Viglen Technical Support can be reached in the following ways: Telephone: 0181 758 7050 Fax:...

  • Page 28: Troubleshooting Procedure

    •= FRB 3 - 7 minute timer. If the system does not make it up to the end of POST in 7 minutes, the system will automatically reset and try again. It is assumed that the processor failed regardless of what may have caused the system to hang.

  • Page 29: Problems And Suggestions

    Errors that prevent the boot process from continuing (fatal errors), are communicated by a series of audible beeps. If this type of error occurs, refer to the error codes and messages listed at the end of this chapter. 6. Confirm that the operating system has loaded. Problems and Suggestions Table 4 What happens...
  • Page 30 Table 4 continued What happens What to do Characters do not Make sure the video display is plugged in and appear on screen turned on. Check that the brightness and contrast controls are properly adjusted. Check that the video signal cable is properly installed.
  • Page 31 Table 4 continued What happens What to do Setup, can't If you can't enter Setup to make changes, clear enter CMOS RAM to the default values and reconfigure the system in Setup. System halts This indicates a fatal system error that requires before immediate service attention.

  • Page 32: Error And Information Messages

    Error and Information Messages The rest of this chapter describes beep codes, and error messages that you might see or hear when you start up the system: BIOS Error Messages Table 5 Error Message Explanation Diskette drive A error or Drive A: or B: is present but fails the POST Diskette drive B error diskette tests.
  • Page 33 Table 5 (continued) Error Message Explanation Parity Check 1 Parity error found in the system bus. BIOS attempts to locate the address and display it on the screen. If it cannot locate the address, it displays ????. Parity Check 2 Parity error found in the I/O bus.
  • Page 34 BIOS Beep Codes If a hardware problem occurs the computer may emit a number of beeps from the speaker. These are known as beep codes. The pitch and duration of the beep codes may vary but there will always be a set number of beeps. These beeps stem from the BIOS’s initial check on the system and will normally occur in the first few seconds of power on.

  • Page 35: Chapter 4: System Bios

    RAM (also known as the CMOS RAM) and provides a special Setup program to change this information. The BIOS in your Viglen computer is guaranteed to be fully compatible with the IBM BIOS. Phoenix Technology Ltd., it was written by an industrial leader in the field of BIOS software.

  • Page 36: Overview Of Bios Features

    Overview of BIOS Features Introduction The motherboard uses an Intel/Phoenix BIOS, which is stored in flash memory and can be upgraded using a disk-based program. In addition to the BIOS, the flash memory contains the Setup program, Power-On Self Test (POST), the PCI auto- configuration utility, and is Windows 95-ready Plug and Play.
  • Page 37 Plug and Play: PCI Auto-configuration The BIOS automatically configures PCI devices and Plug and Play devices. PCI devices may be onboard or add-in cards. Plug and Play devices are ISA add-in cards built to meet the Plug and Play specification. Auto-configuration lets a user insert or remove PCI or Plug and Play cards without having to configure the system.
  • Page 38 ISA Plug and Play If Plug and Play operating system is selected in Setup, the BIOS auto-configures only ISA Plug and Play cards that are required for booting (IPL devices). If Plug and Play operating system is not selected in Setup, the BIOS auto-configures all Plug and Play ISA cards.
  • Page 39 Recovering BIOS Data Some types of failure can destroy the BIOS. For example, the data can be lost if a power outage occurs while the BIOS is being updated in flash memory. The BIOS can be recovered from a diskette with recovery files using the BIOS recovery Jumper See Recovering the BIOS later in the chapter.

  • Page 40: Configuring The Motherboard

    Configuring the Motherboard Before You Begin CAUTION! •= Always follow the steps in each procedure in the correct order. •= Set up a log to record information about your computer, such as model, serial numbers, installed options, and configuration information. Use an anti-static wrist strap and a conductive foam pad when working on •= the motherboard...

  • Page 41: Changing Jumper Settings

    Changing Jumper Settings Below is a list of actions to take to change the jumper setting for the Clear CMOS option. Most of the actions below refer to all of the jumpers that you might wish to change. Any differences for the changing of each jumper are listed in a table. Clearing the CMOS NOTE: Clearing the CMOS will load the Manufacture default settings in to the NVRAM.
  • Page 42 On the header (J2J1), move the first jumper back to pins 1-2 to restore normal operation as shown below. CMOS Clear Jumper J2J1 (1-3) 1 2 3 Figure 8.2 10. Replace the cover and turn on the computer. For all the below actions after the operation is complete replace the jumper back to its original position unless otherwise stated.
