COMPACT COMPONENT SYSTEM
MX-D602T
Consists of CA-D602T, SP-D602 and SP-DS90.
FM
AM
POWER
PRO LOGIC
3CH LOGIC
TEST TONE
SHIFT
CENTER
–
+
LEVEL
CENTER MODE
SLEEP
REAR
SOUND
–
+
LEVEL
DELAY TIME
MODE
L BALANCE R
FM MODE
S.A.BASS
TAPE A
TAPE B
DIRECTION
REPEAT
DISC 1
DISC 2
DISC 3
CD
CONTROL
TAPE
CONTROL
AUX
REC PAUSE
+
VOLUME
–
RM-SED602TU REMOTE CONTROL
DISC
DISC
DISC
SP-D602
(SP-DSS90)
INSTRUCTIONS
PROGRAM
/RANDOM
REPEAT
EDIT
CA-D602T
(SP-DSC90)
(SP-DSS90)
SP-DS90
COMPACT
DIGITAL AUDIO
SP-D602
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
GVT0004-001A
[ J ]
Advertisement
Table of Contents
Related Manuals for JVC MX-D602T
Summary of Contents for JVC MX-D602T
- Page 1 COMPACT COMPONENT SYSTEM MX-D602T Consists of CA-D602T, SP-D602 and SP-DS90. POWER PRO LOGIC 3CH LOGIC TEST TONE SHIFT CENTER – LEVEL CENTER MODE SLEEP REAR SOUND – LEVEL DELAY TIME MODE L BALANCE R FM MODE S.A.BASS TAPE A TAPE B...
-
Page 2: Important For Laser Products
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU FOND MX-D602T[J]Cover Caution –– POWER switch! Disconnect the mains plug to shut the power off completely. The POWER switch in any position does not disconnect the mains line. -
Page 3: Features
• With the One Touch Operation feature of JVC’s COMPU PLAY you can turn on the System and start the radio, the Cassette Deck, or the CD Player with a single touch. To get such great sound from such a compact package the System has: Great sound Built-in Dolby Pro Logic and Dolby 3ch Logic effects. -
Page 4: Table Of Contents
Table of Contents Features ... 1 How This Manual Is Organized ... 1 IMPORTANT CAUTIONS ... 1 Getting Started ... 3 Accessories ... 3 How to Put Batteries in the Remote Control ... 3 Using the Remote Control ... 3 Connecting the FM Antenna ... -
Page 5: Getting Started
Getting Started Accessories Check that you have all of the following items, which are supplied with the System. AM Loop Antenna (1) Remote Control (1) Batteries (2) FM Wire Antenna (1) If any of these items is missing, contact your dealer immediately. How to Put Batteries in the Remote Control Match the polarity (+ and –) on the batteries with the + and –... -
Page 6: Connecting The Fm Antenna
CAUTION: Make all connections before plugging the Unit into an AC power outlet. Connecting the FM Antenna Using the Supplied Wire Antenna Using an FM 75-Ohm Antenna Cable (not supplied) If reception is poor, connect the outside antenna. Before attaching a 75-ohm coaxial lead (the kind with a round wire going to an outside antenna), disconnect the supplied FM Wire Antenna. -
Page 7: Connecting The Speakers
CAUTION: Make all connections before plugging the Unit into an AC power outlet. Connecting the Speakers For each speaker, connect one end of the speaker wire to the speaker terminals on the back of the System. 1. Open each of the terminals and insert the speaker wires firmly, then close the terminals. 2. -
Page 8: Connecting Auxiliary Equipment
Connecting Auxiliary Equipment VCR or other equipment To listen to this source, press AUX. RIGHT LEFT Now you can plug the AC power cord into the wall outlet, and your System is at your command! -
Page 9: Compu Play
COMPU PLAY COMPU PLAY is JVC’s feature that lets you control the most frequently used functions of the System with a single touch. One Touch Operation starts playing a CD, turns on the radio, plays a tape, etc. with a single press of the play button for that function. -
Page 10: Common Operations
Common Operations STANDBY indicator POWER PHONES S.A. BASS POWER PRO LOGIC 3CH LOGIC TEST TONE SHIFT CENTER – CENTER MODE LEVEL SLEEP REAR LEVEL SOUND REAR – LEVEL DELAY TIME MODE –, + L BALANCE R FM MODE S.A.BASS BALANCE TAPE A TAPE B DIRECTION... -
Page 11: Setting The Clock
Setting the Clock Before operating the unit, set the correct time. You can set the clock whether the Unit is on or off. 1. Press TIMER/CLOCK. The hour digits begin flashing. 2. Press 4 P. DOWN or ¢ P. UP on 2 , 4 the MULTI CONTROL to set the hours. -
Page 12: Balance Adjustment
CAUTION: The Volume cannot be adjusted while the Unit is on STANDBY. DO NOT turn on the Unit and/or start playing any source without setting the VOLUME control to 0; otherwise, the sudden blast of sound can damage your hearing, speakers and/or headphones. For private listening Connect a pair of headphones to the PHONES jack. -
Page 13: Sound Modes
Sound Modes The System has some preset sound effects that give you control of the way your music sounds, so you can tailor it for your room and for the quality of the source. We can give you some idea of how each one affects the music, but the only way to really tell is to try them yourself. -
Page 14: When A Rear Speaker Is Connected
3. Use MULTI CONTROL to adjust to any Sound Mode desired. Flashing 4. Press SET. 5. Press 4 P. DOWN or ¢ P. UP on the MULTI CONTROL to select 6. Press SET again. When a Rear Speaker is Connected If the optional rear speaker is connected, you can use the rear speaker to enjoy Surround effects when a Surround effect (D. -
Page 15: Listening To Auxiliary Equipment
Listening to Auxiliary Equipment By playing the sound from auxiliary equipment through the System, you can gain control over how the music or program sounds. Once the connected equipment is playing through the System, you can apply the sound effects. First make sure that the auxiliary equipment is properly connected to the System. -
Page 16: Dolby Surround
Dolby Surround PRO LOGIC / 3CH LOGIC Operation keys POWER PRO LOGIC 3CH LOGIC TEST TONE SHIFT CENTER – LEVEL CENTER MODE SLEEP REAR SOUND – DELAY TIME LEVEL MODE L BALANCE R FM MODE S.A.BASS TAPE A TAPE B DIRECTION REPEAT DISC 1... -
Page 17: Preparing The Dolby Surround
Preparing the Dolby Surround To use the Dolby Surround effects, you need to prepare the various settings. These settings are set using the Remote Control. The Dolby Surround settings are: Center Speaker Mode Center Speaker mode contains the following four settings. PHANTOM: Select this setting if you have not connected a center speaker. -
Page 18: Getting Ready To Use Dolby Pro Logic
Getting Ready To Use Dolby Pro Logic Speaker Arrangements for Dolby Pro Logic ———————— Speaker Setting-up Dolby Pro Logic ———————————————— 1. Press PRO LOGIC/3CH LOGIC to select PRO LOGIC. PRO LOGIC SHIFT 2. Select the desired Center Speaker mode. CENTER MODE 3. -
Page 19: Getting Ready To Use Dolby 3 Channel Logic
Getting Ready To Use Dolby 3 Channel Logic Speaker Arrangements for Dolby 3 Channel Logic ———— Setting-up Dolby 3ch Logic ———————————————— 1. Press PRO LOGIC/3CH LOGIC to select 3CH LOGIC. Each time you press the button, Dolby Surround programs change as follows: = PRO LOGIC = 3CH LOGIC = OFF = (back to the beginning) When using the Remote Control, press SHIFT then press the 3CH LOGIC (2). -
Page 20: Using The Tuner
Using the Tuner POWER PRO LOGIC 3CH LOGIC TEST TONE SHIFT CENTER – LEVEL CENTER MODE SLEEP Number keys REAR SOUND – DELAY TIME LEVEL MODE L BALANCE R FM MODE S.A.BASS FM MODE TAPE A TAPE B DIRECTION REPEAT DISC 1 DISC 2 DISC 3... -
Page 21: Three Ways To Select A Station
On the Remote Control To tune in FM stations, press FM. To tune in AM stations, press AM. COMPU PLAY When FM or AM is pressed while the power is on standby, the power is automatically turned on. Three Ways to Select a Station —————————————— Press 1 TUNING DOWN or TUNING UP ¡... -
Page 22: Using The Cd Player
Using the CD Player POWER PRO LOGIC 3CH LOGIC TEST TONE SHIFT CENTER – LEVEL CENTER MODE SLEEP Number keys REAR SOUND – LEVEL DELAY TIME MODE L BALANCE R FM MODE S.A.BASS TAPE A TAPE B DIRECTION REPEAT CD Player DISC 1 DISC 2 DISC 3... -
Page 23: Loading Cds
Loading CDs 1. Press 0 on the CD Player you want to insert the disc onto. “OPEN” appears on the display and the disc tray slides out. COMPU PLAY When 0 is pressed while the power is on standby, the power is automatically turned on. 2. -
Page 24: Selecting A Track
On the Remote Control CONTROL DISC 1 DISC 2 DISC 3 COMPU PLAY When DISC (1 to 3) on the Remote Control is pressed while the power is on standby, the power is automatically turned on. To stop play the disc, press 7 STOP (or 7 on the Remote Control). The display will show the total number of tracks and total playing time of the disc that was playing followed by the playing time of the first track. -
Page 25: Programing The Playing Order Of The Tracks
Programing the Playing Order of the Tracks You can change the order in which the discs and tracks play, and select only the discs and tracks you want from among those loaded in the CD Player. You can program up to 32 steps in any desired order from among the discs in the CD player. You can only make a program when the CD Player is stopped. -
Page 26: Checking The Program
3. Press the number keys (1 to 10 and +10) to select the tracks. PRO LOGIC 3CH LOGIC TEST TONE CENTER – LEVEL CENTER MODE REAR – LEVEL DELAY TIME L BALANCE R 4. Repeat steps 2 to 3 to select the other tracks for the program. 5. -
Page 27: Repeating A Track Or The Discs
Repeating a Track or the Discs You can have all the discs, the program or the individual track currently playing repeat as many times as you like. REPEAT Press REPEAT on the Unit. Each time you press the button, the Repeat Modes change as follows. = REPEAT ALL = REPEAT 1 = No indicator = (back to the beginning) REPEAT ALL: Repeats all the tracks on the CDs, or all the tracks in the program. -
Page 28: Using The Cassette Deck (Playing)
Using the Cassette Deck (Playing) POWER PRO LOGIC 3CH LOGIC TEST TONE SHIFT CENTER – LEVEL CENTER MODE SLEEP REAR SOUND – LEVEL DELAY TIME MODE L BALANCE R S.A.BASS FM MODE TAPE A TAPE B DIRECTION REPEAT DISC 1 DISC 2 DISC 3 Cassette Deck... -
Page 29: Regular Play
Regular Play When the power is already on, you can use this basic procedure: 1. Press down 0 for the deck you want to use. 2. When the cassette holder opens, put a cassette in, with the exposed part of the tape down, toward the base of the Unit. If the cassette holder does not open, turn the power off, then back on and press down 0 again. -
Page 30: Reverse Mode
Music Scan works by detecting a 4-second long blank at the beginning of each selection, so it will not work well if your tape has • • • Reverse Mode • No blank at the beginning of a selection. • Noise (often caused by much use or poor quality dubbing) which fills the blank with noise. -
Page 31: Using The Cassette Deck (Recording)
Using the Cassette Deck (Recording) POWER PRO LOGIC 3CH LOGIC TEST TONE SHIFT CENTER – LEVEL CENTER MODE SLEEP REAR SOUND – LEVEL DELAY TIME MODE L BALANCE R FM MODE S.A.BASS TAPE A TAPE B DIRECTION REPEAT DISC 1 DISC 2 DISC 3 CONTROL... -
Page 32: Standard Recording
CAUTION: If recordings you have made have excessive noise or static, the Unit may be too close to a TV which was on during recording. Either turn off the TV or increase the distance between the TV and the System. Standard Recording This is the basic method for recording any source. -
Page 33: Recording Am Station To Tape
Recording AM Station to Tape ——————————————— When recording an AM broadcast, beats may be produced which are not heard when listening to the broadcast. In this case, press PROGRAM/RANDOM on the CD Player to eliminate the beats. 1. Set to AM station and start recording. PROGRAM /RANDOM 2. -
Page 34: Tape To Tape Recording (Dubbing)
5. Press SET. 6. Insert a blank or erasable cassette in Deck B. 7. Press CD REC START . To stop at any time while recording, press 7 STOP or REC START/STOP on the Unit. If 7 STOP is pressed, the Cassette Deck will create a four-second blank space after the CD Player stops. If REC START/STOP is pressed, the CD Player and Cassette Deck will stop simultaneously. -
Page 35: Using The Timer
Using the Timer POWER PRO LOGIC 3CH LOGIC TEST TONE SHIFT CENTER – LEVEL CENTER MODE SLEEP SLEEP REAR SOUND – LEVEL DELAY TIME MODE L BALANCE R FM MODE S.A.BASS TAPE A TAPE B REPEAT DIRECTION DISC 1 DISC 2 DISC 3 TAPE CONTROL... -
Page 36: Setting The Daily Timer
Setting the Daily Timer With this timer you can wake up to music from a CD, tape, your favorite radio program. Procedure For Setting the Daily Timer 1. Press TIMER/CLOCK so that “DAILY” appears on the display. 2. Press TIMER/CLOCK again. 3. -
Page 37: Turning The Daily Timer On And Off
To use the Tuner as the source (Possible only after presetting stations.): 1. To listen to FM, press 4 P. DOWN or ¢ P. UP on the MULTI CONTROL repeatedly until “TUNER FM” flashes and press SET. To listen to AM, press 4 P. DOWN or ¢ P. UP on the MULTI CONTROL repeatedly until “TUNER AM”... -
Page 38: Setting The Recording Timer
CAUTION: If the Unit is unplugged, or a power failure occurs, the timer setting will be erased in a few days. If the settings are erased in this way, reset the timer settings. Setting the Recording Timer With the Recording Timer you can make a tape of a radio broadcast automatically whether or not you are home. -
Page 39: Turning The Recording Timer On And Off
Turning the Recording Timer On and Off ————————— Once the Recording Timer has been used, the setting is maintained but the Timer is set to off. To turn the Recording Timer off before the timer starts, press TIMER/CLOCK repeatedly until “REC”... -
Page 40: Timer Priority
Timer Priority Since each timer can be set independently, you may wonder what happens if the settings overlap. Here are the priorities for each timer: Example 1 Recording Timer Sleep Timer Example 2 Recording Timer Daily Timer The Recording Timer always has priority. This means that: •... -
Page 41: Care And Maintenance
Care and Maintenance Compact Discs Handle your compact discs, cassette tapes, and Cassette Deck carefully, and they will last a long time. • Remove the CD from the case by holding it at the edges while pressing the center hole lightly. •... -
Page 42: Troubleshooting
Troubleshooting • If you are having a problem with your System, check this list for a possible solution before calling for service. • If you cannot solve the problem from the hints given here, or the Unit has been physically damaged, call a qualified person, such as your dealer, for service. -
Page 43: Specifications
Specifications CA-D602T ————————————————————————— Amplifier Section Output Power Center 25 watts min. RMS at 8 ohms at 1 kHz, with no more Input Sensitivity/Impedance (1 kHz) Speaker terminals 6 - 16 ohms Cassette Deck Section Frequency Response Type II (CrO Type I (NORMAL) : 50 - 14,000 Hz Wow And Flutter 0.15% (WRMS) CD Automatic Changer Section CD Capacity 3 discs... - Page 44 SP-D602 —————————————————————————— Power Handling Capacity 80 W SP-DS90 —————————————————————————— Power handling capacity 30 watts Power handling capacity 30 watts Type 3-way, 3-speaker bass-reflex type (Magnetically-shielded type) Speaker Tweeter 2 cm (13/16 inches) dome 1 Midrange 5 cm (2 inches) cone 1 Woofer 16 cm (6-5/16 inches) cone 1 Impedance 6 ohms Frequency Range 46 - 20,000 Hz...
- Page 46 Sophisticated electronic products may require occasional service. Just as quality is a keyword in the engineering and production of the wide array of JVC products, service is the key to maintaining the high level of performance for which JVC is world famous. The JVC service and engineering organization stands behind our products.
