5.3. Electronic Meter
Electronic meters have digital readouts, as well as an optical port which emits light pulses similar
to the infrared light produced by a television remote control.
This section deals with meters where the optical port is located on the face, more specifically,
where the distance between the port and the outer rim of the meter dome is AT LEAST 1½
inches (37 mm). If in doubt, physically measure the distance between your port and the outer
rim of the dome. If it is less than 1½ inches (37 mm), you must follow the instructions in section
5.4 to install your Sensor Unit.

5.3.1. Preparing Your Sensor Unit

Your Sensor Unit is ready to be installed from the box.
However, it is recommended that you do the following:
1. Pull the Sensor Arm latch upward to open it.
2. Ensure that the Sensor Arm is completely pushed
in as far as it will go.
3. Close the latch.
12
(Optical Port on Face)
Optical Port
>1.5 inches
