Power connector 2
I/O module bay 1
I/O module bay 5
I/O module bay 2
I/O module bay 6
Blower module 2
error LED
Rear system
LED panel
Serial connector
Notes:
1. Throughout this document, the NetXen 10 Gb 2-Port Ethernet Expansion
Card is referred to as the Ethernet expansion card, the expansion card, or
the I/O expansion card.
2. Unless otherwise stated, references to the BladeCenter unit apply to all
BladeCenter units that support high-speed I/O modules, such as the
BladeCenter H unit.
3. The blade servers or BladeCenter units that are described or shown in this
document might be different from your blade server or BladeCenter unit.
For additional information, see the documentation that comes with your
blade server or BladeCenter unit.
4. Changes are made periodically to the IBM Web site. Procedures for locating
firmware and documentation might vary slightly from what is described in
this document.
5. The illustrations in this document might differ slightly from your hardware.
6. Unless otherwise stated, references to the management module apply to the
BladeCenter Advanced Management Module.
The I/O expansion card comes with a one-year limited warranty. For
information about your warranty, see Appendix B, "Warranty," on page 23. You
can obtain up-to-date information about the expansion card at
http://www.ibm.com/systems/bladecenter/.
2
NetXen 10 Gb 2-Port Ethernet Expansion Card: Installation Guide
I/O module bay 7
I/O module bay 8
I/O module bay 9
I/O module bay 10
Power connector 1
Management
module 1
I/O module bay 3
Blower module 1
error LED
Blower module 1
Management
module bay 2
I/O module bay 4
Blower module 2
