Clarion DCZ625 Service Manual




6 - D I S C C D C H A N G E R
O P T I C A L D I G I T A L O U T P U T

SPECIFICATIONS

Frequency response: 5Hz to 20kHz( 1dB)
Signal to noise ratio: 105dB(1kHz)IHF-A
Wow and flutter: Below measurement limits
Power supply voltage: 14.4V DC
(10.8 to 15.6V allowable)
Ground: Negative
Current consumption: 1A
Dimensions(mm): 225(W) 63(H) 167(D)
Weight: 1.65kg
NOTES
Use a CeNET extension cable that is less than 20m in
length.
CD singles cannot be used.
This unit is compatible with CD text.When it is connected
to a center unit suitable for CD text display, CD text can
be displayed.(When it is connected to a center unit with-
out CD text function,CD text cannot be displayed.)
The following magazines cannot be used for this
unit.Using them will result in a damage to hte mecha-
nism and cause the magazine not to eject.
1.Magazine(CAA-122) for the 12-disc CD chnager
2.Magazine(CAA-355) for the 6-disc CD changer
Do not play heart-shaped, octagonal, or other specially
shaped CDs.
We cannot supply PWB with component parts in prin-
ciple. When a circuit on PWB has failure , please repair
it by component parts base. Parts which are not men-
tioned in service manual are not supplied.
Specifications and design are subject to change without
notice for further improvement.
Clarion Co., Ltd.
5-35-2, Hakusan, Bunkyouku, Tokyo, 112-8608 Japan
Service Dept.- 50 kamitoda,Toda-shi,Saitama,335-8511 Japan Tel: 048-443-1111 FAX:048-433-6996
T E X T
- 1 -
Service Manual
6 Disc CD Changer with CD text

Model
(PE-2433B/for U.S.A.)
(PE-2433K/for Other Countries)

Model
(PE-2433E/for Europe)
COMPONENTS
PE-2433B-A/K-A/E-A
Main unit
CD magazine
Mounting bracket
Mounting bracket(with bolt)
Lock pin
Extension lead(13P)
Parts bag
Cushion rubber
Parts bag
Cord clamp
Wing nut
Hex-bolt
To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow
the instructions so that customers and Engineers
in charge of repair or inspection can avoid suf-
fering any risk or injury.
1. Use specified parts.
The system uses parts with special safety features against
fire and voltage. Use only parts with equivalent charac-
teristics when replacing them.
The use of unspecified parts shall be regarded as re-
modeling for which we shall not be liable. The onus of
product liability (PL) shall not be our responsibility in cases
where an accident or failure is as a result of unspecified
parts being used.
2. Place the parts and wiring back in their original positions
after replacement or re-wiring.
For proper circuit construction, use of insulation tubes,
bonding, gaps to PWB, etc, is involved. The wiring con-
Published by Service Dept.
298-5960-00 Dec.2001 P
Printed in Japan


1
CAA-397-900 1
300-9873-20 2
300-9874-20 2
335-0594-20 3
855-3416-50 1
345-8653-00 2
335-0833-01 2
722-0545-00 4
734-5008-37 4
DCZ625
DCZ628
