StarTech.com R300WN22GA Instruction Manual

StarTech.com R300WN22GA Instruction Manual

300mbps wireless-n guest wifi access point / account generator - 2t2r 2.4ghz
Hide thumbs Also See for R300WN22GA:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
300Mbps Wireless-N Guest WiFi
Access Point / Account Generator -
2T2R 2.4GHz
R300WN22GAxx
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 09/08/2014
*actual product may vary from photos

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R300WN22GA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for StarTech.com R300WN22GA

Summary of Contents for StarTech.com R300WN22GA

  • Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 09/08/2014...
  • Page 2 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by StarTech.com could void the user’s authority to operate the equipment.
  • Page 3 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...

  • Page 4: Table Of Contents

    Table of Contents Introduction ....................1 Packaging Contents ..........................1 Product Diagram ..................1 Product Overview ............................. 1 LED Indicators............................. 1 Installation ....................2 Advanced Setup Menu ................6 Management .............................. 6 Security ................................. 17 System ................................21 Server................................26 Guest Setting .............................. 30 Employee Setting ............................
  • Page 5 Configuration ..................47 Firmware Upgrade ............................ 48 Boot Code ..............................51 System Account ............................51 SSL Certificate ............................. 52 PING ................................52 Restart ................................53 Logout ................................53 Specifications ..................54 Technical Support ..................55 Warranty Information ................55 Instruction Manual...

  • Page 6: Introduction

    Introduction Packaging Contents • 1 x Guest WiFi Access Point / Account Generator • 1 x Ethernet Cable • 2 x Screws for Wall Mounting • 1 x Power Adapter • 1 x Quick Start Guide • 1 x Instruction Manual CD Product Diagram Product Overview Guest Accont...

  • Page 7: Installation

    State Description No power Green Unit powered on Remains off while the unit is initializing Initialization complete, Green system is ready to use During firmware Green (Blinking) upgrades, this system LED will blink No network connection 10/100Mbps network Green connection established Green (Blinking) Indicates WAN activity No network connection...
  • Page 8 2. The distance between the two mounting sockets on the back of the Network Switch is approximately 106mm. Mark the distance on the wall, making sure your marks are straight and level. 3. Depending on the mounting surface, use the appropriate tools and hardware to install mounting screws into the surface.
  • Page 9 10. The Setup Wizard will bring you through the basic configuration requirements in 3 sections: Internet – Allows you to select the appropriate Internet connection type for your • DHCP Client – Allows the device to automatically obtain TCP/IP settings from your ISP Modem.
  • Page 10 Wireless – Allows you to specify basic wireless network settings • Country – Choose between ETSI (European Telecommunications Standards Institute) or FCC (Federal Communications Commission – North America). • Channel – Select the channel ID for wireless connection. System – Allows you to specify basic system settings for the AP •...

  • Page 11: Advanced Setup Menu

    • System date and time – Specify the Time Zone and choose between manual date and time entry or NTP server settings. • Secure Administrate IP Address – Administrator can specify 5 IP addresses or a range to allow remote control access from network. 11.
  • Page 12 Item Default Description Syslog Disable Enables or disables the syslog server function. Syslog on LAN Server IP Address Empty Enter your syslog server LAN IP address. Server MAC Empty Enter your syslog server MAC address. Address Syslog on WAN Server 1 IP Empty Enter the WAN IP address of your first syslog server.
  • Page 13 Instruction Manual...
  • Page 14 Interval Item Description Time System System information would be sent according to specified interval time. Format: PRODUCT=GW-1;VER=2.00.00;LOGNAME=DVI; DATE=07Mar26;TIME=11:30:00; WANMAC=09-00-0e-00-00-01;LANMAC=09-00- 0e-00-00-02; WLANMAC=09-00-0e-00-00-03; 5~60 System Information IP_ADDRESS=210.66.37.21; SYS_UP_TIME=14D2 minutes 3H34M21S;WANTXOK=99999; WANRXOK=99999;WANTXERROR=99999;WA NRXERROR=99999; LANTXOK=99999;LANRX OK=99999;LANTXERROR=99999; LANRXERRO R=99999;WIRELESSTXOK=99999;WIRELESSRX OK=99999; WIRELESSTXERROR=99999;WIRELES SRXERROR=99999; If device have been rebooted or restarted, the log would be sent.
  • Page 15 A log will be sent if system manager (Administrator) login to or logout from the device. Format: PRODUCT=GW-1;VER=2.00.00;LOGNAME=SUN; When DATE=07Mar26;TIME=15:23:32; system System Manager WANMAC=09-00-0e-00-00-01;LANMAC=09-00- manager Activity Information 0e-00-00-02; WLANMAC=09-00-0e-00-00-03; login or IP_ADDRESS=210.66.37.21; logout SYS_NAME=Cafehotspot;LOCATION=East;CITY= Taipei; COUNTRY=Taiwan; FIRMWARE=v1.01.02; MESSAGE=System_Up; Account Name = Admin Status = Login | Logout | Idle_Time_Out A log including wireless users information will be sent according to specified interval time.
  • Page 16 User A log including users information will be sent when a user logs in Format: PRODUCT=GW-1;VER=2.00.00;LOGNAME=ULI;D ATE=07Mar26; TIME=15:23:32;WANMAC=09-00- 0e-00-00-01; When a User Login user logs LANMAC=09-00-0e-00-00-02; WLANMAC=09- 00-0e-00-00-03; IP_ADDRESS=210.66.37.21;USER_ NAME=asdfg12;USER_IP=10.59.1.1; USER_ MAC=02-34-3e-01-00;INTERFACE=Ethernet; USER_TYPE=Dynamic; User Type = Guest/ Employee A log including users information will be sent when user logged –out Format: PRODUCT=GW-1;VER=2.00.00;LOGNAME=ULO...
  • Page 17 A log including logged-in users information will be sent according to specified interval time Format: PRODUCT=GW-1;VER=2.00.00;LOGNAME=CUL ;DATE=07Mar26; TIME=15:23:32;WANMAC=09- 00-0e-00-00-01; .5~60 LANMAC=09-00-0e-00-00-02; WLANMAC=09- Current User List minutes. 00-0e-00-00-03; IP_ADDRESS=210.66.37.21;USER_ NUM=0;SEQ=1-5; USER_NAME=asdfg12,USER_ IP=10.59.1.2,USER_MAC=02-34-3e-01-00, INTERFACE=Ethernet,USER_TYPE=Dynamic,RXDATA=1234, TXDATA=1234,USED_ TIME=24:00:00,SESSION=100,WLAN_SIG=N/A; Account A log will be sent when an account is created Format: PRODUCT=GW-1;VER=2.00.00;LOGNAME=ACI;D ATE=07Mar26;...
  • Page 18 Item Default Description Session Trace Disable Disables or enables session trace function. Primary TFTP Empty Enter the IP address of the primary TFTP server. Server IP Address Secondary TFTP Server IP Empty Enter the IP address of the secondary TFTP server. Address Send Session Send the session trace log file at the specified...

  • Page 19: Bandwidth Management

    E-mail (SMTP) If your SMTP server requires authentication before Server needs accepting e-mail, enable this option. These values Disable to check my (username and password) are supplied by your account network administrator, SMTP server provider or ISP. Enter the username for the SMTP server (max 64 Username Empty characters).
  • Page 20 Item Default Description Enables or disables Bandwidth Disable Bandwidth Management. Specify the max upstream Maximum Upstream 64Kbps bandwidth (64 – 5120 Kbps). Specify the max Maximum Downstream 128Kbps downstream bandwidth (64 – 5120 Kbps). SNMP The SNMP configuration menu allows you to access to your device via Simple Network Management Protocol.
  • Page 21 Item Default Description SNMP Disable Disables or enables SNMP management. If SNMP is enabled, you can specify the SNMP port number. The allowed SNMP port numbers are 161 (default), or from SNMP Port 16100-16199 and Trap port numbers are 162 (default), or from 16200-16299. This Port setting is useful for remote control via NAT.

  • Page 22: Security

    Security Pass Through The Pass Through function allows you to specify devices that can pass through the AP, without being checked and authorized. Click the Add to List button once you’ve created a new entry. Instruction Manual...
  • Page 23 Item Default Description Pass Through Disable Enables or disables the pass through function. Destination URL/IP Address Pass Through Enter the URL Page URL or Website Empty (e.g. http://www.yahoo.com – Max 50 characters). Start / End IP Empty Enter the range of IP address you want to allow. Address Subscriber IP/MAC Address or LAN Device Pass Through Start / End IP...
  • Page 24 Item Default Description Enables or disables the pass through Filtering Disable function. This Web Site Enter the message you would like to HTTP Message to display is blocked by display to the user when they attempt when a website is blocked Administrator to access a restricted area.
  • Page 25 Secure Remote The Secure Remote feature allows you to create a secure connection to a remote site or back-end system through a VPN PPTP Client. If “Secure Remote” is enabled, the RADIUS packet / syslog will be transferred to this secure connection. Item Default Description...

  • Page 26: System

    System System The System menu defines basic system settings. Instruction Manual...
  • Page 27 Item Default Description Enter a system name (Max 40 alphanumeric System/Host Name Empty characters). Domain Name Empty Enter a domain name (Max 80 1 characters). Enter your location and contact information Location Information Empty if desired. Date/Time Select the appropriate time zone for your Time Zone location.
  • Page 28 Manual Setting Manually set the date for the system Date (Year/Month/Day) (Ranges from 2011 to 2035). Time Set the system time. (Hour:Minute:Second) NTP Setting Enter the primary IP address or domain Server IP / Domain Name 1 Empty name of NTP server (Max100 characters). Enter the secondary IP address or domain Server IP / Domain Name 2 Empty...
  • Page 29 This function allows remote users to ping the AP. Ping is normally used to test the Allow remote user to ping Enable physical connection between two devices, the device to ensure that everything is working correctly. SSL Certificate Default Options: Default or Customer Certificate WAN/LAN The WAN / LAN menu allows you to configure IP addressing and WAN connection settings.
  • Page 30 Item Default Description Guest WLAN IP Address Setting Enter the internal LAN IP address for the IP Address 10.59.1.200 device. Enter the subnet mask for the IP address Subnet Mask 255.255.255.0 entered above. Employee WLAN IP Address Setting The internal LAN IP address of your Wireless IP Address 10.59.2.200 Subscriber Server Gateway.

  • Page 31: Server

    Server The Server menu allows you to configure Web and DHCP server settings. Item Default Description Web Server Enter the HTTP port number (80 or from 8010 to 8060). For access to the AP under NAT, enter HTTP Port using the format: “http://[IP Address]:[Port Number]”...
  • Page 32 Enter an idle timeout duration in minutes (From 1-1440). If the idle time out is set as 5 Administrator 5 Minutes minutes, it means that if the administrator Idle-Timeout doesn’t send packet in 5 minutes, the administrator will be logged out. DHCP Server DHCP Disable: Disable the DHCP server DHCP...
  • Page 33 Wireless The Wireless menu allows you to configure your desired wireless mode and applicable settings. Item Default Description General Settings Select the Country code: Country -ESTI (Europe; Channel 1~13) -FCC (North America; Channel 1~11) Select the channel ID for wireless Channel connection.
  • Page 34 Auto Channel Width 20/40MHz Indicates the frequency interval of the Beacon Interval beacon (From 1 to 1000). This valid range is from 256-2342. This setting determines the packet size at which the AP issues a Request To Send (RTS) before sending the packet.

  • Page 35: Guest Setting

    Guest Setting Guest ESSID Settings The Guest ESSID Settings menu allows you to configure your guest wireless settings and security. Item Default Description Activate or de-activate the Guest wireless General Settings Active connection interface. The ESSID is the unique name that is shared among all points in a wireless ESSID Guest...
  • Page 36 The AP will randomly generate keys at the Pre-shared Key Empty length specified here. (8-10 characters) Use WPA with RADIUS Disable Enter the RADIUS server IP address or Server IP Empty domain name (Max 15 characters). Enter the authentication port number Authentication Port 1812 (From 0 to 65535).
  • Page 37 Item Default Description No Authentication: Subscriber can direct access the Internet without enter username and password. Built-in Authentication: The AP provides “Built-in Authentication” that allows you to build up an Internet service without extra authentication software. When selected, you can generate Authentication Built-in the subscriber account inside the AP, and...
  • Page 38 Usage Time The Usage Time menu allows you to manage account expiration and usage duration settings. Item Default Description Enter the number of hours/days that unused accounts Expiration 12 hours should be deleted after (Max 30 Hours / Days). Enter the number of hours/days the guest account Usage Time 3 hours should remain valid for (Max 30 Hours / Days).
  • Page 39 Customization The Customization menu allows you to create a custom login page, add a logo, create an information pop-up window and user agreement as needed. Login Page Tab Provides several different options for you to create or redirect guest users to your login page.
  • Page 40 Item Default Description Select the check box to display the logo file specified on the Logo tab. Logo Disable Note: You will receive an error message if no logo has been specified. Enter a page title for the top of the login box (Max 80 Title Welcome characters).
  • Page 41 Redirect Item Default Description Enter the URL where your login page is located (Max Redirect Disable 200 characters), or click the button to create your own (sample code below). Instruction Manual...
  • Page 42 Advanced Item Default Description Welcome Welcome Enter a Welcome slogan (Max 80 characters). Slogan Page Enter your desired page background color in None Background Hexadecimal. Enter a paragraph for advisement or announcements Article Empty (Max 1024 characters). Article Text 000000 Enter your desired text color in Hexadecimal.
  • Page 43 • Sample Framed Page Logo Tab The Logo tab allows you to upload your company logo for use on the login page. Item Default Description File Path Empty Click Choose File to select a file from your local PC Instruction Manual...
  • Page 44 Information Window Tab The Information Window tab allows you to create a customized message to new guests after they log in. Item Default Description Display Redirect: Displays the Information Window Information in the same tab that the user logs in from. Window after a Enabled –...
  • Page 45 • Sample Information Window User Agreement Tab The User Agreement tab allows you to create a customized user agreement page for guest users. Note: The User Agreement screen can be enabled under Guest Settings > Authentication Instruction Manual...
  • Page 46 Item Default Description User Enter the window name to be shown in the Title Agreement title bar (Max 100 characters). Page Enter your desired title text color in Title Text Colour 000000 Hexadecimal. The article is allowed the administrator to input a paragraph in the subscriber login Article Empty...

  • Page 47: Employee Setting

    Employee Setting Employee ESSID Settings The Employee ESSID Settings menu allows you to configure your employee wireless settings and security. Item Default Description Activate or de-activate the wireless General Settings Active connection interface. The ESSID is the unique name that is shared among all points in a wireless network.

  • Page 48: System Status Menu

    Enter the authentication port number from Authentication Port 1812 0 to 65535. Shared Secret Key Empty Enter the RADIUS key System Status Menu System Report The System report displays current basic system information, including: service connection status, host name, LAN, WAN, DHCP Configuration, DNS, SSL Certificate, network traffic Information and the system firmware version number.

  • Page 49: Account List

    Account List The Account List displays all account information on this device, including: the status, PIN, usage time, time created, login time, expiration time and status. This page will refresh automatically every 5 minutes, or you can click the Refresh button in the top right corner to update manually.

  • Page 50: Account Log

    Account Log The Account Log displays account activity information. • Click the Export button to export the contents of the log to a text file (filename: export.log) • Click Clear Log to empty the log contents • Click the column headings to change the sorting Instruction Manual...

  • Page 51: Current User Report

    Current User Report The Current User report displays currently logged-in user status and allows the administrator to disconnect users if needed. This page will refresh automatically every 5 minutes, or you can click the Refresh button in the top right corner to update manually. •...

  • Page 52: Session List

    Session List The Session List displays the real-time session usage information for the AP. System Tools Menu The System Tools Menu allows you to upgrade Firmware, change passwords and backup or restore configuration files. Configuration The Configuration menu allows you to backup or restore the configuration settings for the device.

  • Page 53: Firmware Upgrade

    Item Default Description Click the button to save the system Backup configuration to a file computer. (export.cfg) Remote TFTP Server IP Empty Enter the IP address of the TFTP Server. Address File Name Empty Enter your desired file name. Restore Click Choose File to select a file from your Local PC File Path Empty...
  • Page 54 Item Default Description Click Choose File to select a file from Local PC File Path your local PC Remote TFTP Server IP Address Empty Enter the IP address of TFTP Server. Enter the file name in the File File Name Empty Name field.
  • Page 55 Scheduled Firmware Upgrade Tab The Scheduled Firmware Upgrade tab allows you to specify a file location and frequency for automated firmware upgrades. Item Default Description Disables or enables the scheduled firmware Disable/Enable Disable upgrade function. TFTP Server IP Empty Enter the IP address of the TFTP Server. Enter the file name and location in the File File Synchronization Empty...

  • Page 56: Boot Code

    Boot Code The Boot Code menu allows you to upload a new boot code file should an update become available. System Account The System Account menu allows you to change the administration account for the device. Item Description Username Enter a username up to 20, case-sensitive alphanumeric characters. Password Enter a password up to 20, case-sensitive alphanumeric characters.

  • Page 57: Ssl Certificate

    SSL Certificate The SSL Certificate menu allows you to add your certificate files to the device. PING The PING menu will issue the ping command to your specified IP address or URL. Item Description IP or URL Enter the IP address or the URL link. Instruction Manual...

  • Page 58: Restart

    Restart The Restart menu will reboot the device. Logout The Logout menu will exit from the configuration screen. Instruction Manual...

  • Page 59: Specifications

    Specifications Supported Wireless Standards IEEE802.11b/g/n Chipset Ralink – RT3052 Connectors 5 x RJ45 Ethernet Female Antenna Configuration 2x2:2 (TxR:s) Wireless Frequency Range 2.400 – 2.484 Wireless Bandwidth 20/40MHz WPA(TKIP with IEEE 802.1x) Wireless Encryption Supported WPA2(AES with IEEE 802.1x) WPA -PSK Maximum Wireless Distance 300Mbps (Wireless-N) Maximum Data Transfer Rate...

  • Page 60: Technical Support

    Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
  • Page 61 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
