Outdoor 300Mbps Wireless N Access
Point - 2T2R 5GHz
R300WN22OP5 / R300WN22OP5G / R300WN22OP5E
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 05/25/2018
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com R300WN22OP5G
Summary of Contents for StarTech.com R300WN22OP5G
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 05/25/2018...
- Page 2 FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 3 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 4: Table Of Contents
Table of Contents Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Product Overview ..................3 Rear View ..............................3 Connection Ports............................4 LED Indicators............................. 5 Installation ....................5 Hardware Installation ..........................6 Operation ....................6 Available Network / IP Modes ....................... 7 Specifications ..................10 Technical Support ..................11 Warranty Information ................11... -
Page 5: Introduction
Introduction Packaging Contents • 1 x Outdoor Access Point • 1 x PoE Injector • 1 x Metal Hose Clamp • 1 x Power Adapter • 1 x Instruction Manual System Requirements • A networked computer system with a Java-enabled web browser (for configuration) •... -
Page 6: Product Overview
Product Overview Rear View LED Panel Pole/Wall Mount Bracket Interface Cover Instruction Manual... -
Page 7: Connection Ports
Connection Ports LAN 1 Ground LAN 2 Reset Button Interface Description Reset Button Press continually for 5 ~ 10 seconds to reset the device to factory defaults LAN 1 Allows LAN connection through a Category 5 (or better) cable. Supports auto-sensing for 10/100Mbps speeds and half/ full duplex LAN 2 Allows LAN connection through a Category 5 (or better) -
Page 8: Led Indicators
LED Indicators Indicator State Description The device is powered on The device is powered off Link detected No link detected Flashing Data is being transmitted / received on the WAN interface Link detected No link detected Flashing Data is being transmitted / received on the LAN interface Wireless client(s) are connected. -
Page 9: Hardware Installation
Hardware Installation 1. Connect the included power adapter to an available wall outlet and the DC jack on the PoE injector. 2. Connect an Ethernet cable from the LAN port of the PoE Injector to your LAN switch or router. 3. -
Page 10: Available Network / Ip Modes
4. Select your desired Operation Mode and click the Change Mode button to apply the change. Note: The Change Mode button will automatically jump you to the Operating Mode Settings page for the mode you have selected. In future visits to the web interface, use the Setup button located next to the mode to open that mode’s configuration page. - Page 11 5. From the Settings menu for each mode, you can access the applicable Wireless and Security settings. To configure wireless security, click the Setup button beside the Security option. Note: It is strongly recommended to configure security, to avoid unwanted access to your wireless network.
- Page 12 7. Select the System Configuration menu from the top of your screen to access IP, System Time, Password and other settings / tools. 8. To restrict access to the web interface of your AP, it is also recommended to configure a password, which can be done by selecting Password Settings from the left column of the web interface.
- Page 13 Instruction Manual...
-
Page 14: Specifications
Specifications Supported Wireless Standards IEEE802.11 a/n Chipset Atheros - AR9344 Connectors 2 x RJ45 Ethernet Female Antenna Configuration 2x2:2 (TxR:s) Antenna Type 14dBi Dual Polarization Directional Antenna Wireless Frequency Range 5.150GHz ~ 5.850GHz Wireless Bandwidth 20/40MHz 64/128 bit WEP WPA(TKIP with IEEE 802.1x) Wireless Encryption Supported WPA2(AES with IEEE 802.1x) WPA -PSK... -
Page 15: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 16 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
