SERVICE MANUAL
This Service Manual is for the
B4-M500 (ECB91ED) / B4-M501 (ECB93ED) / B4-M502 (ECB95ED) model.
For the B4-M500 (ECB91ED) / B4-M501 (ECB93ED) / B4-M502 (ECB95ED)
model, the letter (ECB91ED) / (ECB93ED) / (ECB95ED) is printed on the
Model No. Label on the back of the unit. Refer to the Model No. Label below.
Model No. Label
Blu-ray Disc Player
MODEL NO. B4-M500
"ECB91ED"
BLU-RAY DISC PLAYER
B4-M500
B4-M501
B4-M502
Model No. Label
Blu-ray Disc Player
MODEL NO. B4-M501
ECB91ED
Model No. Label
Blu-ray Disc Player
MODEL NO. B4-M502
ECB93ED
"ECB93ED"
ECB95ED
"ECB95ED"
