Pro-Form PFEVEL73908.0 User Manual page 9

7. Attach the Water Bottle Holder (65) to the
Upright (2) with two M4 x 19mm Screws (26).
8. Identify the Left Upper Body Arm (6), which is
marked with an "L" sticker.
Insert the Left Upper Body Arm (6) into an
Upper Body Leg (5); make sure that the
hexagonal holes are in the indicated
location.
Attach the Left Upper Body Arm (6) with two M8
x 45mm Button Bolts (50) and two M8 Locknuts
(38). Make sure that the Locknuts are in the
hexagonal holes. Do not tighten the Button
Bolts yet.
Repeat this step for the Right Upper Body
Arm (not shown) and the other Upper Body
Leg (not shown).
7
2
8
6
50
9
65
26
38
Hexagonal
Holes
5
