INSTRUCTION MANUAL
Angle Grinder
9067/9067S/9067L
9069/9069S
001011
DOUBLE INSULATION
IMPORTANT: Read Before Using.
1

Advertisement

   Related Manuals for Makita 9067

   Summary of Contents for Makita 9067

  • Page 1

    INSTRUCTION MANUAL Angle Grinder 9067/9067S/9067L 9069/9069S 001011 DOUBLE INSULATION IMPORTANT: Read Before Using.

  • Page 2: Specifications

    ENGLISH (Original instructions) SPECIFICATIONS Model 9067/9067S 9067L 9069/9069S Depressed center wheel diameter 180 mm 180 mm 230 mm Spindle thread No load speed (n ) / Rated speed (n) 8500 min 6600 min 6600 min Overall length 458 mm 458 mm...

  • Page 3

    Do not expose power tools to rain or wet Power tool use and care conditions. Water entering a power tool will 18. Do not force the power tool. Use the correct increase the risk of electric shock. power tool for your application. The correct Do not abuse the cord.

  • Page 4

    GEB033-4 capable stopping small abrasive workpiece fragments. The eye protection must GRINDER SAFETY WARNINGS be capable of stopping flying debris generated by Safety Warnings Common for Grinding, Sanding, various operations . The dust mask or respirator Wire Brushing, or Abrasive Cutting-Off Operations: must be capable of filtrating particles generated by This power tool is intended to function as a your operation.

  • Page 5

    point of pinching. Abrasive wheels may also break under Additional Safety Warnings Specific for Abrasive these conditions. Cutting-Off Operations: Kickback is the result of power tool misuse and/or a) Do not “jam” the cut-off wheel or apply incorrect operating procedures or conditions and can be excessive pressure.

  • Page 6

    Additional safety warnings: disconnect the tool from the mains supply 17. When using depressed centre grinding wheels, ( use non metallic objects ) and avoid be sure to use only fiberglass-reinforced damaging internal parts. wheels. 37. When use cut-off wheel, always work with the 18.

  • Page 7: Functional Description

    To start the tool, push in the lock lever and then pull the FUNCTIONAL DESCRIPTION switch trigger. Release the switch trigger to stop. For continuous operation, push in the lock lever, pull the switch trigger and then push the lock lever further in. CAUTION: To stop the tool from the locked position, pull the switch Always be sure that the tool is switched off and...

  • Page 8

    in reverse. Installing or removing cut-off wheel Installing or removing depressed center 1. Lock nut grinding wheel/Multi-disc (accessory) 2. Outer flange 78 3. Cut-off wheel 1. Lock nut 4. Inner flange 78 2. Depressed 5. Dust collecting center wheel wheel guard 3.

  • Page 9: Replacing Carbon Brushes, Optional Accessories

    Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Wheel guard (Wheel cover) • Inner flange • Depressed center wheels •...

  • Page 10

    Lock nut wrench • Cut-off wheels • Inner flange (For cut-off wheel) • Outer flange (For cut-off wheel) • Wire cup brush • Side grip • Loop handle • Dust collecting wheel guard • NOTE: Some items in the list may be included in the tool •...

  • Page 12

    Makita Corporation Anjo, Aichi, Japan www.makita.com 884183A773...
