Netis WF-2409 User Manual
  1. Manuals
  2. Brands
  3. Netis Manuals
  4. Wireless Router
  5. WF2409
  6. User manual

Netis WF-2409 User Manual

Netis 300mbps wireless n router
Hide thumbs Also See for WF-2409:
Table of Contents

Advertisement

Quick Links

WF-2409

User Manual

V1.1
1141 Budapest, Fogarasi út 77.
1095 Budapest, Mester u. 34.
2011-06-21
Tel.: *220-7940, 220-7814, 220-7959,
Tel.: *218-5542, 215-9771, 215-7550,
220-8881, 364-3428 Fax: 220-7940
216-7017, 216-7018 Fax: 218-5542
Mobil: 30 531-5454, 30 939-9989
Mobil: 30 940-1970, 20 949-2688
www.netis-systems.hu
E-mail: info@delton.hu Web: www.delton.hu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF-2409 and is the answer not in the manual?

Questions and answers

Related Manuals for Netis WF-2409

Summary of Contents for Netis WF-2409

  • Page 1: User Manual

    WF-2409 User Manual V1.1 1141 Budapest, Fogarasi út 77. 1095 Budapest, Mester u. 34. 2011-06-21 Tel.: *220-7940, 220-7814, 220-7959, Tel.: *218-5542, 215-9771, 215-7550, 220-8881, 364-3428 Fax: 220-7940 216-7017, 216-7018 Fax: 218-5542 Mobil: 30 531-5454, 30 939-9989 Mobil: 30 940-1970, 20 949-2688 www.netis-systems.hu...

  • Page 2: Fcc Statement

    WF-2409 User Manual Certification FCC CE FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 Reproduction in any manner without the permission of Netis Corporation is strictly forbidden All the information in this document is subject to change without notice.

  • Page 4: Table Of Contents

    WF-2409 User Manual Contents CONTENTS ............................3   1.   INTRODUCTION ......................... 5   1.1.   ....................... 5   RODUCT VERVIEW 1.2.   ........................5   EATURES 1.3.   ................. 6   UPPORTING TANDARD AND ROTOCOL 1.4.   ......................6  ...
  • Page 5 WF-2409 User Manual 4.4.1.   WAN..........................41   4.4.2.   LAN ..........................42   4.4.3.   DHCP ........................... 43   4.4.4.   Port settings ......................... 44   4.5.   ..........................44   IRELESS 4.5.1.   Wireless Basic ......................44  ...

  • Page 6: Introduction

    Remote Management and system log so that network administrators can manage and monitor the network in real time. WF-2409 Wireless-N Router also provides a hardware WPS (Wi-Fi protected setup) button, which helps you setup a secure wireless network in a snap. The button lets you activate the wireless protection easily 1.2.

  • Page 7: Supporting Standard And Protocol

    WF-2409 User Manual 1.3. Supporting Standard and Protocol IEEE 802.11b/g/n IEEE 802.11e IEEE 802.11h IEEE 802.11k IEEE 802.11i IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX IEEE802.3ab 1000 Base-T 1.4. Working Environment Temperature 0° to 40° C (operating) -40° to 70° C (storage)

  • Page 8: Hardware Installation

    WF-2409 User Manual 2. Hardware Installation 2.1. System Requirement Minimum Requirements: Broadband (DSL/Cable) modem and service with Ethernet port 802.11n b/g/n wireless adapter or Ethernet adapter and cable for each computer Internet Explorer® 5.0, Firefox® 2.0 or Safari® 1.4 or higher 2.2.

  • Page 9: Restore To Factory Configuration

    WF-2409 User Manual Figure 2-1 Description Function Connect to Power adapter, please don’t use the unknown power adapter, otherwise your device may be damaged. Connect with computer NIC or Ethernet device Internet access Reset Restore settings WPS settings 2.3. Restore to factory configuration If the router ever freezes in a setting change process or if you can’t access it because you can’t...
  • Page 10 WF-2409 User Manual Figure 2-2 Attach one end of an Ethernet cable to your computer’s Ethernet port, and the other end to one of the LAN ports of your router. Connect another Ethernet cable from your Cable/DSL modem to the WAN port of your router.

  • Page 11: Login

    WF-2409 User Manual 3. Login You can manage WF-2409 Wireless-N Router through the Web browser-based configuration utility. To configure the device via Web browser, at least one properly configured computer must be connected to the device via Ethernet or wireless network. The 300Mbps Wireless-N Router is configured with the default IP address of 192.168.1.1 and subnet mask of...
  • Page 12 WF-2409 User Manual Figure 3-1 2. Double click the icon Network and Dial-up Connections 3. Highlight the icon Local Area Connection, right click your mouse, and click Properties Figure 3-2 4. Highlight Internet Protocol (TCP/IP), and then press Properties button...
  • Page 13 WF-2409 User Manual Figure 3-3 5. Choose Obtain an IP address automatically and Obtain DNS server address automatically, and then press OK to close the Internet Protocol (TCP/IP) Properties window Figure 3-4 6. Press OK to close the Local Area Connection Properties window...

  • Page 14: Windows Xp

    WF-2409 User Manual Figure 3-5 3.1.3. Windows XP Please follow the steps below to setup your computer: 1. Go to Start Settings Control Panel 2. Click Network and Internet Connections Figure 3-6 3. Click Network Connections...
  • Page 15 WF-2409 User Manual Figure 3-7 4. Highlight the icon Local Area Connection, right click your mouse, and click Properties Figure 3-8 5. Highlight Internet Protocol (TCP/IP), and then press Properties button...
  • Page 16 WF-2409 User Manual Figure 3-9 6. Choose Obtain an IP address automatically and Obtain DNS server address automatically, and then press OK to close the Internet Protocol (TCP/IP) Properties window Figure 3-10 7. Press OK to close the Local Area Connection Properties window...

  • Page 17: Windows Vista

    WF-2409 User Manual Figure 3-11 3.1.4. Windows Vista Please follow the steps below to setup your computer: 1. Go to Start Settings Control Panel 2. Click Network and Sharing Center Figure 3-12 3. Click Manage Network Connections...
  • Page 18 WF-2409 User Manual Figure 3-13 4. Highlight the icon Local Area Connection, right click your mouse, and click Properties Figure 3-14 5. Highlight Internet Protocol Version 4 (TCP/IP) and then press Properties button...
  • Page 19 WF-2409 User Manual Figure 3-15 6. Choose Obtain an IP address automatically and Obtain DNS server address automatically, and then press OK to close the Internet Protocol (TCP/IP) Properties window...
  • Page 20 WF-2409 User Manual Figure 3-16 7. Press OK to close the Local Area Connection Properties window.

  • Page 21: Windows 7

    WF-2409 User Manual Figure 3-17 3.1.5. Windows 7 Please follow the steps blow to setup your computer: Go to Start→ Control Panel→ Network and Internet. Click Network and Sharing Center→ Change adapter settings. Highlight the icon Local Area Connection, right click your mouse, and click Properties.
  • Page 22 WF-2409 User Manual Figure 3-18 Figure 3-19 Choose Obtain an IP address automatically and Obtain DNS server address automatically,...

  • Page 23: Mac Os

    WF-2409 User Manual and then press the OK to close the window. Figure 3-20 Press OK to close the Local Area Connection Properties window. 3.1.6. MAC OS Please follow the steps blow to setup your computer: Go to Start→ System preference Settings→ Network.
  • Page 24 WF-2409 User Manual Figure 3-21 Click Network, Select Use DHCP at the Configuration bar, the system will get the IP address automatically. Figure 3-22...

  • Page 25: Checking Connection With The Router

    WF-2409 User Manual Press Apply to complete this operation and close the window. 3.2. Checking Connection with the Router After configuring the TCP/IP protocol, use the ping command to verify if the computer can communicate with the Router. To execute the ping command, open the DOS window and Ping the IP address of the 300Mbps Wireless-N Router at the DOS prompt: For Windows 98/Me: Start →...

  • Page 26: Login

    WF-2409 User Manual Request timed out. Request timed out. Request timed out. Request timed out. Ping statistics for 192.168.1.1: Packets: Sent = 4, Received = 0, Lost = 4 (100% loss), Verify your computer's network settings are correct and check the cable connection between the router and the computer.
  • Page 27 WF-2409 User Manual Figure 3-19 After you have logged in, the router's user interface will be displayed. The left menu shows the main options to configure the system, and the right screen is the summary information for viewing and adjusting the configurations.

  • Page 28: Router Setup

    WF-2409 User Manual 4. Router Setup 4.1. System Information This feature provides running status information and detailed information about router. 4.1.1. System Info Show current running information of System. Figure 4-1 4.1.2. This feature provides running status information of the WAN port (the port connect to the...

  • Page 29: Lan Info

    WF-2409 User Manual Figure 4-2 Connection Type: Display router’s current connection type, It should be one of “PPPoE”, “DHCP”, “Static IP”, depending on what kind of connection type your ISP provides. MAC Address: The physical address of WAN port, this is a unique address assigned by manufacturer.

  • Page 30: Wireless

    WF-2409 User Manual Figure 4-3 4.1.4. Wireless This item provides current running information of wireless. Figure 4-4 Wireless status: Display wireless interface status is enabled or not SSID: SSID (Service Set Identifier) is your wireless network's name shared among all points in a wireless network.

  • Page 31: Host Monitoring

    WF-2409 User Manual 4.1.5. Host Monitoring This item provides current running information of Host Figure 4-5 4.1.6. Traffic Statistics This item provides statistics information about the bits router sends and received. Figure 4-6 4.1.7. Statistics This item provides statistics information about System log...

  • Page 32: Quick Setup

    WF-2409 User Manual Figure 4-7 4.2. Quick Setup Providing you the convenient and simplest method for configure the router, the purpose of this item is to provide an easy way for you to use it and configure your router to access the Internet quickly;...

  • Page 33: Pppoe

    WF-2409 User Manual 4.2.2. PPPoE Figure 4-9 If your ISP provides you the PPPoE service (all ISP with DSL transaction will supply this service, such as the most popular ADSL technique), please select this item. In the “Convenient configuration” You can input your PPPoE username and password to access the Internet.

  • Page 34: Static Ip + Pptp Client

    WF-2409 User Manual server)” according to the information provided by your ISP. And every IP address should be input in appropriate IP field, a IP address only divided into four IP octets by sign“.” is acceptable. IP address: The IP address that your Internet access into...

  • Page 35: Static Ip + L2Tp Client

    WF-2409 User Manual configuration” You can input your PPTP Server, username and password to access the Internet. Server The Server IP address that your Internet access into IP Address The Local IP address that your Internet access into Subnet mask...

  • Page 36: Wireless Configuration

    WF-2409 User Manual IP Address The Local IP address that your Internet access into Subnet mask Subnet mask Specify a Subnet Mask for your WAN segment Default gateway It is provided by your ISP Primary DNS DNS server is used for resolve domain name. Your ISP will provides you with at least one DNS...

  • Page 37: Wps Settings

    WF-2409 User Manual The item allows you to encrypt your wireless communication, and you can also protect your wireless network from unauthorized user access. It supplies “None”, “WEP”, “WPA-PSK”, “WPA2-PSK” and “WPA/WPA2-PSK” five different encryption modes. And you can also use WPS function and then it will be encrypted to WPA2-AES mode automatically 4.3.
  • Page 38 WF-2409 User Manual WPS Configuration: display the encryption information WPS can connect the wireless adapter and the router in a safe way. If you have a wireless network card which has WPS button, you may set up a safe network via the following methods Method 1: 1.
  • Page 39 WF-2409 User Manual Method 3: 1. Input the PIN code of the adapter’s WPS page into the router’s WPS configure page, then click ’connect’ Figure 4-1 Figure 4-17 2. Push the ‘PIN Input Config (PIN)’ in the Wi-Fi protect setup of the adapter Figure 4-18 3.
  • Page 40 WF-2409 User Manual Figure 4-19 4. Please wait until the following window appears, the connect between the adapter and the router will connect automatically Figure 4-20 Method 4: 1. Click ‘connect’ in the router’s WPS PBC configure page Figure 4-21...
  • Page 41 WF-2409 User Manual following picture appears Figure 4-22 3. The next is the safe connection between the adapter and the router, please wait 4. The connect between the adapter and the router is success Method 5: 1. Select ‘Input PIN from AP’ in WI-FI protect setup page, input PIN of the router, then click ‘PIN Input Config (PIN)’...

  • Page 42: Network

    WF-2409 User Manual 3. Please wait until the following window appears, the connect between the adapter and the router will connect automatically Figure 4-25 Remark If there is more than one AP in the PBC mode when you use the method 1/2/4, there will be session overlap.

  • Page 43: Lan

    WF-2409 User Manual Figure 4-26 IP address: The IP address you obtained after connect to the Internet, if you haven’t connected to the Internet yet, this field is 0.0.0.0. Subnet Mask: The Subnet mask you obtained after connect to the Internet, if you haven’t connected to Internet yet, this field is 0.0.0.0.

  • Page 44: Dhcp

    WF-2409 User Manual Figure 4-27 4.4.3. DHCP Figure 4-28 DHCP Server Status Keep the default setting “Enable”, so router is able to use DHCP function. If a DHCP server has already existed in the network, please select “Disable”. IP Address Pool The IP Address pool is used for allocate IP address by DHCP server;...

  • Page 45: Port Settings

    WF-2409 User Manual 4.4.4. Port settings Show current running information of Interface Mode, Default settings is auto. Figure 4-29 4.5. Wireless 4.5.1. Wireless Basic Providing basic configuration items for wireless router users, including “wireless network status”, “SSID”, “Radio Band”, “Radio Mode”, “MAC”, “SSID broadcasting”, “Channel...
  • Page 46 WF-2409 User Manual Figure 4-30 Wireless status: You can choose “enable” or “disable” to enable or disable the “Wireless Network Status”, if what you choose is “Disable”, the AP function of wireless router will be turned off. SSID: The default is trst1.

  • Page 47: Wireless Security

    WF-2409 User Manual pure router, draft 802.11n wireless network. Channel sideband: It controls your wireless router use higher or lower channel when working on 40MHz. Region: please select the region where you live in. Channel: In 20MHz, you can select one channel from 1 to 13 manually, and in 40MHz, you can select one channel from 1 to 9 or 5 to 13, which provides a choice of avoiding interference.

  • Page 48: Wep

    WF-2409 User Manual 4.5.2.2. Figure 4-32 Key Length: There are two basic levels of WEP encryption, 64 bits and 128 bits, the more bits password have, the better security wireless network is, at the same time the speed of wireless is more slower.

  • Page 49: Wpa-Psk

    WF-2409 User Manual 4.5.2.3. WPA-PSK Figure 4-33 Encryption type: You can select the algorithm you want to use, TKIP, AES or TKIP&AES. TKIP means “Temporal Key Integrity Protocol”, which incorporates Message Integrity Code (MIC) to provide protection against hackers. AES, means “Advanced Encryption System”, which utilizes a symmetric 128-Bit block data.

  • Page 50: Wireless Mac Filter

    WF-2409 User Manual Figure 4-35 4.5.3. Wireless MAC Filter Figure 4-36 Access Control Status: the default is disable. You can filter wireless users by enabling this function; thus unauthorized users can not access the network. Rule: you can select permit or deny. The default is permit.

  • Page 51: Wds Settings

    WF-2409 User Manual **-**-**-**-**-**（e.g.: 00-22-33-da-cc-bb）. Follow the following steps to set Wireless Access Control: 1. Enable Wireless MAC Address Filter, then select save. 2. Add MAC address you want to control in the “MAC address” field (the format is **-**-**-**-**-**), then click “Add” button, and you will see the MAC address has displayed in the MAC list.
  • Page 52 WF-2409 User Manual keyboard. Figure 4-38 AP1: Select radio mode is WDS or AP+WDS in wireless base of AP1. Click on ‘Wireless’- ‘Wireless Security’ and select and save None as authentication type. Click on ‘Wireless’- ‘WDS Settings’ ,Input WDS name (e.g.: default), input MAC address of AP2 (00-22-4f-bc-af-5d), click add, then the record named default will appears in WDS list.

  • Page 53: Repeater Settings

    WF-2409 User Manual 4.5.5. Repeater Settings Wireless Repeater mode, is used to relay the wireless signal from a relay point to the next point, relay and amplify the signals and form a new wireless coverage area. Figure 4-39 AP1: Select radio mode is ‘Access Point’ in wireless base of AP1.
  • Page 54 WF-2409 User Manual Figure 4-40 AP2: Select radio mode is ‘REPEATER’ in wireless base of AP2. Click ‘AP Scan’ in wireless base of AP2 ,and select ‘Netis1’ and Connect , then the ‘Repeater SSID’ and ‘ ’ become same as AP1.

  • Page 55: Wireless Advanced

    WF-2409 User Manual Figure 4-41 AP3: Select radio mode is ‘REPEATER’in wireless base of AP3. Click ‘AP Scan’ in wireless base of AP3 ,and select ‘Netis1’ and Connect , then the ‘Repeater SSID’ and ‘Channel’ become same as AP2. The IP address of AP3 should be 192.168.1.x (1<x<255),but different from AP2.
  • Page 56 WF-2409 User Manual Figure 4-42 Authentications type: The default is set to “Auto”, which allows “Open System” or “Shared Key” authentication to be used. Select “Shared Key” if you only want to use “Shared Key” authentication (the sender and recipient use a WEP key for authentication).

  • Page 57: Multiple Ap Settings

    WF-2409 User Manual Preamble Type: "Short Preamble" is suitable for heavy traffic wireless network. "Long Preamble" provides much communication reliability; the default setting is "Long Preamble”. 4.5.7. Multiple AP Settings The default status of secondary AP is disab le, you can select enable to enable the secondary AP.
  • Page 58 WF-2409 User Manual Figure 4-45 Intelligent QoS Status: QoS switch. WAN line bandwidth:WAN bandwidth control Status: Application priority setup control. Priority: use a number to define the application priority,The smaller number has higher priority LAN host: Set the LAN host IP, you can define “all Host”,”Specific Host”,”Host subnet”...

  • Page 59: Host Bandwidth Control

    WF-2409 User Manual 4.6.2. Host Bandwidth control Figure 4-46 Uplink Speed: set host uplink bandwidth Downlink Speed: set host downlink bandwidth Maximum connection numbers: set the Maximum connection numbers IP Address: Set the IP address range for restricted hosts.

  • Page 60: Forwarding

    WF-2409 User Manual 4.7. Forwarding 4.7.1. Virtual Servers Figure 4-47 Description: Describe current virtual server item Internal Host IP Address: The “Internal Host IP Address” indicates IP address of the internal host using virtual server. Templates: The templates item supplies several protocols. For example, if you have web server within LAN, you can select the HTTP template then the router will input port number 80 automatically.

  • Page 61: Dmz

    WF-2409 User Manual Figure 4-48 4.7.3. DMZ opens all the ports of one computer, exposing the computer to the Internet. So it should only be used for some special-purpose, especial for Internet online games. Using this function you can select “DMZ” item and input IP address of DMZ host, then click “Save”. For the purpose of security, we suggested that using “Virtual servicer”...

  • Page 62: Security Setup

    WF-2409 User Manual “Enable” to enable this function. Figure 4-50 4.8. Security Setup 4.8.1. IP/MAC bind Figure 4-51 Bind mode: define the bind mode ,you can select manually add, auto binding or export/import TXT file of ARP. Rule Name: define name for this rule...

  • Page 63: Ip Filtering

    WF-2409 User Manual 4.8.2. IP Filtering Figure 4-52 Status: the default is disable. The rules of “Internet access control” based on source IP, port number and protocol. Description: describe IP Firewall list to tell from different IP Firewall lists. Rule: you can select permit or deny. The default is permit.

  • Page 64: Mac Filtering

    WF-2409 User Manual 1. You can select “enable” and click “Save” to enable “IP Address Filtering” function. This is only the first step, you should continued to create appropriate rules for “IP Address Filtering”. 2. Input description information for current access control rule in the “Description” field. Input IP address of host you want to restrict.

  • Page 65: Domain Filtering

    WF-2409 User Manual **-**-**-**-**-**（e.g.: 00-22-33-da-cc-bb） Follow the following steps to set MAC filter: 1. Enable MAC Filter, then select save. 2. Add MAC address you want to control in the “MAC address” field (the format is **-**-**-**-**-**), then click “Add” button, and you will see the MAC address has displayed in the MAC list.

  • Page 66: Advance

    WF-2409 User Manual field, such as www.163.com. Follow these steps to set Domain filter: 1. You can select “enable” and click “Save” to enable “Domain Filter” function. This is only the first step, you should continued to create appropriate rules for “Domain Filter”.

  • Page 67: Dynamic Dns

    WF-2409 User Manual address for local host) that allows forwarding data between router and remote network or host. Routing Table: You can check out all current route items, click “delete” button to delete an route item existed in routing table.

  • Page 68: Port Triggering

    WF-2409 User Manual Figure 4-57 4.9.4. Port Triggering Port trigger module dynamically registers virtual server rules when any IP host generates the packet from the specified trigger protocol and port. Port trigger module use forward protocol type and port number and use the IP address of host that generates the trigger packet when it registers a rule.

  • Page 69: Vpn Settings

    WF-2409 User Manual Trigger Port: you can select a part of ports. Forward Protocol: you can select TCP/UDP. Forward Port: you can select a part of ports. 4.9.5. VPN Settings VPN is commonly used for encapsulate and encrypt data across the public network. For VPN tunnel, the router supports IPSEC pass-through, PPTP pass-through and L2TP pass-through.

  • Page 70: Firmware

    WF-2409 User Manual 4.10.1. Firmware Click "Browse..."button and select a File to upgrade, after you have selected the appropriate file, click "Upgrade" button to execute upgrade procedure. Do not cut off the power supply during the process of upgrading. Figure 4-61 4.10.2.

  • Page 71: Remote Management

    WF-2409 User Manual Figure 4-63 4.10.4. Remote Management WEB Management Status: the default is disable. Router can be accessed on the remote site using “Web setup”. Check the “Management Port” and enter the port number and then press “save” button to enable web management.

  • Page 72: Reboot

    WF-2409 User Manual Figure 4-65 4.10.6. Reboot Click “Reboot” button to restart the router. Figure 4-66 5. Troubleshooting 1. I cannot access the Web-based Configuration Utility from the Ethernet computer used to configure the router. Check that the LAN LED is on. If the LED is not on, verify that the cable for the LAN connection is firmly connected.
  • Page 73 WF-2409 User Manual Please follow the following steps to check the problems: Check whether the DSL modem works well or the signal is stable. Normally there will be some indicator lights on the modem, users can check whether the signal is ok or the modem works well from those lights.
  • Page 74 WF-2409 User Manual settings of the remote computer.
