How To Assemble; Features - Hoover Power Scrub Owner's Manual

note: PHILLIPS SCREWDRIVER NEEDED FOR ASSEMBLy.
attaCH HandLe
1. Position upper handle and slide down into carpet
washer base (Fig. 2)
2. Insert both screws and tighten with screwdriver
(Fig. 3).
pLaCe soLution/ Water tank
3. Position bottom of tank onto Carpet Washer
(Fig. 4).
4. Push tank handle while supporting back of
cleaner with other hand until Solution Tank
clicks into place (Fig. 5).
5. Check to make sure tank is securely latched.
2
5
actual model may vary from images shown.

HoW to asseMbLe

3
6
6
store tooLs
6. Place tools and hose into Mesh Tool Storage
bag provided.
7. Mesh Tool Storage Bag should not be hung on
the Carpet Washer while the Carpet Washer is
in use.
8. Mesh Tool Storage Bag can be conveniently
stored either on the back of the unit or hung
elsewhere by the provided hook (Fig. 6).
Cord storage
9. Wrap cord around cord hooks for convenient
storage. Attach the plug end to cord.
4
