MIX FEATURES > AUDIO INTERROGATE
Audio Interrogate is a powerful method of checking and changing a particular switch status across
all channels on the currently selected fader layer. For example, you can check at a glance which
channels are routed to the main LR mix bus and change that status rapidly for all visible channels.
Audio Interrogate works for all status buttons on the Assignable Channel Strip:
48v ON/OFF
Phase Reverse ON/OFF
HPF IN/OUT
GATE IN/OUT
COMPressor IN/OUT
EQ IN/OUT
LR routing ON/OFF
MONO routing ON/OFF
To Interrogate an ACS switch status:
1) Select a Fader Layer (FADERS) relevant to the switch status you wish to interrogate (for example, to interrogate LR
routing of input channels, the current Fader Layer must include input channels).
2) Press and hold the ACS button for the chosen function (HPF, GATE, EQ, LR, and so on).
The SEL (Select) buttons of any channels where that function is active will light.
3) While holding the relevant ACS button, you can use the SEL buttons across that Fader Layer to change the status
for each channel.
For example, if you select a Fader Layer containing input channels and you hold the 48V button down, the SEL but-
tons of any channels that have 48V Phantom Power enabled will illuminate. If you continue to hold the 48V button, you
can then press the channel SEL buttons across the Fader Layer to toggle 48V on or off for each channel.
User Manual
8.3: AUDIO INTERROGATE
8.3: MIX FEATURES > INTERROGATE
