- Page 1 IN THIS GUIDE YOU WILL LEARN HOW TO HOOK UP YOUR NIFTY NEW ADAPTOR IN NO TIME THE INCREDIBLY EASY GUIDE TO CONNECTING YOUR NEW POWERLINE ADAPTOR TO YOUR SET TOP BOX...
- Page 2 • Identify a power point near your modem to plug the White Adaptor (A) into. • Identify a power point near your Optus TV Set Top Box to plug the Black Adaptor (C) into. • Ensure you have easy access to the power points and existing modem for setup.
- Page 3 CONNECT THE WHITE STEP 1 ADAPTOR TO YOUR MODEM BITS YOU’LL NEED: WHITE ADAPTOR ETHERNET CABLE Go to the room with your existing modem. Plug one end of the Ethernet Cable (B) into the Ethernet port located at the top of the White Adaptor (A). Plug the other end into a spare Ethernet port on your existing modem.
- Page 4 Black Adaptor (C). Plug the other end into the port labelled ‘RJ45’ on the back of the Optus TV Set Top Box. Plug the Power Cord (D) into the Black Adaptor (C). Plug the other end into a power point near the Set Top Box.
- Page 5 IF OK: SET TOP BOX GUIDE If all of the above have been checked, your internet connection should be set up correctly. Go back to Step 2 in your Set Top Box Quick Install Guide to finish setting up Optus TV.
- Page 6 IT SHOULD LOOK SOMETHING LIKE THIS BITS YOU’LL NEED: WHITE ADAPTOR ETHERNET CABLE BLACK ADAPTOR POWER CORD ETHERNET CABLE THE ROOM WITH YOUR MODEM THE ROOM WITH YOUR SET TOP BOX AND TV INTERNET DELIVERED THROUGH YOUR POWER LINES YOUR MODEM SET TOP BOX...
- Page 7 WAIT, I NEED HELP! GOT ANY ISSUES, PROBLEMS OR HEAD-SCRATCHERS? Q. What if I don’t have a spare Ethernet port Q. Why does the Powerline light on my device on my modem? appear to be yellow or red in colour? A.
- Page 8 SO FAR HAS LED TO THIS MOMENT WE HAVE FAITH THAT YOU CARRIED OUT YOUR TASK SPLENDIDLY. BUT, IN CASE YOU NEED A LITTLE HELP, PLEASE CONTACT OUR OPTUS TV TECHNICAL SUPPORT AT 133 937 OR VISIT OPTUS.COM.AU/OPTUSTV/PLCINSTALL OPTUS16702/1400330 (08/13)
