Local IP / Subnet Mask
Remote IP / Subnet
Mask
More Remote Subnet
H o w t o
H o w t o
The IPSec services can provide access control, connectionless integrity, data origin
authentication, rejection of replayed packets that is a form of partial sequence integrity, and
confidentiality by encryption. These objectives are met through the use of two traffic
security protocols, the Authentication Header (AH) and the Encapsulating Security Payload
(ESP), and through the use of cryptographic key management procedures and protocols.
1. Open VPN and Remote Access >> VPN Profiles.
2. Simply click the Add button.
3. The following dialog will appear. Click the Basic tab to configure the settings.
Vigor2960 Series User's Guide
Display the LAN IP address with subnet mask of this profile.
Display the WAN IP address with subnet mask of this
profile.
Display other LAN IP addresses with subnet mask which can
be used of this profile.
c r e a t e a n I P S e c V P
c r e a t e a n I P S e c V P
N p r o f i l e
N p r o f i l e
