2.1.2 Configuration

The Configuration button gives access to the main menu. Pressing this button will cause the
cutter to go offline and suspend all operations in progress. The main menu contains all
submenus and access to tests and calibration routines.
The chosen tool will influence the configuration displayed.
Settings: This menu offers access to different submenus that allow configuration of the
cutter's operating parameters. Access to some of the submenus will be determined by
plotting language or tool type.
Tests & Setup: This menu offers access to the different internal tests and calibration
routines. The calibration routines are used to adjust and fine-tune the cutter for the chosen
application. The internal tests are used for diagnostics.
Knife (pen or pounce) pressure: This menu allows users to set or modify the cutting
pressure of the current tool.
Knife offset: This menu allows users to set or modify the distance between the tip of the
knife and the axis. The default knife offset value is .45 mm. Knife offset is only displayed
when the chosen tool is a drag knife.
Pouncing gap: The pouncing gap parameter is used to set or modify the distance
between the pounced holes. Pouncing gap only applies when the machine is in "pounce"
mode.
Velocity: The velocity is used to set or modify the velocity of the tool.
User Selection: The S CLASS™ cutters include 8 user configurations, all of which consist of
the same parameters. Each configuration can have unique parameter settings. This allows
the cutter to be quickly and easily reconfigured for different types of jobs or media. The
touch screen can be used to change the user. However, user configuration names can only
be modified through Summa Cutter Control.
