- Page 1 TechNotes V2.0 Industrial Mainboards D3071-S / D3076-S...
-
Page 2: Table Of Contents
Content Safety Instructions Feature Overview D307x-S Basic Layout Block Diagram External Connectors D3071-S External Connectors D3076-S Onboard components D3076-S Onboard components D3071-S I/O-Shield Interfaces & Connectors Frontpanel Connector Internal Parallel Port Connector Internal COM2 Connector Internal USB Connector (2 x 2 Ports) - Page 3 Known Issues & Important Notes Windows XP Installation in AHCI mode – necessary adjustments RAID / AHCI driver disk installation (Windows XP) from floppy disk Miscellaneous 10.1 System Watchdog (WD) 10.2 BIOS Update / BIOS Recovery TechNotes D307x-S V2.0 Page 3 of 56 www.ts.fujitsu.com/mainboards...
-
Page 4: Safety Instructions
I/O connectors) until the mainboard is completely powered down. Any damage caused to the mainboard by misuse of the onboard connectors is excluded from the standard warranty. Fujitsu Technology Solutions cannot be held liable for any damage that results from incorrect use of any onboard connectors. -
Page 5: Feature Overview D307X-S
• Four memory sockets DDR3/1333 supporting up to 32GB 15µ gold plating for improved durability and reliability • • Dual Intel Gbit LAN onboard • Link Aggregation support (Teaming, Bonding) • iAMT support TechNotes D307x-S V2.0 Page 5 of 56 www.ts.fujitsu.com/mainboards... - Page 6 • PCI Express Gen2 • State-of-the-art performance provided by all PCIe extension slots 5.1 multichannel audio onboard • • 8-Bit GPIO onboard • 6-Layer PCB (Tin Plating) • Improved electrical signal quality • Improved durability TechNotes D307x-S V2.0 Page 6 of 56 www.ts.fujitsu.com/mainboards...
- Page 7 Designed & approved for enhanced operating temperature range from 0°C to 60°C Designed & approved for 24/7 continuous operation High Efficient core voltage regulator design (89% @ 65W, 86% @ 95W) Extended lifecycle up to 5 years TechNotes D307x-S V2.0 Page 7 of 56 www.ts.fujitsu.com/mainboards...
- Page 8 Easy SW integration via Windows API Pin layout compatible with D2703-S, D2963-S, D3003-S Hardware Watchdog Incl. BIOS/Boot and OS supervision Easy SW integration via Windows API & Linux Driver TechNotes D307x-S V2.0 Page 8 of 56 www.ts.fujitsu.com/mainboards...
-
Page 9: Basic Layout
Feature Overview D307x-S 2.1 Basic Layout TechNotes D307x-S V2.0 Page 9 of 56 www.ts.fujitsu.com/mainboards... -
Page 10: Block Diagram
Feature Overview D307x-S 2.2 Block Diagram 2 DIMM Sockets Memory Bus Channel A DDR 3 with 1066/1333 LGA1155 CPU 2 DIMM Sockets Memory Bus Channel B DDR 3 with 1066/1333 PCIe x16 PCIe x16 Slot FDI-Link DMI Link Intel Ethernet1 Intel PCIe Link... -
Page 11: External Connectors D3071-S
Feature Overview D307x-S 2.3 External Connectors D3071-S Audio LAN1; 2 x USB 2.0 LAN2; 2 x USB 2.0 COM1; DVI-I DisplayPort 4 x USB 2.0 PS/2 Kbd-Mouse... -
Page 12: External Connectors D3076-S
Feature Overview D307x-S 2.4 External Connectors D3076-S Audio LAN1; 2 x USB 2.0 LAN2; 2 x USB 2.0 COM1; DVI-I DisplayPort 4 x USB 2.0 PS/2 Kbd-Mouse TechNotes D307x-S V2.0 Page 12 of 56 www.ts.fujitsu.com/mainboards... -
Page 13: Onboard Components D3076-S
Parallel Port Frontpanel Audio 12V Supply (Processor) Socket for USB Stick 6 Layer PCB 4 x PCI PCIe x16 (16 Lanes, Gen2) PCIe x8 (1 Lane, Gen2) TechNotes D307x-S V2.0 Page 13 of 56 www.ts.fujitsu.com/mainboards PCIe x16 (4 Lanes, Gen2) -
Page 14: Onboard Components D3071-S
Feature Overview D307x-S 24 pin ATX PS 2.6 Onboard components D3071-S SCSI LED Frontpanel 2 x SATA III 8 Bit GPIO 4 x SATA II PS Fan Control 1 x USB (Flashdrive) 4 x DDR3 (15µ gold plating) 2 x USB... -
Page 15: I/O-Shield
Feature Overview 2.7 I/O-Shield Spring Steel Sheet (front view) Enforcement Sheet Spring Steel Sheet (rear view) Gasket = Foam with Aluminium TechNotes D307x-S V2.0 Page 15 of 56 www.ts.fujitsu.com/mainboards... -
Page 16: Feature Overview
FTS IO shield. Nominal force: ~ 150 – 200 N for specified ATX IO “letterbox” Note: ATX Chassis “letterbox” for I/O shield: Nom. size = 158.75 x 44.45mm Tolerance = +/- 0.2mm TechNotes D307x-S V2.0 Page 16 of 56 www.ts.fujitsu.com/mainboards... -
Page 17: Interfaces & Connectors
Cathode: Pin14 – output (4mA) HDD LED: Anode: Pin 1 – 365R Pullup to 5V Cathode: Pin 3 – output (6mA ; ~ 0.7V low level) Speaker Output: Differential audio signal; max. 0.5W / 8Ohm TechNotes D307x-S V2.0 Page 17 of 56 www.ts.fujitsu.com/mainboards... -
Page 18: Internal Parallel Port Connector
Interfaces & Connectors 3.2 Internal Parallel Port Connector optional Parallelport cable with ATX bracket 3.3 Internal COM2 Connector optional COM2-cable with ATX bracket TechNotes D307x-S V2.0 Page 18 of 56 www.ts.fujitsu.com/mainboards... -
Page 19: Internal Usb Connector (2 X 2 Ports)
Interfaces & Connectors 3.4 Internal USB Connector (2 x 2 Ports) 3.5 Internal USB Flash Drive Connector (1 port) 3.6 Internal USB Stick Connector (1 port) TechNotes D307x-S V2.0 Page 19 of 56 www.ts.fujitsu.com/mainboards... -
Page 20: Fan Connector
In 3-wire mode, the default minimum operating voltage is set to ~ 6V. 3.8 Power Supply Fan Connector Note: This feature is not supported by standard ATX power supplies! Fan4 and PS Fan connector must not be used simultaneously! TechNotes D307x-S V2.0 Page 20 of 56 www.ts.fujitsu.com/mainboards... -
Page 21: High Definition Frontpanel Audio Connector (Hd Audio)
Note: In case of using this connector in AC97 = Legacy mode (BIOS Setting) take care for pin 7. This pin is tied to GND. HP_ON# signaling on this pin is not supported. TechNotes D307x-S V2.0 Page 21 of 56 www.ts.fujitsu.com/mainboards... -
Page 22: Power Supply Connector
Interfaces & Connectors 3.11 Power Supply Connector 3.12 Additional Power Supply Connector TechNotes D307x-S V2.0 Page 22 of 56 www.ts.fujitsu.com/mainboards... -
Page 23: Gpio Connector
VCC_5V VCC_12V VCC_12V GPIO access is provided via the SM-Bus controller PCA9554A Parameter Range ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Indu GPI/O Input Low Voltage -0.5V … 0.8V strial&ExtendedLifetime/D3071-S_D3076-S/Documentation/Specifications/GP IO_Chip_PCA9554a.pdf GPI/O Input High Voltage 2V … 3.3V Note: SM-Bus address: 0x78h (8-bit) GPI/O Output Low Voltage max. -
Page 24: Chassis Intrusion
BIOS POST if an intrusion event has been detected. In order to continue, the Supervisor Password must be entered to confirm the intrusion event. The intrusion status can be easily monitored by using the BMCAPI (Windows): ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D3071-S_D3076-S/IndustrialTool s_D307x-S/BMC_Management-Controller-API/ TechNotes D307x-S V2.0 Page 24 of 56... -
Page 25: System Monitoring
4 System Monitoring - Temperature Sensors and Fans - SystemGuard: Fan / Temperature Monitor - SilentFanConfig-Manager - Thermography D307x-S - Temperature Reference Points TechNotes D307x-S V2.0 Page 25 of 56 www.ts.fujitsu.com/mainboards... -
Page 26: D307X-S: Temperature Sensors And Fan Connectors
Note: Do not attach more than one fan per connector! Selectable via BIOS Setup Selectable via BIOS Setup Remove or connect fans only when unit is powered off! (Default = PWM) TechNotes D307x-S V2.0 Page 26 of 56 www.ts.fujitsu.com/mainboards... -
Page 27: D307X-S: Systemguard
User can configure fan aging control • (menu “Special”) • User can configure system watchdog (menu “Special”) User can adjust system behaviour via “Silent PC / Performance PC” slider by forced processor throttling TechNotes D307x-S V2.0 Page 27 of 56 www.ts.fujitsu.com/mainboards... -
Page 28: D307X-S: Systemguard - Details
1) Note: As Intel has replaced the analogue processor „diode“ temperature measurement by the digital „PECI“ measurement (Platform Environment Control Interface) which does no longer provide the absolute processor temperature, SystemGuard can only display the processor´s temperature range. TechNotes D307x-S V2.0 Page 28 of 56 www.ts.fujitsu.com/mainboards... -
Page 29: Silentfanconfigmanager - Customize System Monitoring Settings
4.4 SilentFanConfigManager – Customize System Monitoring Settings Windows-based System Management Configuration Tool ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D3071-S_D3076-S/IndustrialTools_D307x-S/SilentFanConfig-Manager/ 1. Windows-based configuration tool (SilentFanConfig) to create customized system monitoring settings like minimum fan speed and temperature sensor influence. These customized settings are stored in a specific “SMCO” flash file. - Page 30 System Monitoring SilentFanConfigManager – Customize System Monitoring Settings Basic fan settings: Adjust minimum fan startup speed (BIOS default D307x-S: 30% for all fans) Enable/disable mainboard fan speed control TechNotes D307x-S V2.0 Page 30 of 56 www.ts.fujitsu.com/mainboards...
- Page 31 “Red dot” indicates that sensor x controls fan y Due to safety reasons this is fully controlled BIOS default settings D307x-S: by the system BIOS! All sensors active, except for CPU sensor (controls CPU fan and fan4 only) TechNotes D307x-S V2.0 Page 31 of 56 www.ts.fujitsu.com/mainboards...
-
Page 32: Components For Continous Operation @ 60°C
All onboard electrolyte (e.g. 2.000hrs) capacitors: Polymer type only Solid Electrolyte: to = 105°C (= solid electrolyte) tx = capacitor surface temperature Fluid Electrolyte: (e.g. 75°C) TechNotes D307x-S V2.0 Page 32 of 56 www.ts.fujitsu.com/mainboards Sample picture: Processor Core Voltage Regulator) -
Page 33: Capacitor Endurance Time Comparison
System Monitoring 4.6 Capacitor Endurance Time Comparison TechNotes D307x-S V2.0 Page 33 of 56 www.ts.fujitsu.com/mainboards... -
Page 34: Thermography D307X-S
System Monitoring 4.7 Thermography D307x-S TechNotes D307x-S V2.0 Page 34 of 56 www.ts.fujitsu.com/mainboards... -
Page 35: Temperature Reference Points D307X-S
60°C. Operation between 60°C and 70°C may result in: Audio Codec max. 70°C - Higher self discharge rate - Decline of specified characteristics - Danger of leakage increases Inductor max. 90°C TechNotes D307x-S V2.0 Page 35 of 56 www.ts.fujitsu.com/mainboards... -
Page 36: Power Supply
1) The ATX power supply should support the minimum load conditions as mentioned in the chart. Note: The max. mainboard current in the chart doesn´t include the power for optional adapters and drives! TechNotes D307x-S V2.0 Page 36 of 56 www.ts.fujitsu.com/mainboards... -
Page 37: Display Options
6 Display Options 6.1 VGA Output DVI-VGA Interface optional: Audio Connector max. VGA screen resolution: 1920 x 1200 Analog (VGA) Monitor TechNotes D307x-S V2.0 Page 37 of 56 www.ts.fujitsu.com/mainboards... -
Page 38: Dvi Output
Display Options 6.2 DVI Output optional: Audio max. DVI screen resolution: 1920 x 1200 Digital (DVI) Monitor Note: DVI supports Single Link only! TechNotes D307x-S V2.0 Page 38 of 56 www.ts.fujitsu.com/mainboards... -
Page 39: Hdmi Output
6.3 HDMI Output DVI-HDMI Interface Connector HDMI max. HDMI screen resolution: 1920 x 1200 Digital (HDMI) Monitor HDMI transfers Video & Audio Note: HDMI Audio Device needs to be enabled via Control Panel! TechNotes D307x-S V2.0 Page 39 of 56 www.ts.fujitsu.com/mainboards... -
Page 40: Displayport Output
Display Options 6.4 DisplayPort Output Display Port max. DP screen resolution: 2560 x 1600 Digital (DisplayPort) Monitor TechNotes D307x-S V2.0 Page 40 of 56 www.ts.fujitsu.com/mainboards... -
Page 41: Dual Dvi Output
Display Options 6.5 Dual DVI Output Digital (DVI) Monitor 1 DisplayPort- DVI-Converter Cable Dual Independent Display / Extended Desktop Digital (DVI) Monitor 2 TechNotes D307x-S V2.0 Page 41 of 56 www.ts.fujitsu.com/mainboards... -
Page 42: Multi Monitor Output
Display Options 6.6 Multi Monitor Output Digital (DVI) Monitor 1 Digital (DVI) Monitor 2 Digital (DVI) Monitor 3 DisplayPort- DVI-Converter Cable Digital (DVI) Monitor 4 Simultaneous use of internal Graphics and PCIe Graphics TechNotes D307x-S V2.0 Page 42 of 56 www.ts.fujitsu.com/mainboards... -
Page 43: Operating System Support
7 Operating System Support - Windows® XP - Windows® 7 - Linux TechNotes D307x-S V2.0 Page 43 of 56 www.ts.fujitsu.com/mainboards... -
Page 44: Support For Windows Xp / Windows 7
• Mainboard D307x-S is designed according to the Microsoft Guidelines for Windows XP and Windows 7 MS certified drivers (32/64 Bit) are available via OEM DU-DVD • and OEM FTP Server ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D3071-S_D3076-S/Drivers_D3071-S_D3076-S/ TechNotes D307x-S V2.0 Page 44 of 56 www.ts.fujitsu.com/mainboards... -
Page 45: Linux Status
Save to RAM failed failed failed PS/2 Devices not tested not tested not tested not tested not tested not tested Audio Playback Audio Recording failed failed failed failed failed not tested failed (external source) TechNotes D307x-S V2.0 Page 45 of 56 www.ts.fujitsu.com/mainboards... -
Page 46: Mainboard Tools
8 Mainboard Tools Common Mainboard Tools 8.1 BIOS Boot Logo Tool - Tool to integrate a customized boot logo ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Services/Software&Tools/Common-Mainboard-Tools/BootLogo_4_UEFI/ 8.2 EditCMOS - DOS-based production tool to change BIOS settings and freeze customized BIOS settings (= customized default settings) ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Services/Software&Tools/Common-Mainboard-Tools/EditCMOS_UEFI/ 8.3 OEMIDENT... -
Page 47: Systemguard
Mainboard Tools 8.4 SystemGuard - Windows-based tool to monitor temperatures and fan speed of FTS mainboards - Option to configure automatic fan ageing supervision - Provides access to the System Watchdog ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Services/Software&Tools/Common-Mainboard-Tools/SystemGuard/ TechNotes D307x-S V2.0 Page 47 of 56 www.ts.fujitsu.com/mainboards... -
Page 48: Industrial Tools
Includes DOS-based tool "SMCO" to flash the configuration file permanently into the system BIOS. - Available in 03/2012 ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D3071-S_D3076-S/IndustrialTools_D307x-S/SilentFanConfig-Manager/ 8.6 Windows System-Monitoring API (BMCAPI) - BMC-Management-Controller to access and adjust System Monitoring parameters like fan speed and temperatures. This API also provides access to the mainboard watchdog, the 8Bit GPIO interface and the intrusion feature of the mainboard. -
Page 49: Known Issues & Important Notes
9.1 Windows XP Installation in AHCI mode – necessary adjustments - Choose BIOS AHCI-mode (ADVANCED – SATA Configuration) - Download F6 SATA Driver Disk ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D3071-S_D3076-S/Drivers_D3071-S_D3076-S/ - Start the Installation of Win XP – press F6 to install SATA drivers - Use the following Drivers for D307x-S: - Continue the installation TechNotes D307x-S V2.0... -
Page 50: Raid / Ahci Driver Disk Installation (Windows Xp) From Floppy Disk
- D307x-S doesn´t offer a legacy floppy interface Windows XP has some limitations regarding USB floppy support, for details see link below http://support.microsoft.com/kb/916196 Alternative option: Use nLite-tool to create customized XP installation CD incl. RAID/AHCI driver www.nliteos.com/nlite.html TechNotes D307x-S V2.0 Page 50 of 56 www.ts.fujitsu.com/mainboards... -
Page 51: Miscellaneous
Note: All three watchdogs are physical identical, but they are handled from different application levels As the SystemGuard tool offers access to the watchdog it can be used as “WD software agent” to retrigger the watchdog during OS runtime TechNotes D307x-S V2.0 Page 51 of 56 www.ts.fujitsu.com/mainboards... - Page 52 No user interaction possible – POST Watchdog is always enabled! BIOS Boot Watchdog o Set Watchdog in BIOS Setup 0 = WD disabled 1 – 255 = WD enabled (timeout = 1 – 255 minutes) TechNotes D307x-S V2.0 Page 52 of 56 www.ts.fujitsu.com/mainboards...
- Page 53 For easy access to the watchdog functions, the Windows API (BMCAPI) or the related Linux driver (lm-sensors) can be used: ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D3071-S_D3076-S/IndustrialTools_D307x-S/ o For easy testing, the SystemGuard tool provides access to the OS Watchdog. After enabling the Watchdog, SystemGuard retriggers the WD continuously.
-
Page 54: Bios Update / Bios Recovery
Miscellaneous 10.2 BIOS Update / BIOS Recovery BIOS update options Link to related BIOS files (OEM FTP Server): ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D3071-S_D3076-S/BIOS_D3071-S/ ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D3071-S_D3076-S/BIOS_D3076-S/ DOS-based BIOS update (DOS-bootable USB stick) Required BIOS files: EfiFlash.exe (DOS flash tool) DosFlash.bat (batch file) D307x-S1.upd (flash file) DosFlash.bat... - Page 55 Follow instructions on the screen and set jumper to default position Note: BIOS Recovery should only be used to repair a corrupted BIOS. All customized data except for OEM SLP data will be reset. TechNotes D307x-S V2.0 Page 55 of 56 www.ts.fujitsu.com/mainboards...
- Page 56 TechNotes D307x-S V1.1 Copyright 2011 FUJITSU TechNotes D307x-S V2.0 Page 56 of 56 www.ts.fujitsu.com/mainboards...
