Clear-Com Intercom Systems
11
9—Call Alert Tone Level Control
This control adjusts the volume of the Call Alert Tone sound. This is normally
adjusted when the system is set up and shouldn't need to be adjusted during
normal operation. This feature can be disabled by turning the control fully
counterclockwise.
10—Minimum Volume Control
This control adjusts the minimum setting of the Intercom Level control on the
front panel. Setting this control can prevent people from inadvertently turning
the intercom level all the way down. This is normally adjusted when the
system is set up and shouldn't need to be adjusted during normal operation.
This feature can be disabled by turning the control fully counterclockwise.
© Clear-Com Intercom Systems 2000
14
P3 Must be
installed if
no option
P1 Must be
installed if
no option
View from top
of KB-212
9 10
FIGURE 2: Internal Controls
13
12
Front Panel
5
KB-212 Speaker Station
Rev. B
