Operation

Normal operation of the KB-212 Speaker Station only requires access to the
front-panel controls. The controls located elsewhere on the unit are intended
to be set-and-forget in nature For intercom operation, set the Listen level
control to the desired level and press the Talk button when talking.

Front Panel

The controls, indicators, and connectors on the KB-212 front panel are shown
in Figure 1 on page 3 and are described by the following text.
8
Mic
1—Talk Button
The Talk button activates the microphone feed to the intercom channel. The
Talk button has a momentary action.
© Clear-Com Intercom Systems 2000
4
Call
Talk
1
FIGURE 1: Front Panel
