KB-212 Speaker Station
Scenario 3
Plug P1 missing on circuit board.
Solution: Plug P1 must be installed in the J1 jack if the EB-4W or EB-TW
options are not used.

Parts Lists

Parts List for the KB-212 Main PCB
Capacitors
Value Type
220 uF Aluminum
22 uF Tantalum
4.7 uF Aluminum NP
100 uF Aluminum
22 pF Ceramic Disc SMD
47 pF Ceramic Disc SMD
220 pF Ceramic Disc SMD
390 pF Ceramic Disc SMD
470 pF Ceramic Disc SMD
.0015 uF Ceramic Disc SMD
.0047 uF Ceramic Disc SMD
.01 uF Ceramic Disc SMD
.047 uF Ceramic Disc SMD
.1 uF Ceramic Disc SMD
.22 uF Ceramic Disc SMD
.47 uF Tantalum SMD
1 uF Tantalum SMD
4.7 uF Tantalum SMD
10 uF Tantalum SMD
Resistors
Value Power
10 OHM 1/4
390 OHM 1/4
1.3K OHM 1/2
2.2 OHM 1/10
100 OHM 1/10
301 OHM 1/10
432 OHM 1/10
475 OHM 1/10
1.00K OHM 1/10
1.21K OHM 1/10
1.50K OHM 1/10
2.00K OHM 1/10
Rev. B
Volts
35V
16V
50V
35V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
35V
16V
16V
25V
Type
Carbon Film
Carbon Film
Carbon Film
SMD
SMD
SMD
SMD
SMD
SMD
SMD
SMD
SMD
12
Clear-Com Intercom Systems
Tol. Part #
150021
150032
150087
150136
5% 151116
5% 151120
5% 151128
5% 151131
5% 151132
5% 151138
10% 151156
10% 151160
10% 151168
10% 151172
10% 151176
10% 151184
10% 151185
10% 151189
10% 151192
Tol. Part #
5% 410002
5% 410005
5% 410075
5% 411181
1% 411293
1% 411339
1% 411354
1% 411358
1% 411389
1% 411397
1% 411406
1% 411418
© Clear-Com Intercom Systems 2000
Designator
C5 C18
C21 C24
C13
C25 C45
C14
C7 C19 C30 C36
C26
C10
C17
C11
C27
C32 C33 C35 C38 C44
C23 C37
C3 C4 C12 C15 C29
C39C40 C41 C46 C47
C16 C22 C28
C31 C34
C6 C20 C43
C8
C42
Designator
R19 R45
R39
R28
R27
R40
R41
R15
R10
R29
R17
R31
R14 R38
