  • Page 1 MOB-GPC12AF MOBILE AIR CONDITIONER...
  • Page 2: Table Of Contents

    CONTENTS ................. SUMMARY ..............WORKING PRINCIPLE ................STRUCTURE ..............OPERATING METHODS ....NAMES AND FUNCTIONS OF THE REMOTE CONTROLLER 8-10 ......... OPE RATION OF THE REMOTE CONTROLLER 11-12 ..ACCESSORIES AND INSTALLATION OF HEAT EXHAUST HOSE 13 - 15 ............. CARE AND MAINTENANCE 16-17 ...............
  • Page 3: Summary

    SUMMARY INVENTOR MOBILE AIR CONDITIONER is a small, moveable air conditioner. It possess the functions of COOL, DRY and the Separate Ventilation, and depends on different places, it can be moved as will. It is fit for home and office use, especially fit for the house with many rooms.
  • Page 4: Structure

    STRUCTURE Front Air outlet Controller panel Handle Remote box Rear Upper air inlet grille Air exhaust outlet Lower air inlet grille...
  • Page 5: Operating Methods

    OPERATING METHODS ° The working range of COOL mode and HEAT modeis16 The working range of COOL ° F mode,Heat mode and DRY At DRY mode,the static pressure range is 0 25 pa. mode. Location requirement The appliance is for indoor use only. The appliance shall be installed in accordance with national wiring regulations.
  • Page 6 OPERATING METHODS ¡ñ Can not use the steel wire or the brass wire replace the fuse, the capability of the fuse must be appropriate. In order to avoid the power cord damaged and electrical leakage, do not fix the power supply on the knife edge or the sharp object.
  • Page 7 OPERA TING METHODS COOL mode DRY mode Set TEMP. WATE full FAN mode ON/ OFF key MODE key " "" " I1M-12 Control panel and the function 1. "ON/ OFF " key Press once to start and press once more to stop the unit. 2."MODE"...
  • Page 8 OPERATING METHODS COOL mode 1). To select a place near the door and window, install the exhaust duct. 2). Press "MODE" key to select "COOL" mode. " " " " ° ° key to set the suitable temp.16 ℃( 61 ) ~30 ℃...
  • Page 9 OPERATING METHODS Drain Hose Clip Drain port fixed clamp with screw 5. Snap the free end of the drain hose into the drain hose clip. Drain Hose Drain plug clip clip drain hose - 7-...
  • Page 10: Names And Functions Of The Remote Controller

    NAMES AND FUNCTIONS OF THE REMOTE CONTROLLER Note: Be sure that there are no obstructions between receiver and remote control; Don't drop or throw the remote control; Don't let any liquid in the remote control and put the remote control directly under the sunlight or any place where is very hot.
  • Page 11 NAMES AND FUNCTIONS OF THE REMOTE CONTROLLER NOTE: This Remote control is universal, it c o uld be used formany units, some buttons of this control which are not availabl e to this unit will not be described below. TIMER Timer button HEALTH X-FAN...
  • Page 12: Names And Functions Of The Remote Controller

    NAMES AND FUNCTIONS OF THE REMOTE CONTROLLER NOTE: This remote controller is universal, it could be used for many units, some buttons of this controller which are not available to this unit will not be described below. AUTO HEALTH X-FAN HUMIDITY FILTER TURBO...
  • Page 13: Operation Of The Remote Controller

    OPERATION OF THE REMOTE CONTROLLER Guide for operation-general operation 1.Press ON/OFF button to start the unit after powering the main unit on.(Note: Power the unit on every time, the big -guide louver and small-guide louver will be ON/OFF MODE closed firstly. 2.Press MODE button to select desired running mode.
  • Page 14: Ope Ration Of The Remote Controller

    OPERATION OF THE REMOTE CONTROLLER ★ About AUTO RUN When AUTO RUN mode is selected, the setting temperature will not be displayed on the LCD, the unit will be in accordance with the room temp. automatically to select the suitable running method and to make ambient comfortable.
  • Page 15: Accessories And Installation Of Heat Exhaust Hose

    ACCESSORIES AND INSTALLATION OF HEAT EXHAUST HOSE ¡ñ Length range of exhaust pipe should be 50 ~150cm. It is recommended to use it with shortest length. When installing, exhaust pipe should be as flat as possible. Don't prolong the pipe or connect it with other exhaust pipe, or it would cause abnormal operation.
  • Page 16 ACCESSORIES AND INSTALLATION OF HEAT EXHAUST HOSE If the pipe are to be bent, please install it by considering following dimension. 55cm Wrong installation is shown in following figure (If the pipe is bent too much, it would easily cause malfunction.)
  • Page 17: Parts Included

    ACCESSORIES AND INSTALLATION OF HEAT EXHAUST HOSE PARTS INCLUDED Front plastic pipe end Rear plas tic pipe en d Flexible Exhaust Hose Window Exhaust Adapter -15-...
  • Page 18: Care And Maintenance

    CARE AND MAINTENANCE There are castors in the bottom The mobile air conditioner of the unit, according to the demand, it can be moved in the room very expediently . Air inlet grille and filter(inside) Before maintenance, please WARNING pull out the power plug , and cut off power supply, in order to avoid the electric shock.
  • Page 19 CARE AND MAINTENANCE Please use a cloth slightly moistened with water below 40¡æ(104 ) (or Clean the air ° F conditioner the soap water or the water with cleanser),after wresting wipe the dirt. Do not use the gasoline, diesel oil or the congeneric substance to clean the unit.
  • Page 20: Trouble Shooting

    TROUBLE SHOOTING If the malfunction occur , please check the following before maintenance: Solutions Troubles Possible Causes The power supply is not connected well . The air conditioner doesn't start. 1. Insert the power plug tightly . The power plug is not inserted tightly . 2.
  • Page 21: User Notices

    USER NOTICES Location Do not install the unit in the confined place, and keep the well ventilation, in order to avoid malfunction occurs. Do not install the unit where it will be exposed to direct sunlight, in order to avoid fading and efficiency reducing. Do not install the unit in the moist place, it can cause the electrical leakage.
  • Page 22: After Service

    USER NOTICES ¡ñ Do not incline or overturn. If the abnormal phenomenon occurred, please pull out the power plug at once, and inform the dealer to check and maintain. ¡ñ Do not use the insecticide or other sprays, it can cause deformation or crack..
  • Page 23: Circuit Diagram

    CIRCUIT DIAGRAM I1M-12:...
