Summary of Contents for Vision XDVR2POSM

  • Page 1: Table Of Contents

    CCTV How to Set up a POS Surveillance System using XDVR2POSM/M2 Contents Introduction Benefits Features Devices Required for POS Surveillance System Supported Models. Integrated System Configuration System Connectivity (with RS232 DB9 Y Cable) Set-up of Connected Devices Text Module Installation...
  • Page 2: Introduction

    Introduction Integrated POS surveillance system comprises several components mainly including point-of-sales, cameras and digital video recorders which are capable of recording transaction data. It provides retail managers and shop or company owner with a complete picture of trade activity and also enables emphasizing of suspected or questionable event such as “Sweet hearting discounts”...
  • Page 3: Features

    Features • Data synchronization: every sales check’s text information applies to video image • Video Text Overlay: Transaction text message can be displayed on screen and on the video files. You may also choose to hide the data from the screen view. •...
  • Page 4: Integrated System Configuration

    Integrated System Configuration SINGLE POS—DIRECT CONNECTION SINGLE POS—LONG DISTANCE (UP TO 1 KM)
  • Page 5: System Connectivity (With Rs232 Db9 Y Cable)

    MULTI-POS SURVEILLANCE System Connectivity (with RS232 DB9 Y Cable) The RS232 DB9 Y Cable (see the figure below)is available in both Text Module and Data Converter packages for easy wiring. Please refer to the Y Cable’s figure below for each connector’s use. Also refer to the following diagrams for single / multi- POS connection with the Y Cable.
  • Page 6 SINGLE POS CONNECTION VIA THE DB9 Y CABLE MULTI-POS CONNECTION VIA DB9 Y CABLES...
  • Page 7: Set-Up Of Connected Devices

    SET UP OF CONNECTED DEVICES Text Module Installation Before attaching the Text Module to the DVR, please check if the Text Module package contains the items listed below. Main Board Text Module: 1. Text Module x1 2. USB Cable x1 3.
  • Page 8 STEP 2 Fasten the Text Module on the location, which is marked as a frame in the right figure. Then connect USB from Socket A (on the Main Board as shown on left) and connect it to Socket B (on the Text Module), as shown on right.
  • Page 9: Osd Setup (Local/Remote)

    OSD Setup (Local/Remote) After completing Text Module installation, please carry on the DVR’s OSD setup for activating the text function. To setup the Text Overlay function, enter the OSD setup menu with the correct administrator password, and then select “Text Setup”. Main Menu 1.
  • Page 10 TEXT OVERLAY You can decide to see text overlay in LIVE mode, PB mode or both. • Available options - OFF, Only Live, Only PB, Live/PB • Max lines displayed on OSD : 15 lines • 42 bytes per line •...
  • Page 11 TRIGGER When turned “ON”, those transactions containing “Exception Strings” and meeting “Numerals” conditions will be marked as exceptions in text database and then trigger preset actions such as alarm output, alarm message via e-mail, SMS, etc. Exceptions can also be quickly searched via Text Query in Search menu.
  • Page 12: Data Converter Setting

    Port Selection PORT SELECTION 1. Serial Port Text It is essential to select a port for either the POS/cash register 2. USB Port-Front NONE or modem when the text function is set on. Meanwhile, also 3. USB Port-Rear Top NONE check whether the device is connected to the port selected.
  • Page 13 POS ID SETTING The Data Converter’s POS ID should correspond with the cash register’s number, i.e. POS ID 1? Register No.1, POS ID 2? Register No.2, etc. Please refer to the table below for POS ID setting. MODE SETTING Set the mode according to whether the connected device is a transmitter or receiver.
  • Page 14: Example Of Data Converter Setting

    Example of Data Converter Setting Suppose that there are two POS/ cash registers connecting to a DVR in a POS surveillance system, like the illustration below. Each Data Converter’s POS ID and Mode should be set as follows. DC 1: POS ID 1 (0000);...
  • Page 15: Pos/Cash Register Setting

    POS Cash Register Setting Please refer to the user manual of the POS/cash register in use for printer-related setting. Text Operation (Local/Remote) Users can easily investigate specific transactions data via Text Module’s text search function, which can be found on the DVR’s Search menu. Press the button SEARCH to enter the Search menu, as shown below. Then move the cursor to the Text Query Page under the item: Search By Text.
  • Page 16 SEARCHING CONDITION BY TEXT AVAILABLE OPTIONS • OFF • Specific - Transactions with the specific keyword will be found. • AND - Transactions with the exact two keywords will be found. • OR - Any transaction containing one of the two keywords will be found. •...
  • Page 17 Then, move the cursor down to “Text Query List” and press ENTER for searching result; see the figure below. • EXC. is the abbreviation of Exception. • The EXC. column will show Exception Strings if searching by “Exception.” • Strings of more than 7 bytes will be abbreviated.
  • Page 18 EXPORT • AVI No text overlay support when exporting AVI format • DRV Text overlay is only present in DRV format. Users can use “Local Playback of DVR Remote”, “DVR Player” and CMS to playback DRV file. Text overlay will show when playback DRV file is in full screen mode. NOTE: We recommend using the “ezBurn”...
  • Page 19: Appendix A: Pin Definition Of Rs232 Db9 Male

    Appendix A: Pin Definition of RS232 DB9 Male RS232-A for POS/Cash Register (Half-duplex) Definition RS232-B for DVR (Full-duplex) Definition...
  • Page 20: Appendix B: Pos Menu Tree

    Appendix B: POS Menu Tree The table below is the POS menu tree. Item Level 1 Level 2 Level 3 Text Setup 1.Text function <ON><OFF> 2.Text overlay <ON><OFF> 3.Exception Setup 1.Exception No. <1>~<16> 2.Trigger <ON><OFF> 3.Exception String Ex: <NO SALE>,<VOID>,<CANCEL>, <RETURN>,<COUPOUND>,<DISCOUNT>...
  • Page 21: Appendix C: List Of Supported Models

    Appendix C: List of Supported Models The supported models for pole display and printer are listed below. Pole Display Printer Cache Technology VFD-202T Citizen CBM-1000 II Citizen C2202 Citizen CT-S300 Digipos CD5220 Dell T200 Emax Pole Display Epson TM-T88II/ TM-T88III/ TM-T88IV Epson DM-D Series Epson TM-T90 Logic Controls LD9000...
  • Page 22: Appendix D: Ascii Table

    Appendix D: ASCII Table...
