Vision Security System
OWNER MANUAL
V-LED1
Congratulations on your purchase of the OPTEX Vision security system. Vision is an
advanced microprocessor based alarm system which provides fire and burglar protection.
This manual provides simple operation instructions which will help you to enjoy the greatest
benefit from your security system with the least difficulty. Please read this manual before
operating the system.
Vision is a versatile system and some of the functions explained in this manual may not have
been included in your system. Please ask your security company if there are features
mentioned in this manual which you would like to add to your system.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-LED1 and is the answer not in the manual?

Questions and answers

Related Manuals for Vision V-LED1

Summary of Contents for Vision V-LED1

  • Page 1 Vision Security System OWNER MANUAL V-LED1 Congratulations on your purchase of the OPTEX Vision security system. Vision is an advanced microprocessor based alarm system which provides fire and burglar protection. This manual provides simple operation instructions which will help you to enjoy the greatest benefit from your security system with the least difficulty.

  • Page 2: System Reference Guide

    SYSTEM REFERENCE GUIDE System Information Central Station Phone Number Central Station Account Number Service Call Arming Your system is programmed - Zone Type Arming Area Group Arming Mode Arming Delay Times Exit Delay Time sec. Exit Delay Time 2 sec. Entry Delay Time sec.

  • Page 3: Basic Operation

    Basic Operation Vision’s ‘Point & Click’ control makes operating your security system quick and easy. For most day to day operations you can simply select the area you wish to secure (A, B, C, or D) and press . If your security system is ‘On’ (armed), entering a valid User PIN turns-off (disarm) the entire system.

  • Page 4: System Operation

    System Operation The green ‘Ready’ light indicates that all detectors are secure and ready to arm. If the ‘Ready’ light is not on, one or more detectors are activating (open) and are not ready to be armed. Depending on your system’s design, this may or may not prevent your system from arming.

  • Page 5: User Functions

    User Functions Vision allows system users to control many advanced features. This provides quick service, greater convenience, and lower operating cost. Access these features by press- and the feature number. Chime Smoke Detector Reset System Walk Test Viewing Alarm Memory Viewing System Trouble Bypassing Zones Installer Programming...
  • Page 6 [4] Viewing Alarm Memory A blinking Memory LED or Zone Indicator LED while the panel is armed, or a lit Memory LED while the system is disarmed, indicates that an alarm occured during the most recent arming period. Press + 4 while the system is disarmed to view the first alarm of the arming period.

  • Page 7: Bypassing Zones

    [6] Bypassing Zones Zones can be manually excluded as you arm your security system (if they are inoperable or if they would conflict with a planned activity). To enter Zone Bypass Mode, press + 6 . The green ‘ready’ LED will blink to indicate bypass mode. Press to scroll upwards to the desired zone, or enter the zone number (01, 02, 03, etc...).

  • Page 8: User Programming

    [0] No Exit Delay Arming & Quick Exit During the exit delay period, enter + 0 to arm the system immediately. This will cancel the remainder of the exit delay. While your system is armed, press + 0 to bypass the entire system for two minutes. may enter or exit freely until the system automatically returns to its prior armed status at the end of the two minute period.
  • Page 9 If you continue, Vision will automatically advance to the address of the next PIN and wait for a four digit code + + two digit autorization level , etc..and automatically return to Clear ‘Home’ of User Programming after the eigth user PIN is programmed. At any time, Clear be pressed once to return to ‘Home’...
  • Page 10 [4] Set System Time Clock Many important Vision features utilize an internal clock to operate. Set, or reset, the clock here. Set hours and minutes (HH:MM) using 24 hour format (1330 = 1:30pm) and press . Then set month and day (MMDD), press , year (YY) and Complete sequence to set the system clock + 8 + PIN + 4 +...

  • Page 11: Keypad Alarms

    User Activated Alarms Keypad Alarms If equipped, your Vision keypad can be used to report alarms to the monitoring company. Press 2 & 3 for approximately 2 seconds for emergency PANIC alarm ( Press 5 & 6 for approximately 2 seconds for emergency FIRE alarm ( Press 8 &...
