4
Adjust volume using VOLUME .
To
Press
Pause
CD u
Resume play after
CD u again
pause
Locate the beginning
.**
of the current
track (AMS*)
Locate the next
>**
track (AMS)
Go back at high speed
Hold down .**
Go forward at high
Hold down >**
speed
Locate the previous
. repeatedly**
track (AMS)
Locate the succeeding
> repeatedly**
track (AMS)
Stop play
x
* AMS = Automatic Music Sensor
** These operations are possible during both
play and pause.
• To handle compact discs
Correct
Handle the disc
by its edge.
Incorrect
Do not touch the
surface.
Do not stick paper
or tape nor write
anything on the
surface.
Note
If you press CD u when there is no disc in the
CD compartment, "00" flashes for about 5
seconds on the display and the unit turns off
automatically.
Various Modes of CD
Playback
You can play tracks repeatedly or in random
order.
Press CD PLAY MODE .
Each press changes the play mode as
follows:
Display
Play
Indication
mode
none
(normal play)
All the tracks are played once.
m
"REP 1"
(single repeat)
A single track is played repeatedly.
m
"REP ALL"
(all repeat)
All the tracks are played repeatedly.
m
"SHUFFLE"
(shuffle play)
All the tracks are played once
in random order.
m
"SHUFFLE REP"
(shuffle repeat)
All the tracks are played repeatedly
in random order.

Operating the Radio

Manual Tuning

1
Press RADIO ON•BAND to turn on the
radio.
"RADIO" appears in the display.
The display shows the band and frequency
for a few seconds and then changes back to
the current time.
2
Press RADIO ON•BAND repeatedly to
select the desired band.
Each press changes the band as follows:
* When using FM1 or FM2 preset mode, you
may listen to the radio on either mode
(See "Preset Tuning").
3
Use TUNE/TRACK/TIME SET + or – to
tune in to the desired station.
The FM channel step is set to 0.1 MHz and
the AM channel step is set to 10 kHz (US,
Canadian models).
The FM channel step is set to 0.05 MHz* and
the AM channel step is set to 9 kHz (AEP
model).
* The FM frequency display is raised or
lowered by a step of 0.1 MHz. For example,
frequency 88.00 and 88.05 MHz is displayed
as "88.0 MHz."
Two short beeps sound when the
minimum frequency of each band is
received during tuning.
4
Adjust volume using VOLUME .
• To turn off the radio, press OFF .
• To improve radio reception
FM: Extend the AC power cord fully to
improve FM reception.
AM: When installing the unit, rotate the unit
horizontally for optimum reception and
then install the unit. A ferrite bar antenna
is built into the unit.
• To check the station being received, press
RADIO ON•BAND lightly. The display shows
the band and frequency for a few seconds and
then changes back to the current time.

Preset Tuning

You can preset 10 stations in FM (5 stations in
FM1, 5 stations in FM2) and 5 stations in AM.
Presetting a Station
Example: To preset FM90 MHz onto preset
button 2 for FM2.
1
Press RADIO ON•BAND to turn on the
radio.
2
Press RADIO ON•BAND to select FM2.
<
3
Tune in to the station on FM90 MHz
(See "Manual Tuning").
4
Hold down the PRESET TUNING
button 2 until you hear two short
beeps.
The display shows the frequency for a few
seconds and then changes back to the current
time.
To change a preset station
Tune in manually to the station you want to store
and hold down the PRESET TUNING button (1-5)
until you hear two short beeps. The previously
stored station will be replaced by the new one.
Tuning in to a preset station
1
Press RADIO ON•BAND to turn on the
radio.
2
Press RADIO ON•BAND to select the
band.
3
Press the PRESET TUNING button
lightly where the desired station is stored.
4
Adjust the volume using VOLUME .
After a few seconds, the display returns to
the current time but the preset button
number remains.
Note
When the PRESET TUNING buttons (1-5) are
pressed lightly, the radio station that is preset
will be selected. When they are pressed for a
while, the station that is on will be newly preset.
Useful Functions
To Obtain Powerful Bass
Switch MEGA BASS to ON .
The "MEGA BASS" system produces a powerful
bass sound.

Setting the Alarm

Before setting the alarm, make sure to set the
clock (see "Setting the Clock").
To Set the Alarm Time
1
Turn off the radio.
2
Press ALARM for a few seconds.
You will hear a beep and the hour will start
to flash in the display.
3
Press TUNE/TRACK/TIME SET + or –
until the desired time appears in the
display.
4
Press ALARM once.
The minutes starts to flash.
5
Repeat steps 3 and 4 to set the minute.
Two short beeps will confirm the setting, and
the display will show the current time.
When TUNE/TRACK/TIME SET + or – is held
down, the displayed time initially changes in
one-minute steps, and after about a second,
switches to ten-minute steps.
To Check the Alarm
Time
Press ALARM .
The display shows the alarm time for a few
seconds and then returns to show the current
time.
ALARM ON —
To Set the Alarm Mode
Press ALARM ON/OFF to set the alarm.
"
" will appear in the display.
When the alarm comes on at the preset time,
"
" flashes in the display.
ALARM OFF —
The alarm is turned off automatically after
59 minutes.
To Stop the Alarm
Press OFF•ALARM RESET to turn off the
alarm.
The alarm will come on again at the same time
the next day.
To Cancel the Alarm
Press ALARM ON/OFF.
"
" will disappear from the display.
– 5 –
