CD RECEIVER
DEH-P490IB
DEH-P4900IB
This service manual should be used together with the following manual(s):
Model No.
Order No.
CX-3195
CRT3815
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
Mech.Module
S10.5COMP2
CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
DEH-P490IB/XN/UC
/XN/UC
Remarks
ORDER NO.
CRT3846
/XN/UC
K-ZZU. DEC. 2006 Printed in Japan
Advertisement
Table of Contents
Related Manuals for Pioneer DEH-P490IB
Summary of Contents for Pioneer DEH-P490IB
- Page 1 PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2006 K-ZZU.
-
Page 2: Safety Information
(shorting-solder) by referring to "the DISASSEMBLY". 4. After replacing the pickup unit, be sure to check the grating. 5. Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by electrostatic induction. DEH-P490IB/XN/UC... - Page 3 To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be installed before shipment. Please be sure to follow this method especially if it is specified in this manual. DEH-P490IB/XN/UC...
-
Page 4: Table Of Contents
6.5 SYSTEM MICROCOMPUTER TEST PROGRAM ................... 56 7. GENERAL INFORMATION ..........................57 7.1 DIAGNOSIS ............................. 57 7.1.1 DISASSEMBLY ............................. 57 7.1.2 CONNECTOR FUNCTION DESCRIPTION ..................60 7.2 IC ................................61 7.3 OPERATIONAL FLOW CHART ....................... 70 8. OPERATIONS ..............................71 DEH-P490IB/XN/UC... -
Page 5: Specifications
1. SPECIFICATIONS - DEH-P490IB/XN/UC Backup current ....5 mA or less DEH-P490IB/XN/UC... - Page 6 - DEH-P4900IB/XN/UC Backup current ....5 mA or less DEH-P490IB/XN/UC...
- Page 7 DEH-P490IB/XN/UC...
-
Page 8: Exploded Views And Parts List
• Screw adjacent to mark on the product are used for disassembly. • For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions,apply as you think it appropriate.) 2.1 PACKING DEH-P490IB/XN/UC... - Page 9 Protector XHP7016 Accessory Assy XEA7011 Protector XHP7017 Polyethylene Bag CEG1160 Holder CND1249 (2) CONTRAST TABLE DEH-P490IB/XN/UC and DEH-P4900IB/XN/UC are constructed the same except for the following: Mark Description DEH-P490IB/XN/UC DEH-P4900IB/XN/UC Caution Card Not used CRP1294 Warranty Card CRY1070 CRY1246 Owner's Manual...
-
Page 10: Exterior
2.2 EXTERIOR 56 62 DEH-P490IB/XN/UC... - Page 11 See Contrast table(2) Button(BAND,DISP) XAC7146 Holder See Contrast table(2) Screw See Contrast table(2) Spring XBH7001 Cover XNS7180 Sub Spring Assy XXA7363 Lighting Conductor XNV7033 Connector(CN1901) CKS5207 Button(UP,DOWN,L,R) See Contrast table(2) Double side Tape CNM8673 OLED Unit MXS8233 Holder XNC7028 Holder XNV7034 DEH-P490IB/XN/UC...
- Page 12 (2) CONTRAST TABLE DEH-P490IB/XN/UC and DEH-P4900IB/XN/UC are constructed the same except for the following: Mark Description DEH-P490IB/XN/UC DEH-P4900IB/XN/UC Panel XNS7182 XNS7181 Tuner Amp Unit XWM7175 XWM7176 Detachable Assy XXA7476 XXA7475 Button(UP,DOWN.L,R) XAC7150 XAC7147 Sub Grille Assy XXA7483 XXA7482 Grille Unit...
- Page 13 DEH-P490IB/XN/UC...
-
Page 14: Cd Mechanism Module
2.3 CD MECHANISM MODULE DEH-P490IB/XN/UC... - Page 15 Bracket CND2583 CND2584 Lever CND2585 CND2586 Bracket CND2587 CND2588 Lever CND2589 Holder CNV7201 Gear CNV7207 Gear CNV7208 Gear CNV7209 Gear CNV7210 Gear CNV7211 Gear CNV7212 Rack CNV7214 CNV7216 Roller CNV7218 Gear CNV7219 Guide CNV7361 Gear CNV7595 Guide CNV7799 CNV7805 DEH-P490IB/XN/UC...
-
Page 16: Block Diagram And Schematic Diagram
LCOM CONT XOUT CONT SWVDD /PUEN RESET /RESET /RESET CDRST DPDT 12EJ BRST,BRXEN,BSRQ BRST,BRXEN,BSRQ,BDATA,BSCK BDATA,BSCK DSCSNS CD 7.5V REGULATOR Q650 HOME B.UP KYDT Q651 S905 S904 S901 12EJ HOME S903 DSCSNS VDCONT CSENS VDSENS DETACH SENSE SW DSENS S802 DEH-P490IB/XN/UC... - Page 17 DPDT DPDT DPDT OLED UNIT XOUT X1921 DPDT 10.000MHz KEY/OEL CONTROLLER KYDT KYDT KYDT KYDT 13,16 IC 1921 OEL DATA PEG268A OEL+B OEL+B CSENS CSENS CSENS 5.1V CN1951 DETACH SENSE SW CN1950 Q2011 8.5V DSENS Q2012 REGULATOR S802 8.5V DEH-P490IB/XN/UC...
-
Page 18: Overall Connection Diagram(Guide Page)
No differentiation is made between chip resistors and capacitance values are expressed in codes: discrete resistors. Ex. *Resistors Symbol indicates a capacitor. Code Practical value No differentiation is made between chip capacitors and 12k ohms discrete capacitors. 10k ohms *Capacitors Code Practical value 0.01uF 101/10 100uF/10V DEH-P490IB/XN/UC... - Page 19 > DETACH FM,AM:21.1 dBs IPBUS:36.3 dBs CD:36.1 dBs AUX/IPOD:35.3 dBs The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. DEH-P490IB/XN/UC...
- Page 20 DEH-P490IB/XN/UC...
- Page 21 DEH-P490IB/XN/UC...
- Page 22 DEH-P490IB/XN/UC...
- Page 23 DEH-P490IB/XN/UC...
-
Page 24: Keyboard Unit
3.3 KEYBOARD UNIT CN1951 FUNC DISP TION CLOCK DEH-P490IB/XN/UC DEH-P4900IB/XN/UC DEH-P490IB/XN/UC... - Page 25 KEYBOARD UNIT OLED UNIT DEH-P490IB/XN/UC...
-
Page 26: Cd Mechanism Module(Guide Page)
3.4 CD MECHANISM MODULE(GUIDE PAGE) PICKUP UNIT(P10.5)(SERVICE) SWITCHES: CD CORE UNIT(S10.5COMP2) S901:HOME SWITCH..ON-OFF S903:DSCSNS SWITCH..ON-OFF S904:12EJ SWITCH.....ON-OFF S905:8EJ SWITCH....ON-OFF The underlined indicates the switch position. M1 CXC7134 SPINDLE MOTOR M2 CXC4026 LOADING/CARRIAGE MOTOR CD DRIVER DEH-P490IB/XN/UC... - Page 27 CD CORE UNIT(S10.5COMP2) SIGNAL LINE FOCUS SERVO LINE TRACKING SERVO LINE CARRIAGE SERVO LINE SPINDLE SERVO LINE CN651 & DEH-P490IB/XN/UC...
- Page 28 DEH-P490IB/XN/UC...
- Page 29 DEH-P490IB/XN/UC...
- Page 30 DEH-P490IB/XN/UC...
- Page 31 DEH-P490IB/XN/UC...
- Page 32 200 ms/div 500 mV/div 2 ms/div 1 V/div %RFAGC 500 mV/div 500 mV/div 500 mV/div 9TIN 500 mV/div Focus Search waveform Track Open waveform 1 Track Jump waveform Ref.: Ref.: Ref.: REFO REFO REFO Mode: Mode: Mode: TEST TEST TEST DEH-P490IB/XN/UC...
- Page 33 4LOEJ 312SNS 5 V/div 5 V/div 1 V/div 4LOEJ 0FIN 5 V/div 1 V/div Black dot(800 μm) during play 12 cm CD Eject operation 8 cm CD Eject operation Ref.: Ref.: Ref.: REFO Mode: Mode: Mode: Normal Normal Normal DEH-P490IB/XN/UC...
-
Page 34: Pcb Connection Diagram
For further information for respective destinations, be sure to check with the schematic dia- CORD ASSY gram. 2.Viewpoint of PCB diagrams AUX INPUT IP-BUS Capacitor Connector SIDE A SIDE B Chip Part P.C.Board CN701 DETACH DEH-P490IB/XN/UC... - Page 35 SIDE A REAR OUTPUT FRONT OUTPUT SUBWOOFER OUTPUT ANTENNA iPOD TESTIN CN1950 FRONT DEH-P490IB/XN/UC...
- Page 36 TUNER AMP UNIT DEH-P490IB/XN/UC...
- Page 37 SIDE B DEH-P490IB/XN/UC...
-
Page 38: Keyboard Unit
4.2 KEYBOARD UNIT KEYBOARD UNIT SIDE A KEYBOARD UNIT SIDE B CN1951 CLOCK OLED UNIT DISPLAY FUNCTION DEH-P490IB/XN/UC... -
Page 39: Panel Unit
4.3 PANEL UNIT SIDE A PANEL UNIT CN1901 EJECT SIDE B PANEL UNIT CN801 DEH-P490IB/XN/UC... -
Page 40: Cd Core Unit(S10.5Comp2)
4.4 CD CORE UNIT(S10.5COMP2) CD CORE UNIT(S10.5COMP2) SIDE A CN651 PICKUP UNIT(P10.5)(SERVICE) LOADING /CARRIAGE MOTOR SPINDLE MOTOR DEH-P490IB/XN/UC... - Page 41 CD CORE UNIT(S10.5COMP2) SIDE B DEH-P490IB/XN/UC...
-
Page 42: Electrical Parts List
D 650 (A,16,69) MTZJA8R2(B) IC 703 (A,123,76) IC TC4066BFT D 801 (B,102,30) Diode MC2850-11 IC 704 (A,125,59) IC NJM2794V D 802 (B,112,29) Diode MC2848-11 IC 851 (B,38,18) IC NJM2360M D 803 (B,124,32) Diode MC2846-11 IC 901 (A,5,120) IC NJM2388F84 DEH-P490IB/XN/UC... - Page 43 R 164 (A,74,62) RS1/16S103J R 607 (A,81,56) RS1/16S822J R 172 (A,69,99) RS1/16S223J R 608 (B,103,44) RS1/16S102J R 175 (A,66,99) RS1/16S223J R 609 (A,93,38) RS1/16S102J R 201 (A,82,87) RS1/16S102J R 610 (A,89,60) RS1/16S471J R 202 (A,90,85) RS1/16S102J R 611 (A,93,45) RS1/16S473J DEH-P490IB/XN/UC...
- Page 44 C 185 (A,97,90) CKSRYB105K10 R 808 (B,113,24) RS1/16S222J C 186 (A,94,91) CKSRYB105K10 R 809 (A,104,21) RD1/4PU222J C 201 (B,66,72) CKSRYB105K10 C 202 (A,73,73) CKSRYB105K10 R 810 (B,129,26) RS1/16S102J R 811 (B,112,33) RS1/16S102J C 203 (B,66,74) CKSRYB104K16 R 812 (B,107,32) RS1/16S102J DEH-P490IB/XN/UC...
- Page 45 C 652 (B,85,25) CKSRYB152K50 D 1947 (A,40,89) LED SML412BC5T(NP) C 653 (B,87,30) CKSRYB152K50 D 1948 (A,40,100) LED SML412BC5T(NP) C 659 (A,48,41) CEJQ101M16 D 1949 (A,40,110) LED SML412BC5T(NP) C 660 (B,67,45) CKSRYB105K10 D 1950 (A,40,121) LED SML412BC5T(NP) C 661 (B,54,23) CKSRYB103K50 DEH-P490IB/XN/UC...
- Page 46 R 1953 (B,36,131) RS1/16S331J C 1951 (A,39,130) CKSRYF104Z50 R 1954 (B,36,136) RS1/16S331J C 1952 (A,40,147) CKSRYF104Z50 R 1955 (B,27,154) RS1/16S391J C 1953 (A,18,154) CKSRYF104Z50 R 1957 (B,28,33) RS1/16S391J C 1954 (A,40,152) CKSRYF104Z50 R 1958 (B,32,33) RS1/16S391J C 1955 (A,6,45) CKSRYF104Z50 DEH-P490IB/XN/UC...
- Page 47 R 1994 (B,12,35) RS1/16S182J S 1984 (A,40,125) Push Switch CSG1155 R 1995 (B,14,37) RS1/16S821J S 1985 (A,40,136) Push Switch CSG1155 R 2011 (B,14,77) RS1/16S273J S 1986 (A,40,142) Push Switch CSG1155 S 1987 (A,40,157) Push Switch CSG1155 R 2012 (B,26,80) RS1/16S473J DEH-P490IB/XN/UC...
- Page 48 R 214 (B,36,34) RS1/16SS472J C 251 (B,33,29) CKSSYB102K50 R 216 (B,47,49) RS1/16SS472J C 303 (A,35,19) CKSSYB472K25 R 221 (B,36,32) RS1/16SS103J C 304 (A,34,21) CKSSYB223K16 C 307 (B,25,9) CKSRYB104K16 R 222 (B,35,32) RS1/16SS103J C 308 (B,10,27) CKSRYB105K10 R 225 (A,49,49) RS1/16SS103J DEH-P490IB/XN/UC...
- Page 49 Unit Name : Panel Unit MISCELLANEOUS D 1970 CL220PGC S 1970 Push Switch CSG1112 RESISTORS R 1970 RS1/16S101J R 1971 RS1/16S101J R 1972 RS1/16S0R0J CAPACITORS C 1970 CKSRYB104K16 Miscellaneous Parts List Pickup Unit(P10.5)(Service) CXX1942 Motor Unit(SPINDLE) CXC7134 Motor Unit(LOADING/CARRIAGE) CXC4026 DEH-P490IB/XN/UC...
-
Page 50: Adjustment
1k ohms in series. • The load and eject operation is not guarantied with the mechanism upside down. If the mechanism is blocked due to mistaken eject operation, reset the product or turn off and on the ACC to restore it. DEH-P490IB/XN/UC... - Page 51 • When the power is turned on/off the jump mode is reset to the Single TR (91) while the gain of the RFAMP is reset to 0 dB. At the same time all the self-adjusting values shall return to the default setting. DEH-P490IB/XN/UC...
-
Page 52: Checking The Grating After Changing The Pickup Unit
Because of eccentricity in the disc and a slight misalignment of the clamping center the grating waveform may be seen to "wobble" ( the phase difference changes as the disc rotates). The angle specified above indicates the average angle. • Hint Reloading the disc changes the clamp position and may decrease the "wobble". DEH-P490IB/XN/UC... - Page 53 Ech → Xch 20 mV/div, AC Grating waveform Fch → Ych 20 mV/div, AC 0° 30° 45° 60° 75° 90° DEH-P490IB/XN/UC...
-
Page 54: Error Mode
Remarks: Mechanical errors are not displayed (because a CD is turned off in these errors). Unreadable TOC does not constitute an error. An intended operation continues in this case. Upper digits of an error code are subdivided as shown below: 1x: Setup relevant errors, 3x: Search relevant errors, Ax: Other errors. DEH-P490IB/XN/UC... -
Page 55: Ipod Test Mode
[Features of this test mode] Enables switching at any time to the iPod source Disables communication with iPod Disables indication of logos (Pioneer) on iPod Functions regardless of connection of the iPod body to H/U [How to shift to test mode] The following describes how to enter and display the test mode. -
Page 56: System Microcomputer Test Program
The frequency of the clock signal is 625 kHz that is one 32th of the fundamental frequency(20 MHz/32). The clock signal should be 625 kHz(±25 Hz). If the clock signal is out of the range, the X'tal (X601) should be replaced with new one. DEH-P490IB/XN/UC... -
Page 57: General Information
Remove the two screws and then remove the Grille Assy. Fig.1 Grille Assy Removing the Tuner Amp Unit (Fig.2) Remove the screw. Remove the three screws. Straighten the tabs at three locations indicated and then remove the Tuner Amp Unit. Tuner Amp Unit Fig.2 DEH-P490IB/XN/UC... - Page 58 Upper Frame. 3. While lifting the Carriage Mechanism, remove it from the three Dampers. Caution: When assembling, be sure to apply some alcohol to the Dampers and assemble the mechanism in a clamped state. Damper Damper Carriage Mechanism Lower Frame DEH-P490IB/XN/UC...
- Page 59 Assemble the sub unit side of the Pickup, taking the plate (Chassis) in-between. When treating the leads of the Load Carriage Motor Assy, do not make them loose over the Feed Screw. Poly Washer Change Arm Pickup Lock Arm Inner Holder Feed Screw Planet Gear Pickup Rack Chassis Pickup DEH-P490IB/XN/UC...
-
Page 60: Connector Function Description
7.1.2 CONNECTOR FUNCTION DESCRIPTION DEH-P490IB/XN/UC... - Page 61 7.2 IC NJM2794V OUT1 IN1+ IN1- OUT1 IN1+ IN1- VREF Vref IN2- IN2+ OUT2 IN2- OUT2 IN2+ DEH-P490IB/XN/UC...
- Page 62 PML015B - Block Diagram - Pin Layout IN1_L IN1_R IN2_L IN2_R IN3_L IN3_R IN4+_L IN4+_R IN4-_R IN4-_L Front_R Front_L Rear_L Rear_R Vref DATA FIE_R FIE_L Pre/SW_R Pre/SW_L LMout PGND Pref DEH-P490IB/XN/UC...
- Page 63 PAL007C DEH-P490IB/XN/UC...
- Page 64 EVOL : Source select(iPod) IPODON Not used 53-59 Power supply input(+) Not used Communication mode (UART) notification output psensg Connection sense input Power supply control output PPOWER psens Connection sense input DALMON For consumption current reduction output Not used DEH-P490IB/XN/UC...
- Page 65 PBUS : Clock output BSCK PEG270A Format Meaning CMOS Nch open drain TC4066BFT IN/OUT1 1 14 VDD OUT/IN1 2 13 CONT1 12 CONT4 OUT/IN2 3 IN/OUT2 4 11 IN/OUT4 CONT2 5 10 OUT/IN4 9 OUT/IN3 CONT3 6 VSS 7 8 IN/OUT3 DEH-P490IB/XN/UC...
- Page 66 OELD master clock output MCLK AD KEY input 2 ADKEY2 AD reference voltage input(VCC) VREF AD KEY input 1,0 17,18 ADKEY1,0 General purpose port(DIMMER output) Command select for OELD controller XCMD PEG268A Format Meaning CMOS PE5547A Format Meaning CMOS Nch open drain DEH-P490IB/XN/UC...
- Page 67 Power supply for the crystal oscillator Power supply for DAC DA.VDD Output of audio for the left channel LOUT Ground for DAC DA.GND Connected to the capacitor for band gap REGC DA.GND Ground for DAC Output of audio for the right channel ROUT DEH-P490IB/XN/UC...
- Page 68 Output of reference voltage REFOUT Reversal input of FE Output of FE ADCIN FE,TE A/D converter input Reversal input of TE Output of TE Output of LD Input of PD AD.VDD Power supply for servo ADC Ground for servo ADC AD.GND DEH-P490IB/XN/UC...
- Page 69 22 AUDIOGND audio ground Ground of audio block 23 L ch O L channel output FM stereo “L-ch” signal output or AM audio output 24 R ch O R channel output FM stereo “R-ch” signal output or AM audio output DEH-P490IB/XN/UC...
-
Page 70: Operational Flow Chart
In case of the above signal, the communication Source keys with Grille microcomputer may fail. operative If the time interval is not 300 msec, the oscillator may be defective. Source ON SYSPW←H Pin 1 Completes power-on operation. (After that, proceed to each source operation.) DEH-P490IB/XN/UC... -
Page 71: Operations
8. OPERATIONS Press and hold to select bass boost setting menu. DEH-P490IB/XN/UC... - Page 72 CND1250 CND1249 BPZ20P060FTB DEH-P490IB/XN/UC...
- Page 73 - Connection Diagram DEH-P490IB/XN/UC...
- Page 74 CD Mechanism Module Before shipping out the product, be sure to clean the following portions by using the prescribed cleaning tools: Portions to be cleaned Cleaning tools CD pickup lenses Cleaning liquid : GEM1004 Cleaning paper : GED-008 g p p DEH-P490IB/XN/UC...
