Summary of Contents for Indesit KP 59 MS.C X
- Page 1 Cooker Maxioven KP 59 MS.C (X)/G Instructions for installation and use...
- Page 2 Cooker Maxioven Instructions for installation and use...
-
Page 3: Safety Precautions
Congratualtions on choosing an INDESIT appliance, which you will find is dependable and easy to use. We recommend that you read this manual for best performance and to extend the life of your appliance. Thank you. SAFETY PRECAUTIONS THESE INSTRUCTIONS ARE ONLY VALID FOR THE COUNTRIES OF DESTINATION WHOSE SYMBOLS ARE SHOWN IN THE BOOKLET AND THE APPLIANCE RATING PLATE. -
Page 4: Cooker Description
COOKER DESCRIPTION A Auxiliary gas burner T Cooking programmer B Semi-rapid gas burner S Electric oven operation indicator light C Rapid gas burner G Electric oven selector knob (cooking function D Triple ring gas burner selection) R Support Grid for Cookware H Electric oven thermostat knob (temperature M Control Knobs for Gas Burners selection) -
Page 5: Hob Operation
INSTRUCTIONS FOR USE When a liquid starts boiling, it is advisable to turn the flame HOB OPERATION down just enough to keep the liquid simmering. The hob is fitted with a pan reducing support (fig.1), which The burners are fitted with automatic ignition and a should only be used on the auxiliary burner "A"... - Page 6 Indicator light "S" • With this (fan assisted)mode heat is transmitted to (figure a on page 2) It indicates that the oven is heating up. the food through pre-heated air made to circulate inside When the light goes out, the required temperature has been the oven by a fan.
-
Page 7: Maintenance And Cleaning
MAINTENANCE AND CLEANING Disassembling/assembling the oven door Before cleaning your oven, or performing maintenance, disconnect it from the power supply. To make it easier to clean the inside of your oven, the To extend the life of your oven, it must be cleaned frequently, oven door can be removed, by proceeding as follows (fig. -
Page 8: Cooking Programmer
COOKING PROGRAMMER The electronic programmer has the function of automatically switching on the oven (at the required time) and switching it off at the end of the set cooking time. The 4 figure luminous display showing the actual time and the programming times, also shows the current state of the oven by means of the following symbols: Oven on... -
Page 9: Cooking Tips
COOKING TIPS Cooking times may change according to the nature of the foods, their homogeneity and their volume. When cooking a certain food for the first time, it is advisable to choose the lowest values in the cooking time range given in the table and then increase them if necessary. -
Page 10: Installation
INSTALLATION Kitchen ventilation The air flow into the room where the appliance is installed must equal the quantity of air that is required for regular combustion of the gas and for ventilating the same room. Air must be taken in naturally through permanent apertures made in the outside walls of the room or through single or branching collective ventilation ducts in compliance with current standards and regulations. -
Page 11: Electrical Connection
Gas supply connection Adjusting the low flame • Check that the appliance is set for the type of gas available • Put the tap to the low flame position (the burner should and then connect it to the mains gas piping or the gas be lit);... -
Page 12: Burner And Nozzle Specifications
TECHNICAL SPECIFICATIONS or coloured Green or Green & Yellow. Connect the Brown wire to the terminal marked “L” or coloured Red. ENERGY LABEL Connect the Blue wire to the terminal marked “N” or Directive 2002/40/EC on the label of electric ovens coloured Black. - Page 13 Merloni Elettrodomestici Viale Aristide Merloni 47 60044 Fabriano Italy Tel +39 0732 6611 Fax +39 0732 662501 www.merloni.com...
