- Page 1 ULTRA REVERSE OSMOSIS SYSTEM INSTALLATION INSTRUCTION AND OWNER’S MANUAL Free Drinking Water .Com...
- Page 2 TDS Meter = A digital meter for measuring the TDS level in the water Copyright: This manual is copyrighted by APEC Inc. Under the copyright laws, this manual may not be reproduced in any form, in whole or part, without the prior written consent of APEC Inc.
- Page 3 Part I. HOOK UP THE RO SYSTEM TO YOUR HOME FAUCET RO hook up: Remove your faucet’s aerator (if there is one). Hook up the RO system’s faucet Adapter to your faucet (see Figure A). If the connection does not match, try using the other Valve Adapters provided. Figure A A.
- Page 4 4. Flushing system: Let the RO run for 10-15 minutes to flush out the new Membrane – discard the output water during the flush. When done flushing, the fresh pure water is now ready for your enjoyment! Part II. MAINTENANCE – FILTER CHANGE * Quick Connect Guide: Connect Tubing Press Down on collet To Pull Out Tubing...
- Page 5 Stage-1: Sediment Filter (Manufacturer Part# K2505 filter) Change every 6 months or 600-800 gal pure water used: Figure D (Back View Of System) The Stage-1 Sediment filter is tucked behind the membrane housing. For ease of access, pull and lift the 2 stage filter to the top position.
- Page 6 Stage-2 Pre-Carbon Filter (Manufacturer Part# K2533 filter) Change every 6 months or 600-800 gal pure water used: Figure E (Back View Of System) The Stage-2 Pre-Carbon filter is located between Stage-1 and Stage-4 filters (see Figure E). Locate it, and follow these steps: Step 1.
- Page 7 5 years depending on your input water’s quality. The Membrane needs replacing when: The TDS (total dissolved solids) level in the pure water starts to increase (detected by a TDS meter from APEC), or when the water taste quality starts to decline. Replace the Membrane as follows: 1.
- Page 8 Stage-4 Post-Carbon Filter (Manufacturer Part# K2533 filter) Change every 2-5 years: Figure G Figure H Front View Of System Follow the same procedures as for changing the Stage-2 carbon filter. They are identical 10” carbon filters. To remove the Pure water output line, first use a pair of pliers and remove the tubing lock (red clip) from Point K.
- Page 9 RO-Ctop Pure Water Production Rate Input Water Pressure Time to fill 8 oz cup Time to fill 1 gallon jug Gallons Per Day 60 psi 60 seconds 16 minutes 90 gpd 50 psi 72 seconds 19.2 minutes 75 gpd 40 psi 90 seconds 24 minutes 60 gpd...
-
Page 10: Warranty Policy
WARRANTY POLICY For a period of one year from the date of original purchase, APEC will replace any part of the reverse osmosis system which APEC finds to be defective in operation due to faulty materials or workmanship with the exception of the replaceable filters and membrane which shall be prorated. - Page 11 Advance Purification Engineering Corp. 17085 Green Drive City Of Industry, CA 91745 For questions or comments please visit our website at: Free Drinking Water.Com For technical support contact us at: Techsupport@freedrinkingwater.com 1-800-880-4808...
