- Page 1 ULTIMATE REVERSE OSMOSIS SYSTEM INSTALLATION INSTRUCTION & OWNER’S MANUAL Ver 3.2 All Rights Reserved © APEC Water Systems...
-
Page 3: Table Of Contents
Please keep this Owner’s Manual for future reference. It contains useful information on how to maintain and care for your APEC Reverse Osmosis water filter system. TABLE OF CONTENT Installation: Preparation ..............page 1 Filter housings assembly ..........page 5 Feed water connection ............ -
Page 4: Installation
Copyright: This manual is copyrighted by APEC Inc. Under the copyright laws, this manual may not be reproduced in any form, in whole or part, without the prior written consent of APEC Inc. Manual print ver. 3.2, 2015 Jul. - Page 5 Components included with the RO system: Make sure you have all these parts before starting installation. 1 RO system head 3 Pre-filters in 3 Housings 1 Storage tank with pre installed membrane Installation kit includes: 1 Drain saddle for waste water 1 Faucet with 1 Feed water adaptor washers and nuts...
- Page 6 Component Itemization: Sediment pre-filter and housing (1 -stage filter) Carbon block pre-filter and housing ( 2 -stage filter) Carbon block pre-filter and housing ( 3 -stage filter) Membrane and housing (4 -stage filter) In-line carbon filter (5 -stage filter) Storage tank Tank ball valve ASO –...
- Page 7 There are 2 types of fittings provided for connecting the system Fitting Types: 1. Quick-Connect (QC) fitting: (no insert, sleeve, or nut Most of the fittings on the RO unit are this type. Fig. 1A Fig. 1 How to Connect: - See Fig.1.
-
Page 8: Filter Housings Assembly
Stand the 3 housings upright. Make sure each housing has a rubber O-ring in its Fig. 2 groove. Put the APEC Sediment filter (1-SED10) into the “1 stage” housing on the right. Put the APEC Carbon filter (23-CAB10) into the “2 stage”... -
Page 9: Feed Water Connection
Another option is to use a “self piercing saddle valve” from APEC or from a local hardware store. 2. Feed Water Adaptor (1/2” to 3/8”): See Fig. 5. The Feed Water Adaptor comes with a separate Needle Valve. - Page 10 Fig. 5A - Needle Valve Installation. Attach the needle valve (C) to water supply adapter (A). Please apply 5-6 wraps of teflon tape to needle valve prior to connecting it to the water supply adapter (A). Fig. 5B - If your pipe has a 1/2” Connection. By attaching the 1/2”...
- Page 11 3. Recommend Connection For Flex Line Riser: See Fig.6A. & Fig. 6D. Loosen nut and separate cold water riser tube from faucet shank. Gently bend riser tube so that the Feed Water Adapter (Fig 5) fits onto the faucet shank. If your riser tube has no built-in washer, then fit the cone-shaped washer provided onto the riser tube.
- Page 12 Fig. 6C Fig. 6D Fig. 6E 4. Needle Valve: See Fig. 6C. Screw the Needle Valve onto the Adaptor tightly. Apply 6-8 rounds of Teflon tape onto Needle Valve before attaching it to the Adaptor. To open needle valve: Turn needle handle counter-clockwise. To close needle valve: Turn needle handle clockwise.
-
Page 13: Drain Saddle Connection
Step 2: Drain Saddle Installation Note: To avoid annoying drainage noise, mount drain line as low as possible on the vertical tailpiece, or on horizontal tailpiece. There is constant water pressure “packed” inside the RO system which blocks the waste water from backing-up into the system. - Page 14 3. See Fig.9, 9A. Make sure to align the drain saddle hole to the drilled hole perfectly. Mis-aligning these two holes will block the waste water and cause membrane damage. Attach the drain saddle to the drain pipe and tighten the two screws evenly. Fig.
-
Page 15: Faucet Mounting
3. For Porcelain Sink: Porcelain enameled sinks can readily be chipped if care is not exercised when drilling the hole. Before starting the drill motor, apply firm downward pressure on the bit until a crunching occurs. This will help keep the drill bit from walking when starting the hole. A small pilot hole will also aid the drill bit. -
Page 16: Connecting The Whole System
-stage membrane to drain outlet — Black tubing. Please Note: The diagram below is for our Non Pump RO-45, RO-90 and RO-PH90. If you are installing the RO Perm or RO Pump, please refer to the diagram in the addendum. - Page 17 Fig. 11A Details on Tubing Connections: To ensure a smooth and correct installation, please connect the water lines following the se- quence and order outlined below. Refer to Fig.11 & 11A for proper point locations. 1. Point Z Faucet connection: Tubing color: Clear tubing.
- Page 18 3. Point W Waste water connection: Tubing color: Black tubing. Connect the BLACK tubing from the RO to the Drain Saddle. Fitting type: Quick-Connect fitting on drain saddle. No teflon tape. Do Not add ”insert” into Black tubing. Simply push tubing into port. 4.
- Page 19 7. Point Y Tank’s input & output connection: Prepare tank: See Fig.12. Apply 6-8 wraps of Teflon tape to tank’s threaded Output stem on top of tank (remove rubber cap if there is one). Screw tank Valve onto Output stem. Tubing color: Yellow tubing.
- Page 20 Using RO for Ice-maker only: If you want the RO to feed your ice-maker (fridge) only, you should still connect the RO faucet as a 2nd outlet. This allows you to drain the tank, flush new filters through the faucet rather than through your icemaker line.
-
Page 21: Maintenance
RO system will be contaminated. It’s best to use APEC replacement filters. Using “non APEC” and lesser qual- ity filters may clog up the RO system and damage the membrane. - Page 22 2) Open housing: Have the RO standing upright. Slip the plastic wrench onto the #1 housing. Looking down from a top view, you should open the housing turning clockwise. If necessary, lay RO down on the floor to get a better leverage. If the housing is too tight, use a hammer and tap on the wrench handle to help turn the wrench.
- Page 23 5) Check for leaks! 6) Drain the first tank of water (through faucet) to flush out the new membrane! The 2 tank of water is ready for use. Fig. 14A Fig. 14B How to Replace Stage-5 Carbon Filter: Replace this last filter at the same time you replace the stage-4 membrane. 1) Remove the OLD filter: See Fig.14 A.
- Page 25 OWNER’S MANUAL Please read this section for useful RO system and maintenance information. TABLE OF CONTENT Part I: RO Basics Basic terms ................. page 23 System flow diagram ..............page 23 Water pressure -- The most important factor ......page 24 TDS meter -- How to test your water quality with meter ....
-
Page 26: Owner's Manual - Ro Basics: System Flow Diagram
Product (filtered) water from the membrane feeds the storage tank; the “brine water” from the membrane drains out through the drain line. Product water from the tank passes through stage-5 filter before reaching the dispensing faucet. TANK APEC RO SYSTEM FLOW DIAGRAM BALL VALVE FAUCET... -
Page 27: Input Water Pressure: Most Important Factor
3) Water Pressure – The Most Important Factor! RO systems run on water pressure. Therefore your water pressure has the most direct effect on how well your RO will perform. With sufficient water pressure (85 psi max.), your RO system will function well, give high output with high rejection rate, and fill up the storage tank quickly. -
Page 28: Tank Volume & Delivery Pressure
6) How Full Can My Tank Fill Up? Your incoming water pressure determine how full and how fast the storage tank will be filled up. The stronger your input water pressure, the faster and fuller the tank can fill. If water pressure is low, the tank will fill slower and will not fill up to its full capacity. -
Page 29: Misc. Topics
delivery pressure: 14-gallon tank’s 10 gallons —> 50 psi output pressure ( pressure inside tank ) 9.0 gallon —> 40 psi 7.8 gallon —> 30 psi 6.1 gallon —> 20 psi 3.3 gallon —> 14 psi 1.6 gallon —> 10psi Tank empty —>... -
Page 30: How To Test Your Water Pressure
11) How to Test Your Water Pressure: Get a water pressure gauge that adapts onto your sink or garden faucet (from hardware store), attach gauge onto faucet, turn water on to FULL, then take a reading. For some areas, water pressure is lower during the day and higher at night when less people are using water. -
Page 31: Trouble-Shoot Guide
Part II: Trouble-Shoot Guide For Newly Installed RO System After installation, if you encounter any of the problems described below, please follow this guide to troubleshoot. In most cases, the problem is quickly solved by following this guide. Non-Pumped RO HEAD DIAGRAM Fig. -
Page 32: Humming Noise
If the noise persists after a few days, that means there is air in your water source, or the current Check Valve is resonating with your water pressure and pipes, creating the noise. In this case, a new Check Valve will solve the problem. Contact APEC customer service for assistance. - Page 33 Output line is crimped —> Remove crimp Incorrect installation —> See Fig.11 & 11A. Verify all line connections. Tank defective, no pre-charge pressure —> Set tank pre-charge to 5-7 psi. ASO connection Error —> See Fig. 18A and Fig. 18B to reconnect ASO to the correct connection.
-
Page 34: System Slow Shut-Off
3) Sluggish Flow At Dispensing Faucet Insufficient water pressure (see “ ” for explanation) —> Check water pressure. If too RO Basics low for this chosen RO model, either increase your water pressure or add pump to RO system. Input water to RO is blocked —> Make sure Feed water valve is fully opened and unhindered. Tank not filled yet —>... - Page 35 Input pressure way too low (below 30psi). Not enough pressure to shut off the RO at all —> Check input water pressure. If pressure is below 30psi, need switch to Booster-Pumped RO model. Contact APEC customer service for assistance. One of the shut-off valves is defective, so RO cannot shut off —> Do a shut-off test to determine which valve is defective.
-
Page 36: Tds Level Higher Than Normal
Test#2: Test Check Valve and ASO valve: Make sure there is some water in the tank (tank not empty). Remove the Black drain line from the drain saddle (so you can check waste flow drainage). Turn OFF the Cold feed water supply. Turn ON the tank valve. -
Page 37: Filter Housing Is Leaking
Do Not over tighten the housing. Step 4. Open the tank ball valve and feed water line. Check for leaks. If the filter housing contin- ues to leak, please contact APEC technician for replacement assistance. -
Page 38: Tank Ball Valve Is Leaking
RO units will remove 90-95% of contaminants and impurities in the water. If the pure water is not at 90% or higher, please contact an APEC technician for assistance. 12) Air Bubbles: Lots of Air bubbles in cup or bottle when filling It is quite normal to see air bubbles in a cup of pure water. -
Page 39: Other Information
OTHER INFORMATION AirGap Faucet Installation There are 3 colored tubings on your Air-Gap faucet. At the end of each 1/4” tubing there is a “Quick Connect” fitting. The Quick Connect fittings is used to connect the Pure and Waste water line from the RO unit to the Air Gap Faucet. - Page 40 How wastewater is disposed via Air-Gap faucet: Waste water is routed through the Air-Gap faucet prior to being drained off into the standard drain- pipe outlet. The 1/4” BLACK waste water line from the RO system will discharge through the 1/4” RED line to the Air-Gap faucet.
-
Page 41: Warranty
(1) year from the date of purchase, the Product will be reasonably free of defects in materials and workmanship. Within that one (1) year period from the original purchase, APEC will, at its option, repair or... - Page 42 4. The Product is purchased from someone other than APEC or one of APEC’s authorized dealers. This is because, unless the Product was sold by APEC or one of its authorized dealers, APEC cannot verify or guarantee the integrity or authenticity of the Product.
