APEC ULTRA REVERSE OSMOSIS SYSTEM Installation Instructions Manual

Hide thumbs Also See for ULTRA REVERSE OSMOSIS SYSTEM:

Advertisement

Quick Links

Download this manual See also: Installation Instructions & Owner's Manual
ULTR A REVERSE OSMOSIS SYSTEM
INSTALLATION INSTRUCTION
Free Drinking Water .com

Advertisement

loading
Need help?

Need help?

Do you have a question about the ULTRA REVERSE OSMOSIS SYSTEM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for APEC ULTRA REVERSE OSMOSIS SYSTEM

Summary of Contents for APEC ULTRA REVERSE OSMOSIS SYSTEM

  • Page 1 ULTR A REVERSE OSMOSIS SYSTEM INSTALLATION INSTRUCTION Free Drinking Water .com...
  • Page 2 Please keep this Owner’s Manual for future reference. It contains useful information on how to maintain and care for your APEC Reverse Osmosis water filter system. TABLE OF CONTENT Installation: Preparation ..............page 1 Filter housings & membrane assembly ......page 4 Feed water connection ............
  • Page 3  Install the RO in a sheltered environment, avoid exposure to hot and cold weather or under direct sun light. Copyright: This manual is copyrighted by APEC Inc. Under the copyright laws, this manual may not be reproduced in any form, in whole or part, without the prior written consent of APEC Inc.
  • Page 4 Components included with the RO system: Make sure you have all these parts before starting installation. 1 RO system head 3 Pre-filters in 3 Housings 1 Storage tank 1 RO Membrane Installation kit includes: 1 Faucet with 1 Feed water adaptor 1/2” 1 Drain saddle for waste water washers and nuts with needle valve kit...
  • Page 5 Component Itemization: Bracket Membrane and housing (4 -stage filter) In-line carbon filter (5 -stage filter) Sediment pre-filter and housing (1 -stage filter) Carbon block pre-filter and housing ( 2 -stage filter) Carbon block pre-filter and housing ( 3 -stage filter) Storage tank Tank ball valve ASO –...

  • Page 6: Table Of Contents

    THERE ARE THREE PARTS TO INSTALLING THE RO SYSTEM: Part I. Assemble the filters and housings onto the main system Part II. Placing the Membrane into the membrane housing Part III. Installing the system PART I. ASSEMBLE THE FILTERS AND HOUSINGS ONTO THE MAIN SYSTEM Remove plastic/paper wrappings on the 3 filters, put them into the 3 housings, and assemble the housings onto the main system as follow: Fig.
  • Page 7 PART II. PLACING THE MEMBRANE INTO THE MEMBRANE HOUSING This system has been wet tested in the factory, and the RO membrane is sealed to preserve freshness. 1. Locate the blue membrane and remove it from the plastic bag. 2. Locate the Membrane Housing (labelled “Membrane” ) on the system. 3.
  • Page 8 Another option is to use a “self piercing saddle valve” from APEC or from a local hardware store. 2. Feed Water Adaptor (1/2”): See Fig. 5. The Feed Water Adaptor comes with a separate Needle Valve.

  • Page 9: Fig. 5

    Sink Sink Faucet Faucet Shank Shank FLAT WASHER Needle Needle Valve Valve NEEDLE Riser Riser VALVE Tube Tube Main Water Main Water Supply Supply *Wrap Teflon Tape! Shut-off Shut-off Valve Valve CONE WASHER (optional) For Flexible Line For Solid Line Fig.

  • Page 10: Fig. 6

    Test for leaks at this point: Close the Needle Valve (turn needle handle clockwise all the way in to close) Turn ON the cold water supply to the sink faucet. If the Needle Valve or the Adaptor leaks, check the connection and try applying more Teflon tape or tighten the brass nut some more to stop the leak.
  • Page 11 3. See Fig. 8, 8A. Make sure to align the drain saddle hole to the drilled hole perfectly. Mis-aligning these two holes will block the waste water and cause membrane damage. Attach the drain saddle to the drain pipe and tighten the two screws evenly. Fig.8A Step 3: Drill A Hole For The RO Faucet Drill 1/2”...

  • Page 12: Fig. 9

    3. For Porcelain Sink: Porcelain enameled sinks can readily be chipped if care is not exercised when drilling the hole. Before starting the drill motor, apply firm downward pressure on the bit until a crunching occurs. This will help keep the drill bit from walking when starting the hole. A small pilot hole will also aid the drill bit.

  • Page 13: Fig. 10

    Step 5: Positioning The System 1. Main System: The main system can stand in the sink cabinet. No need to mount the system to the wall. 2. Tank: The storage tank can also lay on its side if needed. The tank works fine in this posi- tion.
  • Page 14 How to connect: - See Fig. 10A. Slide the compression nut onto the tubing. - Insert the into the tubing. “insert” - Insert the tubing into the opening of the fitting. - Slide the nut up, then tighten nut with a wrench. No Teflon tape! 3.

  • Page 15: Fig. 11

    Fig. 11 Fig. 11A...
  • Page 16 Details on Tubing Connections: To ensure a smooth and correct installation, please connect the water lines following the se- quence and order outlined below. Refer to Fig. 11 & 11A for proper point locations. 1. Point Z Faucet connection: Tubing color: Clear tubing.

  • Page 17: Fig. 12

    Tubing color: Clear tubing. Connect the CLEAR tubing from the faucet base stud to the Stage-5 filter’s outflow end at point H. (See “Flow -->” arrow on the filter for flow direction.) Fitting type: Plastic compression nut fitting with built-in sleeve. No teflon tape needed here. 6.
  • Page 18 Using RO for Ice-maker only: If you want the RO to feed your ice-maker (fridge) only, you should still connect the RO faucet as a 2nd outlet. This allows you to drain the tank, flush new filters through the faucet rather than through your icemaker line.
