TX1 He OPERATING MANUAL

TX1 He

DIVE COMPUTER

OPERATING MANUAL

Doc. 12-4101-r06 (1/21/14)

Table of Contents

Need help?

Do you have a question about the TX1 He and is the answer not in the manual?

Questions and answers

Summary of Contents for Hollis TX1 He

Page 1: Dive Computer
TX1 He OPERATING MANUAL TX1 He DIVE COMPUTER OPERATING MANUAL © 2002 DESIGN (2014) Doc. 12-4101-r06 (1/21/14)
Page 2: Table Of Contents
TX1 He OPERATING MANUAL CONTENTS WELCOME..................4 DIVE MODE FEATURES...............34 WARNINGS..................5 PROXIMITY OF THE TMTS AND TX1 He......35 NOTICES....................6 Link Interruption Underwater..........35 FCC ID....................6 WET ACTIVATION..............36 SMARTGLO® BACKLIGHT..........36 FEATURES & FUNCTIONS............7 BAR GRAPHS................36 ABBREVIATIONS/TERMS............8 TLBG..................36 DISPLAY ICONS...............9 VARI..................36 CONTROLS................10 ALGORITHM................37 BUTTON NAVIGATION............11 GRADIENT FACTOR (GF)...........37...
Page 3 TX1 He OPERATING MANUAL SET GROUPS SET A (ALARMS)..............54 SET U (UTILITIES)............54 SET T (TIME/DATE)............54 SET S (SHORTCUT) MENU..........55 SET D (DIVE MAIN) MENU...........55 SET P (PREVIEW) MENU..........56 GAUGE DIVE SCREENS............57 GAUGE DIVE MAIN..............57 GAUGE DIVE ALT..............57 GAUGE CHANGE TMT SCREENS........58 GAUGE TMT SWITCH............58...
Page 4: Welcome
TX1 He. The TX1 He was designed to create a user friendly dive computer that allows the use of Air, Nitrox, and Trimix. It is a powerful instrument indeed - with a digital compass, gauge mode, use of up to six transmitters, Gradient Factors, Hollis Dive Planning Software, and many more features to be discussed within.
Page 5: Warnings
If you dive in situations where your trip would be ruined or your safety would be jeopardized by losing the use of your TX1 He, a backup instrument system is highly recommended.
Page 6: Notices
The program within the TX1 He simulates the absorption of inert gases into the body by using a mathematical model. This model is merely a way to apply a limited set of data to a large range of experiences. The TX1 He dive computer model is based upon the latest research and ex- periments in decompression theory.
Page 8: Abbreviations/Terms
TX1 He OPERATING MANUAL ABBREVIATIONS/TERMS ACTIV = Activation = Minutes (time) = Alarm = Maximum Operating Depth = Alternate = North (compass) = Standard Atmosphere (unit) = No Deco DTR = Audible = No Deco Limit AVAIL = Available = Northeast (compass)
Page 9: Display Icons
TX1 He OPERATING MANUAL DISPLAY ICONS SURF Dot Matrix PO2 BAR 1 Low Battery Indicator p. 15 7 Value is PO p. 46 2 Log p. 21 8 Pressure ID (units) p. 29 3 Value is Time 9 Temperature or Heading p.
Page 10: Controls
PO2 BAR BUTTONS The TX1 He utilizes 3 Control Buttons that allow you to select mode options and access specific information. They are also used to link the Transmitter(s), enter Settings, activate the Backlight, and acknowledge the Audible Alarm. Throughout this manual they will be referred to as the M, A, and S buttons.
Page 11: Button Navigation
TX1 He OPERATING MANUAL BUTTON NAVIGATION ACTION BUTTON FUNCTION Press Button Activate TX1 He • to access Menu SURF • to scroll up the screen (backward) through Menu selections TLBG VARI PO2 BAR • to return to Surface Main SURF...
Page 12: Activation
TX1 He OPERATING MANUAL ACTIVATION To activate the TX1 He, press/release any button. SURF • The unit will enter Diagnostic Mode displaying all segments of the LCD as 8's, fol- TX 1 lowed by dashes ( - - ), then a countdown from 9 to 0. It checks the display and volt- DIAGNOSTICS age to ensure that everything is within tolerance.
Page 13: Audible Alarm
TX1 He OPERATING MANUAL AUDIBLE ALARM While operating in NORM or GAUGE Mode the Audible will emit 1 beep per second for 10 seconds when alarms strike, unless it is set Off. During that time, the Audible can be acknowledged and silenced by pressing the S but- ton (less than 2 seconds).
Page 14: Pc Interface
*Prior to attempting to Download data from your TX1 He or Upload Settings to it, review the HELP section of the HCI program. It is recommended to print those sections of HELP that you consider appropriate for your Interface activities.
Page 15: Tx1 He Low Battery While On Surface
TX1 He OPERATING MANUAL TX1 HE LOW BATTERY WHILE ON THE SURFACE if Low Batt ≤ 2.75 volts (warning level) SURF • Backlight is completely disabled. NORM • Battery icon (shell with inner bar) appears solid. DIVE 0 • If a dive is started, the icon is not displayed on the dive mode screens.
Page 16: Transition Period
TX1 He OPERATING MANUAL TRANSITION PERIOD, upon surfacing: Operation shifts from Dive Mode to Surface Mode upon ascent to 2 FT (0.6 M) for 1 second; however, Surface mode 'screens' will not be available until a Transition time elapses. The reason for this is that making a descent during the first 10 minutes after surfacing from a NORM or GAUGE dive, is a continuation of that dive.
Page 18: Norm Surf Main
TX1 He OPERATING MANUAL NORM SURF MAIN, information includes: > SI (hr:min) with Time (clock) and SURF icons; if no dive yet, this is time since acti- SURF vation. NORM > Graphic NORM (operating mode). DIVE 0 aır > Graphic DIVE and number of dives completed during that operating period, up to...
Page 19: Norm Menu
TX1 He OPERATING MANUAL NORM MENU Selections include: > GAS MENU. > FLY/DESAT. > PLAN. > LOG. > SET MENU. > OP MODE. > HISTORY > TX1 ID. > BATT/TMT > DIVE PREVIEW Norm Surf Main Surf Main Sel Menu...
Page 20: Fly/Desat Screen
TX1 He OPERATING MANUAL Fly/Desat, information includes: (PZ+) > Graphics FLY and DSAT with countdown times (hr:min) and Time (clock) icon, SURF dashes if no dive yet. 23:50 9:59 PLAN MENU TLBG PO2 BAR Selections include: > Time Limits. FLY/DESAT >...
Page 21: Norm/Gauge Log
TX1 He OPERATING MANUAL NORM/GAUGE LOG Information from the latest 24 NORM and/or GAUGE dives is stored for viewing. After exceeding 24 dives, the most recent dive is stored while the oldest is deleted. > Dives are numbered from 1 to 24 starting each time NORM (or GAUGE) Dive Mode is activated.
Page 22: Set Menu
TX1 He OPERATING MANUAL Log Data 3, (mix gas dive only), information includes: > Log (book icon). > O2 at the end of the dive (2 dashes if VGM or MOD exceeded), with graphic % O2 SAT. >Highest GF during the dive (2 dashed if VGM), with graphic GF MAX >...
Page 23: History (Norm/Gauge)
BATT/TMT Access to this selection activates the TX1 He's Receiver, then starts a transmit- SURF ter search. The battery status of the TX1 He wrist unit and all transmitters can be TX1 BATT GOOD >TMT1 BATT GOOD viewed from the same BATT/TMT Status screen. Refer to pages 24 and 33 for more TMT2 BATT LOW information.
Page 24: Gas Sub Menus
PO2 < 0.17 ATA Hypoxic Gas Warning (Mandatory Decline) PO2<0.17 CANNOT SWITCH Attempting to switch to a gas with a PO2 < 0.17 ATA results in the TX1 He display- TO HYPOXIC GAS >DECLINE ing the Hypoxic Gas Decline screen. This message must be aknowledged with the...
Page 25: Select Gases Menu
TX1 He OPERATING MANUAL 0.17 ≤ PO2 ≤ 0.21 ATA Hypoxic Gas Warning (Low PO2) Switching to a 0.17≤ PO2 ≤ 0.21 ATA gas will result in a warning screen. The diver may choose to proceed or not with the gas switch by confirming yes or no.
Page 26: Set Gases
Transmitters The TX1 He allows up to 6 transmitters to be utilized to monitor tank pressures. The Set TMT menu allows for the programming of the wrist unit to receive signals from transmitters. See the Dive Mode Features section (p. 35) for further information on transmitters.
Page 27: Set Transmitter Menu
SURF LINK CODE 123456 TLBG PO2 BAR to save set point to increase or decrease set point After the sixth digit is saved, the TX1 He will return to the Set TMT Menu. © 2002 DESIGN (2014) Doc. 12-4101-r06 (1/21/14)
Page 28: Set Groups
TX1 He OPERATING MANUAL SET GROUPS Information that follows describes the selections contained in the NORM Set Groups (A, U, T, S, D, P) that are accessed from the Set Menu. SET A (Alarms) Menu, information includes: > Graphics SEt A and MENU.
Page 29: Set U (Utilities)
TX1 He OPERATING MANUAL SET U (Utilities) Menu, information includes: > Graphics SEt U and MENU. Selections with their last Set Points saved include: > WET ACT with Set Point (ON or OFF) >> wet activation. > UNITS with Set Point (IMP or MET) >> imperial or metric.
Page 30: Set Gf (Gradient Factor)
TX1 He OPERATING MANUAL Set GF (Gradient Factor), information includes: > Graphics SET and GF. Selections with the last Set Point saved include: > CONS 1 = GF 90 • 90 > CONS 2 = GF 35 • 90 > CONS 3 = GF 30 • 85 >...
Page 31: Set T (Time/Date)
TX1 He OPERATING MANUAL SET T (Time/Date) Menu, information includes: > Graphics SEt t and MENU with Time (clock) icon. Selections with their last Set Points saved include: > DATE FORM with Set Point (M.D or D.M) >> date format, M.D = Month.Day, D.M = Day.Month >...
Page 32: Set D (Dive Main)
TX1 He OPERATING MANUAL SET D (Dive Main) Menu, information includes: > Graphics SEt D and MENU. The default screen for No Deco dives (except while at Stops) displays Current Depth, NDC time, Pressure, and GTR (gas time remaining). Items such as Max Depth and EDT (elapsed dive time) are displayed on Alternate screens.
Page 33: Set P Preview
TX1 He OPERATING MANUAL SET P (Preview) Menu, information includes: > Graphics SEt P and MENU. Using this menu, you can chose up to 4 items (Set Points that have been entered) for display on a Preview screen that can be accessed from the Surface Main Menu (see page 19).
Page 35: Proximity Of The Tmts And Tx1 He
TMT as illustrated. The TX1 He cannot effectively receive a signal when it is held out to the sides of the TMT or held at distances greater than 3 feet (0.91 meters) in front of the TMT. Best reception is achieved when the TX1 He is within less than 3 feet (0.91 meterS) of the...
Page 36: Wet Activation
The contacts are the metal pins of the PC Interface Data Port and the stems of the buttons. When Wet Activation is set OFF, the TX1 He will not enter Dive Mode unless it is first activated by push button and operating in a surface mode or it is a repetitive dive.
Page 37: Algorithm
The settings on the TX1 He allow for a GF Low and a GF High setting. The TX1 He requires the diver to select between 5 GF presets or custom settings (0% to 90%) for both the GF Low and GF High settings.
Page 38: Deep Stop (Ds)
DIVE TIME REMAINING (DTR) The TX1 He constantly monitors nitrogen loading and oxygen accumulation, and will display whichever time is the least amount available as DTR on the No Deco Dive Main screen. The graphic NDC, or OTR, will identify which time is being displayed.
Page 39: O2 Time Remaining (Otr)
Gas Consumption and Depth are continuously monitored and GTR reflects any change in circumstances. For example, when you suddenly find yourself swimming against a strong current and begin breathing more rapidly, the TX1 He will recognize the change and adjust GTR accordingly.
Page 40: Total Ascent Time (Tat)
TX1 He OPERATING MANUAL TOTAL ASCENT TIME (TAT) SURF Available only on an alternate (ALT) screen when in a decompression requirement, FTMAX TAT displays the total time to the surface. For calculation, TAT assumes a strict fol- lowing of the current decompression schedule and prescribed gas switches. It takes into acount all decompression stops and a standard ascent time between stops.
Page 42: Norm Dive Screens
TX1 He OPERATING MANUAL NORM DIVE SCREENS Norm Dive Main Norm Dive Alt 1 Norm Dive Alt 2 Norm Dive Alt 3 (default) SURF SURF 10:55 O2 SAT FTMAX TX 15/45 TX 15/45 GAS2 GAS2 TLBG VARI PO2 BAR PO2 BAR...
Page 43: Deep Stop Preview
TX1 He OPERATING MANUAL DEEP STOP PREVIEW, information includes: > Current Depth with FT (or M) icon. > Graphic DEEP STOP with Stop icon (arrows and bar). > Stop Depth with graphic FT (or M) and countdown Time as 2:00 (min:sec).
Page 44: Decompression
MISSED DECO WARNING If the warning and alarm are ignored, the TX1 He will continue calculating a less conservative decompression schedule at the depth the diver is currently at unless a gradient factor of 90 is exceeded. If the ascent schedule exceeds a gradient factor 90 the computer will enter Deco Ceiling Violation (see the following).
Page 45: Delayed Deco Violation (Ddv)
Mode). 100 FT 7 MIN TX 15/45 GAS2 After a full 10 minutes on the surface, the TX1 He will switch to VGM Surface Main TLBG PO2 BAR (Surface functions remain available). DELAYED DECO VIOLATION (on surface < 5 min)
Page 46: Gas Switch Warning
Warning >> when the actual gas is not the best gas at current depth. When there is required decompression, the TX1 He shall warn the diver about switch- ing to the best active gas available. The best gas is the gas with highest PO2 that is...
Page 47: High 02 Saturation
TX1 He OPERATING MANUAL Low PO2 during Deco If PO2 drops below 0.17 ATA, the Audible will sound during which the PO2 value with icon will flash in place of Pressure. DECO STOP > After the Audible is silenced, the PO2 value with icon will alternate with Pressure...
Page 48: Violation Gauge Mode (Vgm)
Isobaric Counter Diffusion (ICD) Warning During a gas switch the TX1 He will display a warning if there is a risk of ICD. The risk must be accepted or declined by selecting YES or NO in the ICD Menu. If de- clined the TX1 He will not complete the gas switch.
Page 49: Depth Limits
PO2 BAR CURRENT END WOB NOTE: The TX1 He allows the inclusion of oxygen as a narcotic gas by set- ting O2 NARC to yes in the Utilities Menu. If set to yes, oxygen is consid- ered equally narcotic as nitrogen. If O2 Narc is set to No, oxygen narcotic effect will be disregarded in END calculations.
Page 50: Deco Stops
TX1 He OPERATING MANUAL Deco Stops Deco Stops is a menu that displays all of the currently required decompression stops, times, and the gases to be used. Information includes: > Current Depth with FT or M icon. > PO2 value (x.xx ATA) with PO2 icon, replacing Pressure when option E is selected.
Page 52: Gauge Surf Screens
TX1 He OPERATING MANUAL GAUGE SURF SCREENS Gauge Surf Gauge Surf Gauge Surf Gauge Surf Main Alt 1 Alt 2 Alt 3 (PZ+) (PZ+) (PZ+) SURF SURF FT MAX 12:45 GAUGE 232 83 232 01:23 DIVE 0 TMT1 PO2 BAR...
Page 53: Gauge Menu
TX1 He OPERATING MANUAL GAUGE MAIN MENU Selections include: > SWITCH TMT > FLY. > LOG. > SET MENU. > OP MODE. > HISTORY. > TX1 HE ID. > BATT/TMT > DIVE PREVIEW Gauge Surf Gauge Surf Gauge Surf Gauge Fly...
Page 54: Switch Tmt Sub Menu
TX1 He OPERATING MANUAL SWITCH TMT SUB MENUS Information that follows describes the sub menus (GAUGE TMT SWITCH, TMT SWITCH CONFIRMATION, SEARCHING TMT) that are accessed from the Gauge SURF Main Menu. Gauge Surf Gauge TMT Switch Menu Searching for TMT...
Page 55: Set S (Shortcut) Menu
TX1 He OPERATING MANUAL SET S (Shortcut) Menu, information includes: > Graphics SEt S and MENU. Selections include: > LOG MENU. > MY INFO (default Shortcut until another item is selected) > SET HEADING. > SET TIME. Gauge Set S Menu...
Page 56: Set P (Preview) Menu
TX1 He OPERATING MANUAL SET P (Preview) Menu, information includes: > Graphics SEt P and MENU. Using this menu, you can chose up to 4 items (Set Points that have been entered) for display on a Preview screen that can be accessed from the Surface Main Menu.
Page 57: Gauge Dive Screens
TX1 He OPERATING MANUAL GAUGE DIVE SCREENS Gauge Dive Main Gauge Dive Alt (optional main, no timer) (timer not on) SURF FT MAX 10:55 TMT1 PO2 BAR VARI PO2 BAR back to main Gauge Dive Main (using timer, default main)
Page 58: Gauge Change Tmt Screens
TX1 He OPERATING MANUAL GAUGE DIVE CHANGE TMT SCREENS Gauge Dive Main Gauge TMT Switch Menu Searching for TMT (optional main, no timer) (PZ+) (PZ+) (PZ+) SURF SURF SURF SURF >USE DEFAULT >TMT 2 23:50 FT MAX SEARCHING FOR ---...
Page 60: Compass Display Icons
(press S button to extend time) ! WARNING: You must become thoroughly familiar with setup and operation of the TX1 He Digital Compass before using it as your primary device for navigation. Failure to do so could result in seri- ous errors relating to activities involving navigation.
Page 61: Overview
TX1 He OPERATING MANUAL OVERVIEW > Compass OP Mode selected (North or Reference) - remains until changed. > Reference OP Mode - can set a course, then also select a Reverse course while on the surface and during dives. > Numeric values are displayed as 3 digits (000 to 360°), have a resolution of 001°,...
Page 62: Reference Op Main
TX1 He OPERATING MANUAL REFERENCE OP MAIN, information includes - > Current Depth with FT (or M) icon, Surface Interval during first 10 min on surface, blank on surface > 10 min. > Reference Mode icon (2 bars with arrow) with numeric Reference heading (course) set below it.
Page 63: Calibration
TX1 He OPERATING MANUAL Reverse Ref Heading, information includes - > Current Depth with FT (or M) icon, blank on surface. > Reverse Mode icon (2 bars with arrow) with reverse Heading (180° opposite of Reference Heading set) below it (flashing).
Page 64: Declination
TX1 He OPERATING MANUAL DECLINATION Magnetic Declination is taken from numbers provided on maps or charts that apply to a specific location. The numbers represent the easterly or westerly angular difference (Declination) in degrees between magnetic North and true (geometric or polar) North.
Page 65: Reference
REFERENCE CAUTION: When the procedure provided in this section is used to change the TX1 He battery, you must be sure that the case O-ring is not pinched and that the TX1 He is water tight before conducting diving activities.
Page 66: Pc Interface
TX1 He OPERATING MANUAL PC INTERFACE The TX1 He is configured with a Data Port that enables it to be connected to a PC through a USB port using a special Interface Cable supplied or available as an optional accessory.
Page 67: Care And Cleaning
Protect the lens against scratches with a Instrument Lens Protector. Small scratches will naturally disappear underwater. • Soak and rinse the TX1 He in fresh water at the end of each day of diving, and check to ensure that the areas around the low pressure (depth) sensor, PC interface data port, and buttons are free of debris or obstructions.
Page 68: Battery Replacement
OPEN water into the unit. Damage due to improper Battery replacement (or sub- sequent leakage of moisture into the unit) is not covered by the TX1 He's 2 year warranty. When replacing the Battery in the TX1 He, it is recommended that you also consider replacing the Battery(s) in the Transmitter(s) to be used, and vice-versa.
Page 69: Inspection
• Orient the Retaining Bar across the lower portion of the Battery and carefully push it down into position. • Replace the Cover O-ring with a new one which must be a genuine Hollis part that can be purchased from an Authorized Hollis Dealer.
Page 70: Testing
TX1 He OPERATING MANUAL Testing > Ensure that the LCD is clear and sharp in contrast. If any portions are missing or appear dim, or if a Low Battery condition is indicated, return the TX1 He with Trans- DATA >SAVE? mitter to an Authorized Hollis Dealer for evaluation before use.
Page 71: Installing A Transmitter On A Regulator
If the TX1 He Resets (i.e.; is On, turns Off, then turns On again) for any reason dur- ERROR ing any dive, inert gas, O2, and GTR calculations are terminated (upon turning Off).
Page 72: Wrist Strap
(P/N 204.2365) and the standard elastic band version. The shock cord version is excellent if you will routinely mount the TX1 He in the same position and use the same thermal protection. In this scenario the shock cord version will only need to be adjusted once.
Page 73: Adjusting The Shock Cord Version
TX1 He OPERATING MANUAL Adjusting the Shock Cord Version (P/N 204.2365) The shock cord should be fitted in position over any gloves, wetsuit, or drysuit. Keep in mind neoprene compresses with depth, and compensate the tension accordingly. • Knot one end of the shock cord.
Page 75: Specifications
> Pressure < 50 PSI (3.5 BAR) TMT Compatibility with Nitrox • When packaged and shipped from the factory, Hollis Transmitters are rated for use with compressed Air and Nitrox mixtures containing up to 99% O2 by volume and with 100% O2.
Page 76 TX1 He OPERATING MANUAL BAR GRAPHS: TLBG segments • No Deco Normal zone 1 to 3 • No Deco Caution zone • Decompression zone 5 (all) VARI 60 FT (18 M) & Shallower Deeper than 60 FT (18 M) segments...
Page 77 TX1 He OPERATING MANUAL ! WARNING: If your TX1 He stops working for any reason while operating, it is important that you have anticipated this possibility and are prepared for it. This is an important reason for not push- ing the tables, oxygen exposure limits, and a critical reason to avoid entering decompression, without proper training.
Page 78 TRANSMITTER 3 SERIAL NUMBER: TRANSMITTER 4 SERIAL NUMBER: TRANSMITTER 5 SERIAL NUMBER: TRANSMITTER 6 SERIAL NUMBER: DATE OF PURCHASE: PURCHASED FROM: Below to be filled in by an Authorized Hollis Dealer: Date Service Performed Dealer / Technician HOLLIS USA 2002 Davis Street...
