ADJUSTING THE STITCH LENGTH
The stitch length is changed by
pressing down the button (D, Fig. 2) in
the bed plate of the machine and by simultaneously
turning the handwheel slowly toward you.
In due course, the plunger will enter into a notch
in the feeding mechanism.
Hold the plunger down and continue to turn the
handwheel, either forward or rearward, until the
marking with the desired number of stitches on the
handwheel coincides with the reference mark on the
arm. Then release the plunger.
REVERSE STITCH
To do tacking for the purpose of locking the ends of seams, rapidly depress and release
the lever (4, Fig. 15)..
When reversing feed of the machine, keep the lever (4) depressed as long as required.
For all other forward stitching, the lever remains in up position.
ADJUSTING THE LIFT OF THE ALTERNATING PRESSER FEET
The thickness of the material sewn should control the height of the lift of the alternating
presser feet.
It should normally be just high enough for clearance of the material. With normal
adjustment both feet lift to equal height.
To adjust the lift, loosen the wing nut (1), move up the nut to raise the lift and push
down this nut to lower the lift.
When altering the lift of the lifting presser foot unequally against that of the vibrating
presser foot or vice versa, see the instructions 2. " ADJUSTING THE HEIGHT OF THE
PRESSER FEET ".
Numerals on pulley
show number of
length(m/m)
stitch per inch
3
4
5
6
7
8
9
10
12
16
20
24
Stitch
9
6.5
5
4.2
3.6
3.2
2.8
2.5
2.1
1.6
1.2
1
7
