Daewoo DWC-LU1011 Service Manual page 19

No. PARTS NAME
D01 BALANCER WEIGHT L
D02 SPECIAL SCREW
D03 BALANCER WEIGHT R
D04 CLAMP GASKET AS
D05 GASKET
D06 GASKET
D07 NOZZLE SHOWER
D08 CLAMP GASKET BUSHING
D09 SPECIAL SCREW
D10 DUCT B AS
D11 HOSE DRAIN *I
D12 CLAMP AS
D13 CLAMP HOSE
D14 CLAMP HOSE
D15 AIR TRAP
D16 HOSE AIR(PRESSURE)
D17 DAMPER FRICTION
D18 DAMPER PIN
D19 TUB FRONT
D20 SPRING SUSPENSION
D21 SPECIAL SCREW
D22 SPECIAL SCREW
D23 LIFTER WASH
D24 SCREW TAPPING
D25 DRUM AS
D26 SPIDER AS
D27 WATER SEAL
D28 SEALING TUB
D29 FIXTURE HEATER
D30 BEARING INNER
D31 DAMPER FRICTION
D32 DAMPER PIN
D33 TUB REAR AS
D34 BALANCER WEIGHT T
D35 BALANCER WEIGHT T(WASH)
D36 SPECIAL SCREW
D37 CLAMP HOSE
D38 SPECIAL SCREW
D39 UNIT BUBBLE GENERATOR
D40 HOSE VENT
D41 BEARING OUTER
D42 HEATER WASH
D43 PIPE DUCT AS
D44 UNIT STATOR BLDC
D45 SPECIAL BOLT AS
D46 UNIT ROTOR BLDC
D47 SPECIAL BOLT AS
CODE SPECIFICATIONS
3616110600
3616029400 SWCH 8.5X30
3616110500
3611207000
3612325300
3612325400
3618111200 PP
3611206800 GI 1.2T
3616029810 SWCH 6.5X45
3610DUTL00
3613275200
3611203210 ID=61, WIRE+GUIDE+BOLT, GS
3611204700 D26
3611201401 HSW3,YW,D2.6,ID36,W44.5
361A500101 PP
3613266930
361A700110
361A700200 AKS D=14.5
3618830000
3615116800 KGF
3616029800 SWCH 6.5X30
3616029500 SUS430 8*25
361A401300 PP,1PIECE,TWIST
7122401408 T2S TRS 4X14 SUS,STS
3617012500
361A301200
361A600100 NBR
3612321601
3612006700 SUS
3616303100 6206Z
361A700130
361A700200 AKS D=14.5
36100T1400
3616110400
3616110700
3616029400 SWCH 8.5X30
3611204700 D26
3616007400 T2S TRS 4X10+24
36189L4177 HIGH,PAD B,BL/WH,320,RP4,GUIDE O,SPONGE 200
3613267100 EPDM
3616303200 6205Z
3612803700 230V 2000W.1R5A721002.IRCA FUSE 2EA
3614414001
36189L6200 AL,30T(28T),NMT
3616029900 SWCH M8 + SILOCK
36189L6300 L'SERIES, NMT
3616029620
17
Q'TY REMARK
1
8
1
1
1 FOR WASH
1 FOR DRY
1
1 FOR DRY
4
1 FOR DRY
1
1
1
1
1
1
2
2
1
2
14
3
3
3
1
1
1
1
1
1
2
2
1
1 FOR DRY
1 FOR WASH
2
1
2 OPTION
1 OPTION
1
1
1
1
1
6
1
1
