- Page 1 Port Forwarding Setup Guide (NP800 Series)
- Page 2 Port Forwarding with the NP800 Series Port forwarding enables programs or devices running on your LAN to communicate with the internet as if they were directly connected. This is most commonly used for VOIP ATA devices or online gaming (via game console or computer).
- Page 3 Adding a Port Forwarding Rule This guide will take you through the steps required to add a port forwarding rule to your modem / router. Port Forwarding is required when applications require ports to be open to operate correctly. You will need to know the port/s that you are trying to open, and also the IP Address of the device (computer, VoIP ATA, etc.) that you are Port Forwarding to.
- Page 4 Configuring the NP800 Series Router 1. Navigate to http://192.168.20.1 in a web browser. 2. If asked to login, the default username and password is "admin" and "admin" without the quotes. 3. Select Advanced on the left-menu then Port Fw. from the top-menu.
- Page 5 In above example, 192.168.20.2 is the IP address. For Protocol, Select the correct protocol type for your ports traffic, either TCP or UDP. If you are unsure what protocol your port requires, choose Both. In the above example, TCP is selected. In the above example, we have port forwarded the port 3000.
- Page 6 Now press the Apply button. Port Forwarding for port 3000 to the device connected to the router using the IP address 192.168.20.2 has now been configured. For more information on Port Forwarding, Please visit www.portforward.com Please note: Some services require more than one port forwarded. You can do this by specifying a sequential range of ports instead of just one.
