SERVICE MANUAL

MODEL
KD-28DX51U
KD-28DX51E
COMMANDER
DEST
CHASSIS NO.
RM-949
UK
SCC-Q52W-A
RM-949
ESP
SCC-R43A-A
MODEL
KD-32DX51U
KD-32DX51E
KD-28/32DX51
- 1 -
FE-2D
CHASSIS
COMMANDER
DEST
CHASSIS NO.
RM-949
UK
SCC-Q52V-A
RM-949
ESP
SCC-R43B-A
RM-949

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Trinitron KD-28DX51U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony Trinitron KD-28DX51U

Summary of Contents for Sony Trinitron KD-28DX51U

  • Page 1: Service Manual

    SERVICE MANUAL FE-2D CHASSIS MODEL MODEL COMMANDER DEST CHASSIS NO. COMMANDER DEST CHASSIS NO. KD-28DX51U KD-32DX51U RM-949 SCC-Q52V-A RM-949 SCC-Q52W-A KD-28DX51E KD-32DX51E RM-949 SCC-R43B-A RM-949 SCC-R43A-A KD-28/32DX51 RM-949 - 1 -...

  • Page 2: Table Of Contents

    TANCE CRITIQUE POUR LA SÈCURITÈ DU FONCTIONNEMENT, THESE COMPONENTS WITH SONY PARTS WHOSE PART NE LES REMPLACER QUE PAR DES COMPSANTS SONY DONT NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN LE NUMÈRO DE PIÈCE EST INDIQUÈ DANS LE PRÈSENT SUPPLEMENTS PUBLISHED BY SONY.
  • Page 3 Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com - 3 -...
  • Page 4 l l a l l a . s l . s l . s l . s l e i l & n i l i g i i n i WARNING (UK Models only) The flexible mains lead is supplied connected to a B.S. 1363 fused plug having a fuse of 5 AMP rating.
  • Page 5 21 pin connector Pin No Signal Signal level Audio output B Standard level : 0.5V rms (right) Output impedence : Less than 1kohm* Audio input B Standard level : 0.5V rms (right) Output impedence : More than 10kohm* Audio output A Standard level : 0.5V rms (left) Output impedence : Less than 1kohm*...

  • Page 6: Self Diagnostic Software

    FE-2D SELF DIAGNOSTIC SOFTWARE The identification of errors within the FE-2D chassis is triggered in one of two ways :- 1: Busy or 2: Device failure to respond to IIC. In the event of one of these situations arising the software will first try to release the bus if busy (Failure to do so will report with a continuous flashing LED) and then communicate with each device in turn to establish if a device is faulty.

  • Page 7: General

    SECTION 1 GENERAL - 7 -...
  • Page 8 - 8 -...
  • Page 9 - 9 -...
  • Page 10 - 10 -...
  • Page 11 - 11 -...
  • Page 12 - 12 -...
  • Page 13 - 13 -...

  • Page 14: Disassembly

    SECTION 2 DISASSEMBLY 2-1. Rear Cover Removal => => => => Remove the rear cover fixing screws indicated and withdraw the rear cover from the Beznet. 2-2. Chassis Removal and Refitting When refitting the chassis ensure that the main bracket is located in the beznet guide slots before sliding the chassis forwards.

  • Page 15: A Board Removal [Step 1]

    2-3. A Board Removal [ Step 1 ] 2-4. A Board Removal [ Step 2 ] Clip. Screw. Remove the 3 screws securing the PWB to the main bracket. Release the 5 securing clips located around the side of the 1 can be seen in the photo above and the other 2 are either chassis and slide the PWB clear of the bracket.

  • Page 16: A1 Board Removal

    2-6. A1 Board Removal 2-7. Service Position Clip. Release the 4 securing clips located around the side of the Position the chassis as indicated to access the solder side chassis and slide the PWB clear of the bracket. of the PWB’s. To gain access to the A Board follow the instructions on page 18.

  • Page 17: Picture Tube Removal

    2-9. Picture Tube Removal WARNING: BEFORE REMOVING THE ANODE CAP High voltage remains in the CRT even after the power is disconnected. To avoid electric shock, discharge CRT before attempting to remove the anode cap. Short between anode and CRT coated earth ground strap.
  • Page 18 - 18 -...

  • Page 19: Set-Up Adjustments

    SECTION 3 SET-UP ADJUSTMENTS • Carry out the adjustments in the following order : When complete readjustment is necessary or a new picture 3-1. Beam Landing. tube is installed, carry out the following adjustments. 3-2. Convergence. • Unless there are specific instructions to the contrary, carry 3-3.

  • Page 20: Convergence

    If the V.STAT magnet is moved in the direction of the (a) 3-2. Convergence and (b) arrows, the Red, Green and Blue points move as indicated below. Preparation: • Before starting this adjustment, adjust the focus, horizontal size and vertical size. •...
  • Page 21 Geometry Adjustment. YCH Adjustment Preparation: YCH VR 28" YCH VR 32" Before starting this adjustment, adjust the horizontal and vertical static convergence. Deflection Yoke Deflection Yoke Remove the deflection yoke spacer. Tilt the deflection yoke as indicated in the figure below and TLV Adjustment optimise the geometry.

  • Page 22: Focus Adjustment

    Layout of each control 3-4. Screen (G2), White Balance [Adjustment in the service mode using the remote commander] G2 adjustment Input a dot signal from the pattern generator. Set the Picture, Brightness and Colour to minimum. Apply 165V DC from an external power supply to the R, G V.STAT and B cathodes of the CRT.

  • Page 23: Circuit Adjustments

    SECTION 4 CIRCUIT ADJUSTMENTS 4-1. Electrical Adjustments Service adjustments to this model can be performed using the supplied remote Commander RM-949. How to enter into the Service Mode Turn on the main power switch and enter into the stand-by mode. Press the following sequence of buttons on the Remote Commander.
  • Page 24 Deflection System Adjustment Sub Brightness Adjustment Set the TV set or operation in Service Mode [ See Page 23 ] Input a Monoscope pattern. and enter into the ‘Geometry’ service menu. Set the TV set or operation in Service Mode. [ See Page 23 ]. Select and adjust each item in order to obtain the optimum image.

  • Page 25: Test Mode

    4-2. TEST MODE 2: Test Mode 2 is available by programming the TV set for operation in Service Mode [ As shown on Page 23 ], OSD ‘TT’ appears. The functions described below are available by selecting the two numbers. To release the ‘Test mode 2’, press 00, 10, 20 ... twice or switch the TV set into Stand-by mode.

  • Page 26: Block Diagrams

    5-1. BLOCK DIAGRAMS (1) CN8801 SMART IC8401 R.G.B. OUT MULTIPLEXER/ DE-MULTIPLEXER CN8401 CN707 MOSFET BUFFER AMP Y IN CN8402 TO A BOARD (2/2) SWITCH Q8402 V OUT CN508 Q8801 SWITCH Q8405 A BOARD (2/2) SWITCH Q8802 CN512 CN706 Q8803 U OUT BUFFER AMP IC8801 U IN...

  • Page 27: Block Diagrams

    5-1. BLOCK DIAGRAMS (2) CN4101 RIGHT Q4103 TUNER LOCK LOCK LEFT AND LED TUNER MUTE TU4102 (TV) SWITCH FBLK Q4106 CVBS SWITCH SCL (TV) Q4107 FM/AM IC4104 SWITCHES A/D VIDEO VIDEO Q4114 SWITCH IC4105 Q4116 IC4102 SCL (TV) PORT EXPANDER CN4104 SDA (TV) SDA-TV...

  • Page 28: Block Diagrams

    5-1. BLOCK DIAGRAMS (3) A 2/2 ( POWER SUPPLY, CN606 DEFLECTION, VIDEO, AUDIO AC IN F5 BOARD IC501 AC IN CN6102 V OUTPUT PH601 ISOLATOR CN607 CN501 LOW B AC OUT V- DY+ BOOST MAIN RECT A1 BOARD D601 AC OUT V- DY- CN4601 RELAY...

  • Page 29: Circuit Board Location

    ~ A Board Difference Table~ ~ A Board IC Voltage Table~ ~ A Board Waveforms ~ 5-2. CIRCUIT BOARD LOCATION Reference Information RESISTOR : METAL FILM 20us/div 20us/div : SOLID C Board FPRD : NON FLAMMABLE CARBON FUSE : NON FLAMMABLE FUSIBLE : NON FLAMMABLE METAL OXIDE VM Board : NON FLAMMABLE CEMENT...
  • Page 30 ~ A Board Semiconductor Location Table ~ NOTE: ~ A Printed Wiring Board Conductor side ~ Portions of the circuit marked as shown are high voltage areas. Use care to prevent electric shock during inspection or repair. - 30 -...

  • Page 31: A Board Schematic

    A..-28/32DX51 POWER SUPPLY R603 C621 470p 1/2W 500V JW643 D601 FB602 R613 D4SB60L-F C603 8.2M 1.1uH T603 D639 2200p C613 R608 R611 JW644 250V 1500p 2.7k CN606 PS1201 L603 1/10W 1/10W AUDIO_VCC 6.8uH JW645 R606 OCP DETECT TO F5 BOARD AC IN C612 R625...
  • Page 32 A..-28/32DX51 JR505 CN512 CHIP R045 IC501 1/10W STV9379 V OUTPUT SMART L504 C516 TP10 H.DY- JR508 1200V C582 CHIP R589 1200V D502 R588 R564 C503 R542 CHIP PDZ22B-115 CN501 D512 L505 Q576 EL1Z 270uH FOCUS H.DY+ R504 R503 C504 C501 R561 R562 R590...
  • Page 33 TO A1 BOARD SERVICE CN4104 CN001 CN301 CN102 CN101 TU101 MONO A..-28/32DX51 STEREO C106 C105 0.01 L101 JW217 JW411 L104 56uH 22.5MM 4.7uH 7.5MM J404 JW218 L103 C101 C112 L102 22.5MM R100 JR114 JW409 17.5 4.7uH C100 47uH D102 XX L403 C108 XX C435...
  • Page 34 TO H BOARD CN4002 A..-28/32DX51 CN1202 CN1201 CN1200 J1200 IC1201 C1225 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL TDA7495S AUDIO AMP R1217 R1202 JW1232 XX JW1227 XX 1/10W JW1209 4/4 AUDIO JW1216 XX C1220 C1203 JW1217 C1227 C1204 XX C1200 C1232...
  • Page 35 ~ A1 Printed Wiring Board Conductor side A ~ ~ A1 Board Semiconductor Location Table (side A) ~ ~ A1 Printed Wiring Board Conductor side B ~ ~ A1 Board Semiconductor Location Table (side B) ~ - 35 -...

  • Page 36: A1 Board Schematic

    TO N BOARD CN4101 L4606 10uH C4641 R4638 C4841 C4640 1/10W 0.22 3.3V Q4605 C4639 R4629 2SA1162-G 0.22 C4121 6.8k 0.22 2VPP-AorD.CVBS FE-RESET C4842 FL4104 FL4105 Q4606 FL4101 FL4102 FL4103 Q4607 2SC1623 C4637 2SC1623 R4631 C4840 3.3k AV2-UOC 1/10W R4634 R4636 C4638 12VA...
  • Page 37 A1.-28/32DX51 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL TU4800 5VAEMI FB4801 C4819 C4825 3.3V 0.01 D4801 FB4802 RB501V-40TE-17 R4129 TUNER LOCK D4802 D4810 C4817 C4828 C4812 0.01 RB501V-40TE-17 SPLITTER FE-RESET R4116 Q4103 +5V B1 R4851 R4805 FB4800 D4800 L4802 1/16W...

  • Page 38: H5 Board Schematic

    H5.-28/32DX51 F5.-28/32DX51 HEADPHONE, SVHS & PHONO COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL J4000 CN6102 S6100 CN6100 F001 AC OUT JW4000 JW4001 TO A BOARD AC IN TO F3 BOARD CN606 C4006 CN3603 AC IN AC OUT 1000p R6100 VDR6100...
  • Page 39 ~ H5 Printed Wiring Board Conductor Side ~ ~ B1 Printed Wiring Board Conductor Side ~ ~ F5 Printed Wiring Board Conductor Side ~ ~ F3 Printed Wiring Board Conductor Side ~ - 39 -...

  • Page 40: C Board Schematic

    ~ C Board Semiconductor Voltages ~ ~ C Board Difference Table ~ ~ C Board IC Voltages ~ ~ C Board Waveforms ~ 20us/div 20us/div 2.32 Vp-p (H) 2.32 Vp-p (H) 20us/div 20us/div C..-28/32DX51 2.32 Vp-p (H) 116 Vp-p (H) CN704 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL 20us/div...
  • Page 41 ~ D2 Printed Wiring Board ~ ~ C Printed Wiring Board ~ ~ VM Printed Wiring Board ~ - 41 -...

  • Page 42: Vm Board Schematic

    VM.-28/32DX51 R1954 R1955 D1909 220k 330k 1SS133 CHIP CHIP VELOCITY MODULATION C1952 C1953 3300p CN1901 R1956 R1953 C1951 8.2M 270k CHIP IC1902 L1904 L1903 LM358N R1957 C1957 R1965 R1968 R1966 C1918 150uH 0.22 DF/DQP TIMING CHIP CHIP Q1906 R1960 2SC2412K-T-146-R R1958 C1955 R1964...

  • Page 43: Semiconductors

    5-4. SEMICONDUCTORS CXA1875AM-T4 NJM4556AD TDA6108JF/NIB ( TOP VIEW ) L78L33ABZ-AP PCF8593/T118 TDA7495S 2SC3840(3) LA6393DLL PC123F2 TDA9394H/N1/5/0716 LM2940T-9.0 PQ05RF11 PQ3RF33 ( MARKING SIDE VIEW ) LM358N BA09T TLP721(D4-GR.T) LM393DT SE-012N-LF4 LM393PS ( TOP VIEW ) M24C32-WMN6T(A) SE135N-LF4 TOP209P MC14053 BDR2 TOP VIEW 8 PIN SOP ( TOP VIEW ) 3 GND...
  • Page 44 1SS119-25 BAS316-115 L-59SRSGC-CC 1SS133T-77 DTZ-TT11-6.8B ERA38-06 MM3Z12VT1 ANODE FUF4005 MM3Z4V7T1 CATHODE HZS9.1NB2 MM3Z6V8T1 MTZJ-4.7C MM3Z9V1ST1 CATHODE MTZJ-T-77-9.1A PDZ9.1B-115 MTZJ-33A PDZ22B-115 MTZJ-7.5B UDZSTE-175.6B P6KE200ASY ANODE RK46LFT2 RD3.6ES-B2 RD5.1ESB2 AG01ZV0 RD5.6ESB2 D2S4MF RD6.8ES-B2 RD10ESB2 2SA1162-G 2SA1037AK-T146 2SC1623-L5L6 D4SB60L UGB8BT-31 2SC2412K-T-146-R 2SD601A-Q-TX DTC114EKA-T146 –...

  • Page 45: Ic Block Diagrams

    5-5. IC BLOCK DIAGRAMS A BOARD IC501 STV9379A A BOARD IC401/IC531 LM393DT FLYBACK GENERATOR POWER AMPLIFIER THERMAL PROTECTION A BOARD IC601 MCZ3001D Remote DVLD Internal Driver Sel=34v ref 5v Reg. 10v 15v/8v Level Shift Vsense Control Logic Latch Centre Timer A BOARD IC1201 TDA7495S VOLUME OP AMP...

  • Page 46: Exploded Views

    SECTION 6 EXPLODED VIEWS NOTE : Items with no part number and no description are not Items marked “*” are not stocked stocked because they are seldom required for routine since they are seldom required for service. routine service. Some delay should The construction parts of an assembled part are indicated be anticipated when ordering these items.

  • Page 47: Picture Tube

    6-2. PICTURE TUBE REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK - 47 -...

  • Page 48: Electrical Parts List

    SECTION 7 ELECTRICAL PARTS LIST PARTS LISTING TABLE OF CONTENTS Page D2 BOARD COMPLETE Parts List : Parts common to all models listed in this manual ....Model Parts that belong only to the model specified KV-28DX51U ....................49 KV-32DX51U ....................
  • Page 49 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK * A-1302-976-A D2 Board Complete KD-28DX51 * A-1302-977-A VM Board Complete KD-28DX51 * A-1302-957-A D2 Board Complete KD-32DX51 * A-1302-958-A VM Board Complete KD-32DX51 D2 Board Common Parts VM Board Common Parts <...
  • Page 50 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < IC > R1955 1-216-849-11 METAL CHIP 220K 5% 1/10W R1956 1-218-463-11 RES-CHIP 8.2M 5% 1/10W IC1701 8-759-394-36 IC BA09T R1957 1-216-833-11 METAL CHIP 1/10W IC1901 8-759-659-67 IC LA6393DLL R1958 1-216-809-11 METAL CHIP 1/10W IC1902 8-759-008-70...
  • Page 51 VM A REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C1959 1-137-190-91 FILM 0.22UF 5.00% 50V C036 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V C037 1-136-244-11 FILM 0.1UF 2.00% 50V < CONNECTOR > C038 1-163-038-91 CERAMIC CHIP 0.1UF C039 1-164-505-11 CERAMIC CHIP 2.2UF CN1702 * 1-564-506-11 PLUG, CONNECTOR 3P...
  • Page 52 F4 A REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C410 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C545 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V C411 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V C546 1-129-719-61 FILM 0.027UF 5.00% 630V C412 1-164-346-11 CERAMIC CHIP 1UF C547 1-115-519-11 FILM...
  • Page 53 D2 A REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C657 1-126-952-11 ELECT 1000UF 20.00% 35V D007 8-719-069-55 DIODE UDZSTE-175.6B C1201 1-126-952-11 ELECT 1000UF 20.00% 35V D008 8-719-074-43 DIODE BAS316-115 C1203 1-535-303-00 LEAD,JUMPER (5.0MM) D010 8-719-074-43 DIODE BAS316-115 C1207 1-126-960-11 ELECT 20.00% 50V D011...
  • Page 54 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK D436 6-500-028-01 DIODE MM3Z9V1ST1 < FILTER > D501 8-719-979-85 DIODE EGP20G D502 8-719-081-90 DIODE PDZ22B-115 FL201 1-239-803-11 FILTER, EMI D503 8-719-069-55 DIODE UDZSTE-175.6B D504 8-719-074-43 DIODE BAS316-115 < IC > D512 8-719-302-43 DIODE EL1Z IC001 6-804-536-01...
  • Page 55 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK L505 1-412-542-41 INDUCTOR 270UH JR10 1-216-295-91 SHORT CHIP L507 1-412-533-21 INDUCTOR 47UH JR16 1-216-296-11 SHORT CHIP L532 1-412-553-11 INDUCTOR 3.3MH JR17 1-216-295-91 SHORT CHIP L533 1-406-989-21 INDUCTOR 10MH JR105 1-216-295-91 SHORT CHIP L534 1-216-025-11 RES-CHIP...
  • Page 56 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R039 1-216-065-91 RES-CHIP 4.7K 5% 1/10W R236 1-216-057-00 RES-CHIP 2.2K 5% 1/10W R040 1-216-033-00 RES-CHIP 1/10W R238 1-216-025-11 RES-CHIP 1/10W R041 1-216-025-11 RES-CHIP 1/10W R246 1-260-107-11 CARBON 4.7K 5% 1/2W R042 1-216-025-11 RES-CHIP 1/10W R248...
  • Page 57 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R445 1-216-022-00 RES-CHIP 1/10W R556 1-215-918-00 METAL OXIDE 1.5K 5% R446 1-216-113-00 RES-CHIP 470K 5% 1/10W R557 1-216-067-00 RES-CHIP 5.6K 5% 1/10W R447 1-216-295-91 SHORT CHIP R558 1-216-057-00 RES-CHIP 2.2K 5% 1/10W R448 1-216-113-00 RES-CHIP...
  • Page 58 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R1202 1-216-073-91 RES-CHIP 1/10W < CONNECTOR > R1203 1-216-049-11 RES-CHIP 1/10W R1207 1-216-077-91 RES-CHIP 1/10W CN503 NOT FITTED R1210 1-216-077-91 RES-CHIP 1/10W R1213 1-216-049-11 RES-CHIP 1/10W < DIODE > R1214 1-216-049-11 RES-CHIP 1/10W D535 1-806-326-11...
  • Page 59 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK A Board Variant Parts KD-32DX51 R601 1-218-843-11 METAL CHIP 0.5% 1/10W R1847 1-216-499-21 METAL OXIDE < CAPACITOR > R1848 1-216-499-21 METAL OXIDE C508 NOT FITTED < TRANSFORMER > C530 1-137-374-11 MYLAR 0.047UF 5.00% 50V C542 1-162-116-00...
  • Page 60 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C8405 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V < CONNECTOR > C8406 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C8407 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V CN3601 £ * 1-580-843-11 PIN, CONNECTOR (POWER) CN3602 1-695-915-11 TAB (CONTACT) C8408...
  • Page 61 C H5 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK D702 8-719-901-83 DIODE 1SS83 R1808 1-216-833-11 METAL CHIP 1/10W R1809 1-216-833-11 METAL CHIP 1/10W D703 8-719-302-43 DIODE EL1Z R1810 1-216-833-11 METAL CHIP 1/10W D704 8-719-110-17 DIODE RD10ESB2 R1811 1-216-825-11 METAL CHIP 2.2K 5% 1/10W D705...
  • Page 62 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < COIL > C4136 1-126-947-11 ELECT 47UF 20.00% 35V C4137 1-126-964-11 ELECT 10UF 20.00% 50V L4000 1-535-303-00 LEAD, JUMPER (5.0MM) C4138 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C4139 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V <...
  • Page 63 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C4602 £ 1-161-964-91 CERAMIC 0.0047UF 250V C4828 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C4603 1-137-635-41 ELECT(BLOCK) 68UF 450V C4830 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C4604 1-127-568-51 CERAMIC 4700PF C4832 1-164-874-11 CERAMIC CHIP 100PF 5.00% 50V C4605 1-126-964-11...
  • Page 64 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < FERRITE BEAD > < COIL > FB4109 1-469-869-21 FERRITE L4102 1-412-002-31 INDUCTOR 4.7UH FB4110 1-469-869-21 FERRITE L4103 1-412-002-31 INDUCTOR 4.7UH FB4111 1-469-869-21 FERRITE L4300 1-469-842-21 INDUCTOR 0.47UH FB4300 1-400-244-11 FERRITE L4600 1-410-397-21 FERRITE 1.1UH...
  • Page 65 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4140 1-218-965-11 RES-CHIP 1/16W R4313 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W R4141 1-218-965-11 RES-CHIP 1/16W R4315 1-218-887-11 METAL CHIP 0.5% 1/10W R4142 1-218-965-11 RES-CHIP 1/16W R4320 1-218-941-11 RES-CHIP 1/16W R4143 1-218-965-11 RES-CHIP 1/16W R4332 1-414-772-11...
  • Page 66 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4827 1-208-683-11 METAL CHIP 0.5% 1/16W A1 Board Variant Parts KD-28/32DX51E R4830 1-218-989-11 RES-CHIP 1/16W R4831 1-218-965-11 RES-CHIP 1/16W < CAPACITOR > R4832 1-218-965-11 RES-CHIP 1/16W R4833 1-216-809-11 METAL CHIP 1/10W C4635 1-165-908-11 CERAMIC CHIP 1UF C4816...
  • Page 67 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK MISCELLANEOUS £ 1-786-649-11 SWITCH, AC POWER PUSH 1-424-733-11 COIL, PFC CHOKE 65MMH £ 1-783-083-11 CORD, POWER (FILTER) (KD-28/32DX51E) £ 1-776-204-11 CORD, POWER (FILTER) (KD-28/32DX51U 1-693-556-14 FRONTEND (TUNER+IF) (KD-28/32DX51E) 1-693-557-14 FRONTEND (TUNER+IF) (KD-28/32DX51U) 8-597-929-00 TUNER, FSS BTP-DU601 £...
  • Page 68 • User programmable Functional Check through Infrared • Fast and documented Test Mode setting of all Sony TV chassis Additional features such as Adjustments and Troubleshooting are available in chassis-dependent software modules. Please contact your local Sony Service organisation for the latest information.
