Summary of Contents for Sony KDL-19BX200
- Page 1 AZ1-BK(5-3) SERVICE MANUAL CHASSIS MODEL MODEL DEST DEST KDL-19BX200 KDL-22BX200 AEP / UK / RUSS AEP / UK / RUSS RM-ED037 - -...
-
Page 2: Table Of Contents
COMPONENTS IDENTIFIED BY SHADING AND MARKED THE EXPLODED VIEWS AND IN THE PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. - -... -
Page 3: Caution
Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com UK PLUG WARNING WARNING (UK Models only) The flexible mains lead is supplied connected to a B.S. -
Page 4: Specifications
SPECIFICATIONS Specifications Model name KDL-19BX200 KDL-22BX200 System Panel System LCD (Liquid Crystal Display) Panel TV System Analogue: Depending on your country/region selection: B/G, D/K, I, L Digital: DVB-T Colour/Video System Analogue: PAL, PAL60 (only video input), SECAM, NTSC3.58, NTSC4.43 (only video input) Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC MP/HP@L4 Channel Coverage Analogue: VHF:E2-12 / UHF: E21-E69 / CATV:S1-S20 / HYPER: S21-S41 / D/K: R1-R12, R21-R69 / L: F2-F10,B-Q, F21-F69 / I: UHF B21-B69 Digital: VHF / UHF Sound Output 3 + 3 W Input/Output jacks Aerial / Cable 75 ohm external terminal for VHF / UHF 21-pin scart connector including audio / video input, S-Video input, RGB input and TV / AV1 audio/video output. Supported formats: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i / Y Pb Pr IN Y: 1 Vp-p, 75 ohm, 0.3V negative sync. / Pb/Cb: 0.7 Vp-p, 75 ohm / Pr/Cr: 0.7 Vp-p, 75 ohm Audio input (mini jack) Y Pb Pr IN HDMI IN Supported formats: 1080/24p 1080p, 1080i, 720p, 576p, 576i, 480p, 480i Audio: Two channel linear PCM: 32, 44.1 and 48 kHz, 16, 20 and 24 bit, Dolby Digital 32, 44,1 and 48 kHz, Max bit rate 640 kHz... - Page 5 Standby Power Consumption 0.76 W Average annual energy 39 kWh 63 kWh Consumption Dimensions (with stand) 457.3 x 334.5 x 152.6 mm 524.5 x 375.2 x 152.6 mm (W x H x D) (Approx) (without stand) 457.3 x 310.8 x 62.8 mm 524.5 x 352.3 x 66.7 mm Mass (with stand) 4.0 Kg 4.5 Kg (Approx.) (without stand) 3.7 Kg 4.3 Kg Design and specifications are subject to change without notice. 4 hours a day and 365 days a year. PC Input Signal Reference Chart for PC and HDMI IN Resolution Horizontal Vertical Standard frequency frequency (Hz) Signals Horizontal...
-
Page 6: Connectors
CONNECTORS Pin Connector (SCART) Pin No AV-1 AV-2 Signal Signal Level • • Audio Output B Standard Level: 0.5V rms (Right) Impedance: less than 1KΩ* • • Audio Input B Standard Level: 0.5V rms (Right) Impedance: more than 10KΩ* •... -
Page 7: Stand Assy Removal
SECTION 2 DISASSEMBLY 2-1. Stand Assy Removal 2-2. Rear Cover Removal = > > => > To remove the ‘Rear Cover’ first remove the ‘Stand Assy’ To remove the ‘Stand Assy’ remove the 2 stand fixing screws (See Sec 2-2-1) then remove the fixing screws indicated indicated and pull the ‘Stand Assy’... -
Page 8: Switch Unit Board Removal
2-5. Switch Unit Board Removal 2-6. Power Unit Board Removal Screw Screws To remove the ‘Switch Unit’ board remove the 1 screw circled, To remove the ‘Power Unit’ board disconnect all the connectors then remove the 1 connector and ease the board gently away and then remove the 4 screws circled and ease the board gently from the rear of the TV set. -
Page 9: Service Menus
SECTION 3 SERVICE MENUS 3-1. How to enter the Service Mode 3-2. Service Menu Structure Service adjustments to this model can be performed using the The following descriptions show the items that can be supplied Remote Commander (See front cover). viewed and/or adjusted using the Service Menu. -
Page 10: Option 2 Menu
3-2-3. Option 2 Menu 3-2-4. Sound Options Menu The following menu appears on the screen when you enter The following menu appears on the screen when you enter the ‘Option 2’ menu (See Pic.4). the ‘Sound Options’ menu (See Pic.5). Pic.4 Pic.5 OPTION 2... -
Page 11: Block Diagram
4-1. BLOCK DIAGRAM Panel 50/60Hz PSU (LIPS) - 11 -... -
Page 12: Circuit Board Location
4-2. CIRCUIT BOARD LOCATION 5-2. CIRCUIT BOARD LOCATION Reference Information RESISTOR : METAL FILM : SOLID FPRD : NON FLAMMABLE CARBON Power Unit Brd Main Brd FUSE : NON FLAMMABLE FUSIBLE : NON FLAMMABLE METAL OXIDE : NON FLAMMABLE CEMENT : NON FLAMMABLE WIREWOUND CVM Board S1 Board... -
Page 13: Exploded Views
SECTION 5 EXPLODED VIEWS NOTE : Non-serviceable items with no part number and no Items marked “*” are not stocked description are not stocked because they are not since they are seldom required for required for routine service. routine service. Some delay should The construction parts of an assembled part are indicated be anticipated when ordering these items. - Page 14 5-1. CHASSIS Cont. REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK 1-858-452-11 LOUDSPEAKER (3.0x7.0CM) 19 inches 1-858-453-11 LOUDSPEAKER (3.5x15.0CM) 22 inches 1-489-163-11 SWITCH UNIT BOARD, COMPLETE - 14 -...
-
Page 15: Bezel Assy & Stand Assy
5-2. BEZEL ASSY & STAND ASSY REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK X-2548-549-1 19 BEZEL ASSY BLACK 4-178-410-01 19 NECK BLACK X-2548-551-1 19 BEZEL ASSY WHITE 4-193-020-01 19 NECK WHITE X-2548-552-1 22 BEZEL ASSY BLACK 4-178-422-01 22 NECK BLACK X-2548-554-1 22 BEZEL ASSY WHITE 4-193-021-01 22 NECK WHITE X-2548-560-1 19/22 STAND ASSY BLACK... -
Page 16: Rear Cover Assy & Power Supply Cords
5-3. REAR COVER ASSY & POWER SUPPLY CORDS UK MODELS ONLY REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK X-2548-555-1 19 REAR COVER ASSY BLACK £ 1-838-166-11 POWER-SUPPLY CORD (AEP) £ 1-838-167-11 POWER-SUPPLY CORD (UK) X-2548-556-1 19 REAR COVER ASSY WHITE X-2548-557-1 22 REAR COVER ASSY BLACK X-2548-558-1 22 REAR COVER ASSY WHITE - 16 -... -
Page 17: Parts List
Note: To ensure safety and reliability it is Sony policy that boards should not be repaired in the field, as a result all boards are regarded as non service items for exchange only and are not indicated in the parts list of this service manual. - Page 18 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK ACCESSORIES AND CONNECTORS 1-838-168-11 FLEXIBLE FLAT CABLE (30P) (TCON-SIGNAL BRD) (Used with all LCD panels except the 22” CH3G panel) 1-838-288-11 FLEXIBLE FLAT CABLE (30P) (TCON-SIGNAL BRD) (Used with 22” CH3G LCD panel only) 1-910-600-04 CONNECTOR ASSY 5P 19 inches 1-910-600-05 CONNECTOR ASSY 5P 22 inches INSTRUCTION MANUALS *4-193-041-01 INSTRUCTION MANUAL *4-193-042-01 INSTRUCTION MANUAL DVD REMOTE COMMANDER 1-489-037-11 REMOTE COMMANDER (RM-ED037) - 18 -...
- Page 19 English Sony Corporation 10DP7100-1 Sony UK Printed in U.K. Service Promotions Dept. © 2010.04 9-883-485-01...
