SERVICE MANUAL

MODEL NAME
KD-27FS170
KD-32FS170
KD-36FS170
9-965-996-01
REMOTE COMMANDER
RM-YD006
RM-YD006
RM-YD006
KD-32FS170
BA-6
DESTINATION
CHASSIS NO.
US
SCC-S61Y-A
US
SCC-S81A-A
US
SCC-S81B-A
®
TRINITRON
COLOR TELEVISION
Self Diagnosis
Supported model
CHASSIS
RM-YD006

Advertisement

Table of Contents

   Related Manuals for Sony KD-27FS170

   Summary of Contents for Sony KD-27FS170

  • Page 1: Service Manual

    Self Diagnosis Supported model BA-6 SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO. KD-27FS170 RM-YD006 SCC-S61Y-A KD-32FS170 RM-YD006 SCC-S81A-A KD-36FS170 RM-YD006 SCC-S81B-A KD-32FS170 RM-YD006 ® TRINITRON COLOR TELEVISION 9-965-996-01...
  • Page 2 KD-27FS170/32FS170/36FS170 5-3. BLOCK DIAGRAMS AND SCHEMATICS SIGNAL FLOW BLOCK DIAGRAM R & L KD-27FS170/32FS170/36FS170...
  • Page 3 KD-27FS170/32FS170/36FS170 A BOARD SCHEMATIC DIAGRAM (1 OF 3) A BOARD WAVEFORMS FOR JIG TO HS BOARD TO CV BOARD TO M BOARD CN705 CN1106 CN1004 CN102 CN003 CN301 CN004 — 3.2 Vp-p (H) 1.2 Vp-p (H ) 0.9 Vp-p (H )
  • Page 4 KD-27FS170/32FS170/36FS170 A BOARD SCHEMATIC DIAGRAM (2 OF 3) A BOARD WAVEFORMS 2.6V p-p (H) ) 2 12.5V p-p (H) 48.1V p-p (H) — C512 470p R544 :CHIP :CHIP R541 :CHIP 28.2V p-p (V Q582 348 V p-p (H 52.8V p-p (V...
  • Page 5 KD-27FS170/32FS170/36FS170 A BOARD SCHEMATIC DIAGRAM (3 OF 3) IC605 BA50BCOFP-E2 5V REG STBY 5V C645 — C646 1000p D621 IC604 SB140 NJM2391DL1-33 3.3V REG 3.3V D618 C643 SB140 R643 IC603 PQ09RD21JOOH PS605 R641 R647 9V REG 1.1UH — 0.85 AMPS...
  • Page 6 KD-27FS170/32FS170/36FS170 CV BOARD SCHEMATIC DIAGRAM CV BOARD WAVEFORMS 4.10 p-p (H) 3.50V p-p (H) 3.50V p-p (H) KR G1 G4 HV CRT EARTH CN703 TO A BOARD CRT EARTH R761 R717 (T505) 0.47 0.22 — (1P) R718 0.22 R716 CN702...
  • Page 7 KD-27FS170/32FS170/36FS170 HS BOARD SCHEMATIC DIAGRAM [FRONT A/V, MENU KEY, IR DETECTOR] COMPONENT SIDE FRONT VIDEO2 J1231 — R1235 R1236 D1235 C1234 100k RD9.1EW-T1 1/4W 1/4W — R1237 D1236 C1235 R1238 RD9.1EW-T1 1/4W 100k 1/4W TO A BOARD CN002 — CN1004...
  • Page 8 KD-27FS170/32FS170/36FS170 M BOARD SCHEMATIC DIAGRAM (1 OF 5) — TU1100 ET-55HT L1105 JL1101 JL1105 JL1100 JL1102 JL1103 R1111 JL1161 JL1110 JL1109 JL1111 — JL1107 JL1106 JL1108 L1143 C1345 L1144 C1346 0.082 150p 0.068 180p C1245 C1115 1000p B:1608 L1136 L1138 L1132 0.56...
  • Page 9 KD-27FS170/32FS170/36FS170 M BOARD SCHEMATIC DIAGRAM (2 OF 5) IO3.3V — R1185 1/16W CHIP R1186 1/16W :CHIP CRESET_N — Q1104 SSM6N15FU IO3.3V — D1118 R1184 DAN202K 1/16W :CHIP ASEMD0 FB1106 HM601 R1176 R1187 1/16W 1/16W — :CHIP IO3.3V D1114 DAP202K CN1103...
  • Page 10 KD-27FS170/32FS170/36FS170 M BOARD SCHEMATIC DIAGRAM (3 OF 5) SSDDQ150 — SSDDQ0 SDDQ0 SSDDQ1 SDDQ1 SSDDQ2 SDDQ2 SSDDQ3 SDDQ3 SSDDQ4 SDDQ4 SSDDQ5 SDDQ5 DA3.3V SSDDQ6 SDDQ6 IC1104(5/8) SSDDQ7 DAT150 SDDQ7 R8A66950BG SSDDQ8 SDDQ8 ADR2210 — SSDDQ9 DAC33VSS SDDQ9 DAC33VSS SSDDQ10 C1150...
  • Page 11 KD-27FS170/32FS170/36FS170 M BOARD SCHEMATIC DIAGRAM (4 OF 5) — SW2.5V SW2.5V SW2.5V SW2.5V SW2.5V SW2.5V SW2.5V — C1219 C1220 C1121 C1120 C1117 C1122 C1123 6.3V 6.3V B:1608 B:1608 B:1608 B:2012 B:2012 B:1608 B:1608 — SSDDQ150 RB1100 SSDDQ0 1DQ0 SSDDQ1 1DQ1 SW2.5V...
  • Page 12 KD-27FS170/32FS170/36FS170 M BOARD SCHEMATIC DIAGRAM (5 OF 5) JL1148 JL1149 JL1150 JL1151 JL1152 JL1153 JL1154 JL1155 JL1156 JL1157 JL1158 JL1159 — LOW_B — 3.3V 3.3V SW5V 3.3V D1119 MA111-TX JL1145 SW2.5V — IC1113 1.0A NJM2391DL1-33 3.3V REG C1303 C1304 C1274...
  • Page 13 KD-27FS170/32FS170/36FS170 VD BOARD SCHEMATIC DIAGRAM (KD-32FS170/36FS170 ONLY) [VELOCITY MODULATION] COMPONENT SIDE TO CV BOARD CN902 C814 0.056 — CN802 C801 L803 3.3mmH D800 RGP10GPKG23 L800 R807 10mmH 1.8k — TO NECK ASSY R802 CN801 D801 1SS119-25TD R806 Q801 2.2k 2SC2958-L...
